INSTRUCTIONS FOR:
MOTORCYCLE SCISSOR STAND
Model: MC5905.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly
maintained, give you years of trouble free performance.
MC5905.V2 - 2 - 021107
1. SAFETY INSTRUCTIONS
2.1 Introduction
The MC5905 Motorcycle Scissor Stand is suitable for use either on a motorcycle lift or on the floor. The unit is supplied with sliding pin
carriers and three pairs of support pins. Raise by hand or with a 22mm socket.
2. INTRODUCTION & SPECIFICATION
!WARNING! Before use, ensure that the motorcycle to be supported has a suitable structure and centre of gravity to accommodate
the support pins without damaging the motorcycle. DO NOT use if the stand will foul on the exhaust or other vulnerable parts.
"Maintain the stand in good condition (use an authorised service agent).
"Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
"Use a qualified person to lubricate and maintain the stand.
"Locate the stand in a suitable work area. Keep area clean and tidy and free from unrelated materials and ensure that there is adequate
lighting. Also ensure that the floor is level and strong enough (preferably concrete) to take the weight of the stand and the bike. DO NOT
operate the stand on tarmacadam, as the surface may be unstable.
"Keep the stand clean for best and safest performance.
"The maximum bike weight is 300kgs. DO NOT exceed this rated capacity.
"Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and contain long hair.
"Maintain correct balance and footing, do not over reach. Ensure that the floor is not slippery and wear non-slip shoes.
"Ensure that the bike is adequately secured to the stand with appropriate straps.
"Before lifting check that there are no overhead obstructions.
"Keep children and unauthorised persons away from the work area.
#DO NOT use the stand for a task it is not designed to perform.
#DO NOT operate the stand if damaged.
#DO NOT exceed the rated capacity of the stand.
#DO NOT operate the stand when you are tired or under the influence of alcohol, drugs or intoxicating medication.
#DO NOT allow untrained persons to operate the stand.
#DO NOT make any modifications to the stand.
"Before lowering the stand ensure that there are no obstructions underneath the motorcycle and that all persons are standing clear.
"Before storing, ensure that all parts are clean and free of grease and oil and the stand is fully lowered. Store stand in a safe area.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
3. CONTENTS
3.1 Unpack the stand and check contents. If there are any damaged
or missing parts contact your supplier immediately.
1 x Scissor Stand 2 x Medium Support Pins
2 x Sliding Saddles 2 x Long Support Pins
2 x Short Support Pins
4. OPERATING INSTRUCTIONS
!WARNING! Ensure you read, understand and apply the safety instructions before use.
!WARNING! Before use, ensure that the motorcycle has a suitable structure and centre of gravity to accommodate the
stand support pins/frame cradle without damaging the bike.
DO NOT use the stand if it will foul on the exhaust or other vulnerable parts. If necessary remove any lower fairing and ensure
that the bike is stable on the stand before operating.
!WARNING! The stand is raised by turning the grip manually or with a 22mm socket and/or wrench - DO NOT use a power tool.
4.1 Position the bike in a suitable area, checking that the surface on which the stand will be placed is solid and flat (preferably concrete).
4.2 Ensure there is good access and clearance beneath the bike for the stand.
4.3 The stand can be also be used in conjunction with a motorcycle that is already raised on a motorcycle lift. Ensure that the stand is
fully located on the lift platform.
2.2 Specification
Model No: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .MC5905.V2
Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300kg
Low Support Pin Minimum Height . . . . . . . . . . . . . . . . . . . .180mm
Medium Support Pin Minimum Height . . . . . . . . . . . . . . . . .200mm
High Support Pin Minimum Height . . . . . . . . . . . . . . . . . . . 220mm
Lift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335mm
