Select ISAAC E9682 Manuale utente

EAN CODE: 5412025096824

Montage handleiding

Plan de montage

Assembly manual

Montageanleitung

ISAAC

E9682

2660

5300

2320

2460

3880

810

4180

8148

4008

ISAAC - E9682

R E F E R E N C E L E N G T H QTY.

C O N T E N T I M A G E

PO_ _ _ _ _ _ _ _ _ _ _ _ _ _

SAV

REF.

ISAAC - E9682|

A WW040x118-STPP-000-0-

B1 WW040x118-S1IF-000-0-

3880 3

600 36

Plank milled on 2 sides

Plank milled on 1 side, milled troughout length

Plank milled on 2 sides with extension

Plank milled on 2 sides, cut in half lengthwise

Profile plank

Roof beam

4 surfaces planed

E WW040x118-S2IF-000-0- 3880 60

F1 WW040x118-SAV2-IF1-0- 3517 2

G3 WW040x118-A69-000-0- 4780 21

I WW040x073-SDEM-000-0- 3880 3

J1 WW019x123-PRF-000-0- 4820 37

K1 WW040x145-PT1-000-0- 4030 12

K2 WW040x145-4FA-000-0- 236 13

K3 WW040x145-4FA-087-0- 236 4

M1 WW016x087-FEM-000-0- 4240 4

M2 WW016x095-PLA-000-0- 4240 8

M3 WW016x087-MAL-000-0- 4240 4

M4 WW016x087-FEM-000-0- 4220 2

M5 WW016x095-PLA-000-0- 4220 4

M6 WW016x087-MAL-000-0- 4220 2

Plank milled on 2 sides, milled troughout length F2 WW040x118-SAV2-IF2-0- 4930 2

Plank milled on 1 side G2 WW040x118-S1IF-000-0- 3368 21

Profile plank J2 WW019x123-PRF-000-0- 3627 37

C1 WW040x118-SB1F-000-0- 1900 1

C2 WW040x118-SB1H-000-0- 1900 1

D WW040x118-PRF-000-0- 550 17

Plank milled on 2 sides G1 WW040x118-S2IF-000-0- 4180 1

B2 WW040x118-S1IF-000-0- 250 20

Slope top

Plank milled on 1 side

Plank milled on 1 side, recess at the top

Plank milled on 1 side

Profile plank

Plank milled on 1 side, recess at the bottom

Cladding board female

Cladding board male

Cladding board

Cladding board female

Cladding board

Cladding board male

H WW040x055-4G4-RA40-0- 1

2320

List of parts / After sales service

Wall edge cover profile

R E F E R E N C E L E N G T H QTY.

C O N T E N T I M A G E

PO_ _ _ _ _ _ _ _ _ _ _ _ _ _

SAV

REF.

ISAAC - E9682|

Ground beam S 6

RW028x070-CS0-040-1- 6000

Window Q1

Finishing corners N1 WW016x072-2R8-000-0- 350 4

N2 WW016x072-2R8-000-0- 350 4Finishing corners

N2 WW016x072-4R8-000-0- 350 2

Finishing board

S6112 3.5 X 25

S625 5.0 X 70

S6113 3.5 X 17

S637 2.8 X 50

S626 4.0 X 45

Bag of screws 2

Bag of screws

Bag of nails

List of parts / After sales service

E9901 2

E9901-K40 1

S6744 2

S647 1

E9951 2

E9901-ALU 1

P6 1725

Door wing

Door Frame

Lock

Glass

ALU profile

Flush bolt

E9931-40

R E F E R E N C E L E N G T H QTY.

C O N T E N T I M A G E

PO_ _ _ _ _ _ _ _ _ _ _ _ _ _

SAV

REF.

ISAAC - E9682|

Gutter

Gutter board

8360 1

U1 WW016x095-4FA-000-0- 3980 1

V 1EPDM

W S660 9Bardage profil

Poutre de contour S 6RW028x070-CS0-040-1- 6000

Y S522 1Kit anti-tempete

S5016

Gutter board U2 WW016x095-4FA-000-0- 3995 1

ZVentilation kit S6746 1

List of parts / After sales service

T1 S5900

Pipe piece

Gutter hook

Spout

End piece Left and Right

Bend 67°

End bend 67°

S5901

S5902

S5904

S5905

S5906

S5907

Pipe bracket S5908

2000 1

Gutter connection S5909T10 1

LEFT / RIGHT

ALU L-profile left

ALU L-profile right

ALU L-profile center left

ALU L-profile center right

S6700 1

S6701 1

S6700 1

S6701 1

4255

4242

S = 6

ISAAC - E9682

45°

430 1732

3580

3886 3898

01.1

1604

B1 = 1

I = 3

G2 = 1

G3 = 1

B2 = 1

C1 = 1

ISAAC - E9682

B1 = 18

E = 27

G2 = 9

G3 = 9

B2 = 9

Q = 1

ISAAC - E9682

Advice:

Measure that the diagonals have the same length to ensure that the

walls are perpendicular to each other

D = 8

EG3

C2 = 1

G2 E

B2 = 10

G2 = 12

E = 33

G1 = 1

B1 = 17

G3 = 12

ISAAC - E9682

A = 3

F1 = 2

F2 = 2

A2 F1

F2 = 2

H = 1

ISAAC - E9682
