SEI ADVISOR AE100 Manuale utente

ENCODER / DECODER / RECORDER

PROGRAMMING AND INSTALLATION

seinnovators.com

SEI ADVISOR WALL MOUNT

SEI ADVISOR DESKTOP

SEI RECORDER

PRODUCTS                                                                     4

PROGRAMMING   MAIN MENU                                      5

PROGRAM ENCODER                                                    6

PROGRAM DTMF                                                            7

PROGRAM DECODER                                                    8

PROGRAM STACKS                                                        9

VIEW/DELETE SLOTS                                                   10

DELAY ADD/DELETE                                                     11

DE-EMPHASIS ADD/DELETE                                        11

SOFTWARE VERSION                                                   12

CLEAR MEMORY                                                            12

CONFIGURE RELAYS FOR WAKEUP SEQUENCE      12

SET WAKEUP SEQUENCE TIMEOUT                           12

SETUP                                                                             13

PROGRAM ALERT RELAY                                             13

ADD ALIAS                                                                      14

EXIT PROGRAM                                                             14

SCHEMATIC                                                                   15

BOARD LAYOUT                                                            16

INSTALLATION                                                               18

SETUP AND PROGRAMMING                                        22

SCHEMATIC                                                                     30

BOARD LAYOUT                                                              31

INSTALLATION                                                                 33

ADVISOR ENCODER / DECODER
RECORDER

SYSTEM MODULE INTERCONNECTIONS

MIC AUDIO FOR RECORDER                                           35

ADVISOR ENCODER / DECODER WITH MIC                  36
AUDIO FROM MIC INTERCONNECT ADAPTOR

ADVISOR ENCODER / DECODER CONNECTED             37
TO ACCESSORY JACK

RECORDER CONNECTED TO ACCESSORY JACK         37

ADVISOR ENCODER / DECODER WITH RECORDER     38
CONNECTED TO ACCESSORY JACK

ADVISOR ENCODER / DECODER WITH RECEIVER        38
ALLOWS BASE STATION TO SCAN

ADVISOR ENCODER / DECODER WITH RECEIVER        39
AND RECORDER ALLOWS BASE STATION TO SCAN

RECORDER MOBILE INSTALLATION                                 39

ADVISOR WALL MOUNT RECEIVE ONLY                          40

ADVISOR WALL MOUNT RECEIVE ONLY                          40
WITH RECORDER

ADVISOR WALL MOUNT ENCODER / DECODER              41

ADVISOR WALL MOUNT ENCODER / DECODER              41
WITH RECORDER

ADVISOR WALL MOUNT ENCODER / DECODER              42
WITH RECEIVER ALLOWS BASE STATION TO SCAN

ADVISOR WALL MOUNT ENCODER / DECODER              42
WITH RECORDER AND RECEIVER ALLOWS
BASE STATION TO SCAN

ADVISOR DESKTOP EXTRA ENCODER / DECODER         43
WITH RECORDER

ADVISOR DESKTOP EXTRA ENCODER / DECODER         43
WITH RECEIVER ALLOWS BASE STATION TO SCAN

ADVISOR DESKTOP EXTRA ENCODER / DECODER         44
WITH RECORDER AND RECEIVER ALLOWS
BASE STATION TO SCAN

RECORDER WITH MIC AUDIO FROM MIC                           44
INTERCONNECT ADAPTOR

RECEIVER SCHEMATIC                                                        45

WARRANTY                                                                            46


*If the Recorder is slaved to the Advisor the Recorder will only record after the Advisor is tripped.

It is reset with the “*” on the Advisor key pad.

SEI

Advisor

Desktop

Extra

SEI Recorder

Station/Mobile

WIFI Connectivity

CLOUD Connectivity

SEI

Advisor

Wall Mount

SEI Receiver

SEI

Advisor

Desktop

ENCODING / DECODING / RECORDING

FOR PUBLIC SAFETY

TABLE OF CONTENTS

Hold for
    6 Sec. PROGRAM
ENCODER
PAGE 6
PROGRAM
DTMF
PAGE 7
PROGRAM
STACKS
PAGE 9
PROGRAM
DECODER
PAGE 8
DELAY
ADD/DEL
PAGE 11
VIEW/DEL
SLOTS
PAGE 10
CLEAR
MEMORY
PAGE 12
EXIT
PROGRAM
MODE
Programming is intuitive.  Just follow
the Screens.

Hold the “#” key for 6 seconds to En-
ter the Program Mode.

Use the “#” key to step through the
main options.

Use the “*” key to select the option.

“*” press WITH NO ENTRY, will return
to main Program Mode menu

To exit the Program Mode at any time
just hold the “#” key for 6 seconds.
Normal Screen
Displayed for 1.5 Sec.
SETUP
PAGE 13
DE-EMPHASIS
ADD/DEL
PAGE 11
PROGRAM
ALERT RELAY
PAGE 13
TABLE OF CONTENTS
CONFIGURE
 RELAYS
PAGE 12
NEW WUS
TIMEOUT
PAGE 12

ALERT TONE

ADDED

Displayed for 1.5 Seconds

ADD ALIAS

PAGE 14

Select Program Encoder from the Pro-

gram Mode by pressing “*”.

Enter the Slot number you want to Pro-

gram.

Slots 0—999.

Enter the First Tone in the Two Tone Se-

quence. Include the Digit after the Deci-

mal Point. (For 853.4 Enter 8534)

Enter the Second Tone in the Two Tone

Sequence. Include the Digit after the

Decimal Point.

(For 1764.5 Enter 17645)

Select “Alert Tone” for an Alert Tone to

follow the Page.

The Slot Number will be Displayed for

1.5 Sec.

Tone A and Tone B will be Displayed.

Press “#” to Program the Slot.

(“*” TO Start Again)

Press “*” to enter a

16 character Alias for the Slot.

(See Instructions on Page 25)

For Group Call make the A Tone and the

B Tone the Same.

It will now Return to “Program Encoder”

to Program another Slot if Needed.

For 853.4

Enter 8534

For 1764.5

Enter 17645

Example

1764.5

Example

853.4

Example

452

TABLE OF CONTENTS

Select Program DTMF from the Program

Mode by pressing “*”.

Enter the Slot number you want to Pro-

gram.

Enter the number of DTMF Tones You

want to Send. (Min 1, Max 8)

Enter “1” for Standard DTMF, Enter “2”

for Knox F1 DTMF.

Enter the DTMF Digits One at a Time.

0 = 0 1 = 1 2 = 2 3 = 3 4 = 4

5 = 5 6 = 6 7 = 7 8 = 8 9 = 9

10 = * 11 = # 12 = A 13 = B 14 = C

15 = D

The Tones are then Displayed with the

Type. Press “#” to Program the Slot.

Press “*” to enter a 16 character Alias for

the Slot. (See Instructions on Page 25)

It will now Return to “Program DTMF” to

Program another Slot if Needed.

Displayed for 1.5 Seconds

Enter 1 - 8 (Example 5)

Enter 1 or 2 (Example 1)

Enter Digits One at a Time

(Example 3, 5, 9, 2, 8)

All Digits

Are Entered

ADD ALIAS

PAGE 14

ENTER THE SLOT NO.

THAT HOLDS THE

DTMF SEQUENCE

Example

238

PRESS # TO

ACCEPT THE

ENTRY

TABLE OF CONTENTS

Displayed for 1.5 Sec.

Select Program Decoder from

the Program Mode by press-

ing “*”.

Enter the Slot number you

want to Program.

Slots 1—100.

Enter the First Tone in the

Two Tone Sequence. Include

the Digit after the Decimal

Point. (For 853.4 Enter 8534)

Enter the Second Tone in the

Two Tone Sequence. Include

the Digit after the Decimal

Point. (For 1764.5 Enter

17645)

The Slot number will be Dis-

played for 1.5 seconds.

Tone A and Tone B will be Dis-

played. Press “#” to Program

the Slot.

Add WAKE-UP Sequence Op-

tion and select 1, 2 or 3.

Deactivate Relay Option

(Not Available if WAKE-UP Se-

quence or Add Re-Page are

Selected)

It will now Return to

“Program Encoder” to

Program another Slot if Need-

ed.

Enter 1, 2 or 3

Example

853.4

Example

1764.5

For 853.4

Enter 8534

For 1764.5

Enter 17645

PRESS # TO

ACCEPT THE

ENTRY

TABLE OF CONTENTS

ADD ALIAS

PAGE 14

Displayed for 1.5 Sec.

Example

Slot 98

Step Through

all of the

Slots in the

Stack

Displays when End

of Stack is Reached

The Advisor will Accept up to 50

Stacks with up to 48 Slots in each

Stack.

Programming is Intuitive. Just fol-

low the Screens.

Enter the Slot number that will Hold

the Stack (Example 98)

Press # to Accept the Slot number

Enter the Slot number for Each Slot

in the Stack. (Maximum of 48 Slots)

Press “*” to enter a 16 character

Alias for the Slot. (See Instructions

on Page 25)

Press “#” to Review the Slots en-

tered into the Stack or Press “*” to

Finish.

Display the Slot number that Holds

the Stack.

Keep Pressing “#” to Step Through

each Slot in the Stack.

When the End of the Stack is

Reached you can choose to keep the

Stack or Delete it.

ENTER UP TO

48 SLOTS

NUMBERS

THIS IS THE SLOT THAT

WILL BE ENTERED TO

PAGE THE STACK

Displayed for

1.5 Sec.

TABLE OF CONTENTS

CODES: Tell What Decode Functions

are Programmed in the Slot

Enter a Slot

Number

Example 52

Displayed for 1.5 Seconds

ENTER

Enter a Slot

Number

Example 452

Displayed for 1.5 Seconds

If Slot is Two Tone If Slot is DTMF If Slot is a Stack

Displayed for 1.5 Seconds Displayed for 1.5 Seconds

Display Alias

Display DTMF

Digits

Display Alias

Step Through

all of the

Slots in the

Stack

YES

Return to

Program

Mode

Displayed for 1.5 Seconds

ENTER

KEEP

CODES

0 ALERT RELAY ONLY

2015 DEACTIVATE ALERT RELAY

20000 WAKE UP SEQUENCE 1

30000 WAKE UP SEQUENCE 2

40000 WAKE UP SEQUENCE 3

ALERT RELAY IS ACTIVE WITH WAKE UP SEQUENCE

KEEP

YES

Select from

Program Menu

TABLE OF CONTENTS
