Sealey CP108VCP Manuale utente
10.8V 2AH Ø75MM CORDLESS POLISHER
MODEL NO: CP108VCP
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and all
electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical
products. You may obtain an RCD by contacting your local Sealey stockist.
If the product is used in the course of business duties, it must be maintained in a safe condition and routinely PAT (Portable
Appliance Test) tested.
Electrical safety information, it is important that the following information is read and understood.
1.1.1. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
1.1.2. Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
1.1.3. Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the
correct fuse - see fuse rating in these instructions.
8DO NOT pull or carry the appliance by the power cable.
8DO NOT pull the plug from the socket by the cable. Remove the plug from the socket by
maintaining a rm grip on the plug.
8DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is
repaired or replaced immediately by a qualied electrician.
1.1.4. This product is tted with a BS1363/A 13 Amp 3 pin plug.
If the cable or plug is damaged during use, switch the electricity supply and remove from use.
Replace a damaged plug with a BS1363/A 13 Amp 3 pin plug. If in doubt contact a qualied
electrician.
Class II products are wired with live (brown) and neutral (blue) only are marked with the
Class II symbol;
A) Connect the BROWN live wire to the live terminal ‘L’.
B) Connect the BLUE neutral wire to the neutral terminal ‘N’.
C) After wiring, check that there are no bare wires and ensure that all wires have been correctly
connected.
Ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight.
8DO NOT connect either wire to the earth terminal.
Sealey recommend that repairs are carried out by a qualied electrician.
1.2. BATTERY CHARGER SAFETY INSTRUCTIONS
WARNING! DO NOT use the charging base to charge any battery other than that required for the tool. Other types of batteries may
explode!
9Inspect the plug, cable and the charging base for wear and damage to ensure items are safe before connecting to the mains power
supply. If worn or damaged DO NOT use, immediately replace, or contact a qualied electrician.
9Check cables are always protected against short circuit and overload.
9 Uncoil the power cable between the plug and the charging base before use.
8DO NOT pull or carry the charging base by the charger power lead, or pull the plug from the mains socket by the power lead.
8DO NOT use any other type of transformer with the charging base.
8DO NOT try to open or dis-assemble the plug or charging base.
8DO NOT use the plug to power any other electrical item.
9Disconnect the charging base from the mains power supply when not in use.
8DO NOT expose the charging base to damp or wet conditions (for indoor use only).
8DO NOT operate the charging base if it has been dropped, or has received a sharp knock, or is damaged. Contact an authorised
service agent.
8DO NOT dismantle the charging base as this may cause damage or personal injury and will invalidate your warranty.
8DO NOT insert foreign objects or material into the slot reserved for the battery.
8DO NOT immediately charge a second battery. Consecutive charging will overheat the charging base. Allow the unit to cool for 15
minutes before charging the next battery.
9Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9Ensure that cables are always protected against short circuit and overload.
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Wear protective
gloves
Wear eye
protection
Wear face
mask
Wear ear
protection
CP108VCP Issue 1 13/01/21
Charger: Indoor
Use Only
Recommended Fuse
Rating: 3A
8DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty item replaced by a qualified electrician.
1.3. BATTERY SAFETY PRECAUTIONS
WARNING! Battery contains Lithium-ion which is dangerous. Handle with care to avoid damage, re, corrosion or personal injury.
9 Charge battery prior to its rst use. The battery will have been shipped in a low charge state. To reduce the risk of burns or re:
8DO NOT Attempt to open, disassemble, modify or service the battery pack.
8DO NOT Crush, puncture, short external contacts or dispose of in re or water.
8DO NOT Expose to temperatures above 40°C (104°F).
9Replace only with the battery pack designated for this product.
9 Use only the supplied charging base provided to charge the battery.
8DO NOT attempt recharging the battery by means of an engine generator or a DC power source.
WARNING! Dispose of spent batteries correctly as they contain Lithium-ion. DANGER! DO NOT attempt to disassemble the
battery. For safety and environmental reasons DO NOT discard in domestic waste or by burning. ONLY discard or recycle
according to local authority regulations.
1.4. GENERAL SAFETY
9Disconnect the polisher from the battery unit before changing accessories, servicing or performing any maintenance.
9Maintain the polisher and battery in good condition. Check moving parts alignment on a regular basis.
9 Replace or repair damaged parts. Use an authorised service agent and recommended parts only. Unauthorised parts may be
dangerous and will invalidate the warranty.
9 Ensure the polisher is switched o before installing the battery pack.
9Keep the polisher and charger clean for best and safest performance.
9 Remove ill tting clothing. Remove ties, watches, rings and other loose jewellery and contain long hair.
9 Evaluate your working area before using the polisher e.g. ceilings, oors and enclosures may contain electrical items or water piping.
9Ensure battery pack is correctly inserted into the polisher handle and latched in place before attempting to switch on polisher.
9Secure loose work pieces with a clamp, vice or other adequate holding device.
9Avoid unintentional starting.
9 Wear approved safety eye protection (standard spectacles are not adequate).
9 Maintain correct balance and footing. Ensure the oor is not slippery and wear non-skid shoes.
9Keep children and unauthorised persons away from the working area.
9Store polisher and charger in a safe, dry, childproof area where the temperature will not exceed 104°F (40°C).
8DO NOT use the polisher where there are ammable liquids, solids or gases, such as paint solvents, etc.
8DO NOT allow children to operate the polisher.
8DO NOT operate the polisher if any parts are missing as this may cause failure and/or personal injury.
8DO NOT hold unsecured work piece in your hand.
8DO NOT leave the polisher operating unattended.
8DO NOT carry the polisher with your nger on the power switch.
8DO NOT use the polisher for a task it is not designed to perform.
8DO NOT operate the polisher when you are tired or under the inuence of alcohol, drugs or intoxicating medication.
8DO NOT get the polisher or battery wet or use in damp or wet locations.
2. INTRODUCTION
Compact, lightweight cordless polisher. Comfortable housing with soft grip to help reduce vibration. Variable speed control trigger makes this
polisher very easy-to-use. Supplied with side handle and polishing pad as well as a 1 hour mains charger and 1 x 2Ah rechargeable Lithium-ion
battery.
3. SPECIFICATION
Model No. ............................................................ CP108VCP
Battery ............................... 10.8V 2Ah Lithium-ion (Included)
Consumable parts.............................CP108VBP 2Ah Battery
Free speed..........................................0-2400rpm/0-7600rpm
Noise power/pressure .......................................... 91/80dB(A)
Vibration/rating.............................................. 4.7m/s²/1.5m/s²
Pad size .................................................................... Ø75mm
Emissions rating................................................... 91/80dB(A)
Replacement parts.....................CP108VMC - Mains charger
Thread size ....................................................................... M6
Vibration/uncertainty
Main Handle................................................. ahAG:4.700m/s²
Auxiliary handle......................... ahAG:3.334m/S2 k=1.5m/s²
4. BATTERY CHARGING
4.1. Fully charge the battery before rst use.
WARNING! Only recharge batteries with the charger supplied.
4.2. Remove battery by squeezing buttons in on each side. Insert into battery charger.
4.3. Connect charger to mains supply and red LED will light to signal charging. Once charging is complete LED turns green.
4.4. Remove from mains supply, remove battery and insert into tool until a click is heard.
4.5. BATTERY CHARGE STATUS TEST
4.5.1. Press trigger, all LEDs lit: battery charged, one LED lit: battery needs charging.
4.6. In order to maintain battery eciency:
8DO NOT fully discharge. After every use fully charge the battery, charge every 4 months even if tool is not used.
If a decrease of performance of the tool is noticed, charge the battery.
Original Language Version
© Jack Sealey Limited CP108VCP Issue 1 13/01/21
fig.1
5. OPERATION
WARNING! Before use, ensure that you have read and understood Section 1 Safety Instructions.
5.1. To attach/remove the applicator pad depress the chuck lock button behind the chuck (g.1) and screw/unscrew the applicator pad.
5.2. Release the chuck lock button and check that applicator pad is locked into chuck before switching on.
5.3. Attach the battery to the polisher. Press trigger LEDs (g.1) show charge (three lights indicate full charge).
5.4. Set the required speed by use of the speed selector switch (g.1).
5.5. Unlock the drive lock (g.1).
5.6. Fit and grip the side handle and start the polisher by gentle and slow application of pressure on the trigger (g.1).
5.7. Increase/decrease the speed of the polisher using the variable speed control trigger (g.1) to suit the task in hand.
5.8. Ensure that the above features are working correctly prior to use.
6. MAINTENANCE
WARNING: Always disconnect the battery before carrying out any inspection, maintenance or cleaning.
6.1. GENERAL INSPECTION
6.1.1. Regularly check that all the xing screws are tight.
6.1.2. Repairs should only be carried out by an authorised service centre.
6.2. CLEANING
WARNING: Always wear protective equipment including eye protection and gloves when cleaning this tool.
6.2.1. Keep your tool clean at all times. Dirt and dust will cause internal parts to wear quickly and shorten the device’s service life.
6.2.2. Clean the body of your machine with a soft brush, or dry cloth.
6.2.3. Never use caustic agents to clean plastic parts. If dry cleaning is not sucient, a mild detergent on a mildly damp cloth is
recommended.
6.2.4. Water must never come into contact with the tool. Ensure the tool is thoroughly dry before using it.
6.2.5. If available, use clean, dry, compressed air to blow through the ventilation holes (where applicable).
WARNING! – Risk of Hand Arm Vibration Injury.
This tool may cause Hand Arm Vibration Syndrome if its use is not managed adequately.
This tool is subject to the vibration testing section of the Machinery Directive 2006/42/EC.
This tool is to be operated in accordance with these instructions.
Measured vibration emission value (a): 4.7m/s²
Uncertainty value (k): 1.5m/s²
Please note that the application of the tool to a sole specialist task may produce a different average vibration emission. We recommend that a
specific evaluation of the vibration emission is conducted prior to commencing with a specialist task.
A health and safety assessment by the user (or employer) will need to be carried out to determine the suitable duration of use for each tool.
NB: Stated Vibration Emission values are type-test values and are intended to be typical.
Whilst in use, the actual value will vary considerably from and depend on many factors.
Such factors include; the operator, the task and the inserted tool or consumable.
NB: ensure that the length of leader hoses is sufficient to allow unrestricted use, as this also helps to reduce vibration.
The state of maintenance of the tool itself is also an important factor, a poorly maintained tool will also increase the risk of Hand Arm Vibration
Syndrome.
Health surveillance: We recommend a programme of health surveillance to detect early symptoms of vibration injury so that management
procedures can be modified accordingly.
Personal protective equipment: We are not aware of any personal protective equipment (PPE) that provides protection against vibration injury
that may result from the uncontrolled use of this tool. We recommend a sufficient supply of clothing (including gloves) to enable the operator to
remain warm and dry and maintain good blood circulation in fingers etc. Please note that the most effective protection is prevention, please refer
to the Correct Use and Maintenance section in these instructions. Guidance relating to the management of hand arm vibration can be found on the
HSC website: www.hse.gov.uk - Hand-Arm Vibration at Work
.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Original Language Version
© Jack Sealey Limited
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
CP108VCP Issue 1 13/01/21
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
Indice
Altri manuali Sealey Levigatrice
Sealey
Sealey DAS150T Manuale utente
Sealey
Sealey SA32.V2 Manuale utente
Sealey
Sealey SA77.V4 Manuale utente
Sealey
Sealey SM31.V3 Manuale utente
Sealey
Sealey MS900ps Manuale utente
Sealey
Sealey GSA07 Manuale utente
Sealey
Sealey SA70 Manuale utente
Sealey
Sealey SM914 Aggiornamento firmware
Sealey
Sealey DAS149 Manuale utente
Sealey
Sealey OS600 Manuale utente
Sealey
Sealey MS900PS Manuale utente
Sealey
Sealey DAS150T.V4 Manuale utente
Sealey
Sealey SA802.V2 Manuale utente
Sealey
Sealey SA10.V3 Manuale utente
Sealey
Sealey EDA150 Manuale utente
Sealey
Sealey SA77.V4 Manuale utente
Sealey
Sealey CP20VRPX Manuale utente
Sealey
Sealey SA355A Manuale utente
Sealey
Sealey RP1500 Manuale utente
Sealey
Sealey SA800.V5 Manuale utente
