INSTALLATION AND OPERATING INSTRUCTIONS

LOWER CLUBHOUSE II – A24670E

for use with SELWOOD 1.2 METRE FORT II - A23837E

To reduce the risk of serious injury or death, you must read and follow these instructions. Keep and refer to

these instructions often and give them to any future owner of this play system. Manufacturer contact information

provided below.

RESIDENTIAL HOME USE ONLY. Not intended for public areas such as schools, churches, nurseries, day cares or parks.

WARNING

Slide sold separately

Warnings and Safe Play Instructions

CONTINUOUS ADULT SUPERVISION REQUIRED. Most serious injuries and deaths on playground equipment have occurred

while children were unsupervised! Our products are designed to meet mandatory and voluntary safety standards. Complying

with all warnings and recommendations in these instructions will reduce the risk of serious or fatal injury to children using

this play system. Go over the warnings and safe play instructions regularly with your children and make certain that they

understand and follow them. Remember on-site adult supervision is required for children of all ages.

Observe capacity limitations of your play-set. See

front cover.

Dress children with well ﬁtting and full foot enclosing

footwear.

Teach children to sit with their full weight in the center

of the swing seat to prevent erratic swing motion or

falling off.

Check for splintered, broken or cracked wood; missing,

loose, or sharp edged hardware. Replace, tighten and or

sand smooth as required prior to playing.

Verify that suspended climbing ropes, rope ladders, chain

or cable are secured at both ends and cannot be looped

back on itself as to create an entanglement hazard.

On sunny and or hot days, check the slide and other

plastic rides to assure that they are not very hot as to

cause burns. Cool hot slide and rides with water and wipe

dry prior to using.

Do not allow children to wear open toe or heel footwear

like sandals, ﬂip–ﬂops or clogs.

Do not allow children to walk, in front, between, behind

or close to moving rides.

Do not let children twist swing chains or ropes or loop

them over the top support bar. This may reduce the

strength of the chain or rope and cause premature failure.

Do not let children get off rides while they are in motion.

Do not permit climbing on equipment when it is wet.

Do not permit rough play or use of equipment in a

manner for which it was not intended. Standing on or

jumping from the roof, elevated platforms, swings,

climbers, ladders or slide can be dangerous.

Do not allow children to swing empty rides or seats.

Do not allow children to go down slide head ﬁrst or

run up slide.

WARNING

WARNING – Safe Play Instructions

SERIOUS HEAD INJURY HAZARD

Installation over concrete, asphalt, dirt, grass, carpet

and other hard surface creates a risk of serious injury

or death from falls to the ground. Install and maintain

shock absorbing material under and around play-set as

recommended on page 3 of these instructions.

COLLISION HAZARD

Place play-set on level ground at least 6 feet from any

obstruction such as a garage or house, fences, poles,

trees, sidewalks, walls, landscape timbers, rocks,

pavement, planters, garden borders, overhanging

branches, laundry lines, and electrical wires. (See

OBSTACLE FREE SAFETY ZONE on cover)

CHOKING HAZARD

Prior to assembly, this product contains small parts.

DO NOT allow children less than 5 years of age near or

around loose nuts, screws, washers, plastic bags and

other small parts.

STRANGULATION HAZARD

• NEVER allow children to play with ropes, clotheslines,

pet leashes, cables, chains or cord-like items when using

this play-set or to attach these items to play-set.

• NEVER allow children to wear loose ﬁtting clothing,

ponchos, hoods, scarves, capes, necklaces, items with

draw-strings, cords or ties when using this play-set.

• NEVER allow children to wear bike or sport helmets

when using this play-set.

Failure to prohibit these items, even helmets with chin

straps, increases the risk of serious injury and death to

children from entanglement and strangulation.

TIP OVER HAZARD

Choose a level location for the equipment. This can reduce

the likelihood of the play set tipping over and loose-ﬁll

surfacing materials washing away during heavy rains.

DO NOT allow children to play on the play-set until the

assembly is complete and the unit is properly anchored.

 2

 3

 4

Selwood Products Limited Warranty

Selwood Products states that the product is free from defect in materials and workmanship for a period of one (1) year from the original

date of purchase. This one (1) year warranty covers all parts including wood, hardware, and accessories. All wood carries a ten (10)

year warranty against rot and decay. Refer to the schedule associated with replacement of parts under this Warranty. In addition, the

manufacturer will replace any parts within the rst 60 days from date of purchase found to be missing from or damaged in the original

packaging. This warranty applies to the original owner and registrant and is non-transferable. Regular maintenance is required to

assure maximum life and performance of this product and failure by the owner to maintain the product according to the maintenance

requirements may void this warranty. Maintenance guidelines are provided in the Owner’s Manual provided by Selwood Products.

This Limited Warranty does not cover:

• Labour for any inspection or Labour for replacement of any defective item(s)

• Incidental or consequential damages

• Cosmetic defects which do not affect performance or integrity of a part or the entire product

• Vandalism, improper use, failure due to loading or use beyond the capacities stated in the Assembly Manual.

• Acts of nature including but not limited to wind, storms, hail, oods, excessive water exposure

• Improper installation including but not limited to installation on uneven, unlevel, or soft ground

• Minor twisting, warping, checking, splitting, or any other natural occurring properties of wood that do not affect

performance or integrity.

Selwood Products states that the product has been designed for safety and quality. Any modications made to the original product

could damage the structural integrity of the unit leading to failure and possible injury. Modication voids any and all warranties and

Selwood Products will accept no liability for any modied products or consequences resulting from failure of a modied product.

This product is warranted for RESIDENTIAL USE ONLY. Under no circumstance should the product be used in public settings

such as schools, churches, playgrounds, parks, daycares and the like. Such use may lead to product failure and potential injury. Any

and all public use will void this warranty.

Selwood disclaims all other representations and warranties of any kind, expressed or implied.

Warranty Part Replacement Schedule:

Plastic/Metal/Wood Components: 1 Year Warranty

0-60 days from date from purchase: Free Parts & Free Shipping | 61 days to 1 year from purchase: Free Parts + Shipping & Handling

Wooden (Wood Rot and Decay Only): 10 Year Warranty

0-60 days from date from purchase: Free Parts & Free Shipping | 61 days -10 years from purchase: Free Parts + Shipping & Handling

This Warranty gives you specic legal rights. You may have other rights as well which very from state to state or province to

province. This warranty excludes all consequential damages, however, some states do not allow the limitation or exclusion of

consequential damages, and therefore this limitation may not apply to you.

Complete the registration of your Selwood Product purchase online at: www.selwoodproducts.com/warranty-registration

Please refer to the back of this instruction manual for details on how to register your Selwood Products purchase.

At the factory we have added water repellent to the stain. This water repellent decreases the amount of water absorption during

rain or snow thus decreasing the tension in the wood. Sunlight will break down the water repellent, so we recommend applying a

water repellent on a yearly basis (see your local stain and paint supplier for a recommended product). Failure to do so can affect

warranty. Also if storing the product before installation, make sure you store out of direct sunlight in a cool dry place.

 5

Keys to Assembly Success

Part Identiﬁcation Key

On each page, you will ﬁnd the parts and

quantities required to complete the assembly

step illustrated on that page. Here is a sample.

Symbols

Throughout these instructions symbols are provided as important reminders for proper and safe assembly.

Proper Hardware Assembly

Lag screws require drilling pilot

holes to avoid splitting wood. Only

a ﬂat washer is required. For ease of

installation liquid soap can be used

on all lag-type screws.

For bolts, tap T-Nut into hole with

hammer. Insert the hex bolt through

lock washer ﬁrst then ﬂat washer then

hole. Because the assemblies need to

be squared do not completely tighten

until instructed. Pay close attention to

diameter of the bolts. 5/16” is slightly

larger than 1/4”.

Once the assembly is tightened, watch for exposed

threads. If a thread protrudes from the T-Nut, remove the

bolt and add washers to eliminate this condition. Extra

washers have been provided for this purpose.

This identiﬁes information that requires special

attention. Improper assembly could lead to an

unsafe or dangerous condition.

Where this is shown, 2 or 3

people are required to safely

complete the step. To avoid

injury or damage to the

assembly make sure to get help!

Check that assembly is square

before tightening bolts.

Use a measuring tape to assure

proper location.

Check that set or assembly is properly level

before proceeding.

Pre-drill a pilot hole before

fastening screw or lag to prevent

splitting of wood.

This indicates time to tighten bolts, but

not too tight! Do not crush the wood.

This may create splinters and cause

structural damage.

Use

Help

Use

Help

Measure

Distance

Square

Assembly

Use

Level

Pre-drill

1/8” Bit

Tighten

Bolts

No Yes

CAUTION – Protrusion Hazard

Tools Required

Shovel Level #2 & #3 Phillips

or Robertson

Safety

Glasses

Drill (1/8”

3/16” Bit)

Measuring

Tape

Hammer Ratchet 1/2”,

7/16” & 9/16”

Square

Ruler

Step

Ladder

12342X Post 2 x 4 x 83”

 6

1 inch = 25.4mm

SOLO)WAVE DESIGN HARDWARE

For example:

BOLT LENGTH 4½ (4.5) inches long

114mm long

1 inch = 25.4mm

25.4mm

4.5 inches x

DIAMETER CONVERSION

LENGTH CONVERSION

BOLT DIAMETER 5/16 (0.31) inches

0.31 inches x 25.4mm = 8mm

For example:

HARDWARE LENGTH CHART

inches vs millimetres

6 152

5½ 140

5 127

4½ 114

4 102

3½ 89

3 76

2½ 64

2 51

1½ 38

1¼ 32

1-1/8 29

1 25.4

7/8 22

3/4 19

1/2 12.7

1/4" (6mm) Flat Washer

1/4" (6mm)

Lock Washer

1/4"(0.25) = 6mm Hex Bolt

1/4" (6mm)

T-Nut

5/16"(.31) = 8mm Lag Screw

5/16" (8mm)

Flat Washer

1/4"(0.25) = 6mm Lag Screw

1/4" (6mm)

Flat Washer

5/16" (8mm)

Flat Washer

5/16" (8mm) Lock Washer

5/16"(.31) = 8mm Hex Bolt

5/16" (8mm)

T-Nut

3/8"(.38) = 9.5mm Lag Screw

3/8" (9.5mm)

Flat Washer

 7

1 x 2

1 x 4

1 x 5

1 x 6

1 x 3

1/2 x 4

5/4 x 6

5 1/2"

139.7

25.4

11.1

.44

82.6

3 1/4"

4 x 4

3 1/2"

88.9

3 1/2"

88.9

4 1/2"

114.3

5/8"

15.9

5/8" 1 3/8"

34.9

2 x 6

5 3/8"

136.5

1 1/2"

38.1

15.9

5/8" 3 3/8"

85.7

60.3

2 3/8"

15.9

5/8"

1505mm

SOLO)WAVE DESIGN WOOD PROFILES

LENGTH CONVERSION

For example:

1 inch = 25.4mm

BOARD LENGTH 59¼ (59.25) inches

59.25 inches x 25.4mm =

Dimensions in brackets

[mm] represent millimetres.

5/4 x 4

3 1/2"

88.9

25.4

5 3/8"

136.5

5/8"

15.9

2 x 4

3 3/8"

85.7

1 3/8"

34.9

5/4 x 5

4 1/2"

114.3

25.4 2 x 3

2 1/2"

63.5

1 3/8"

34.9

5/4 x 3

63.5

2 1/2"

25.4

x 2

1 1/2"

38.1

1 1/2"

38.1

 8

(4)

1/4" Flat Washer

(9251200)

Part Identification (Reduced Part Size)

Part Identification (Actual Size)

(4) Pan Screw #12 x 1" (9264610)

(2) Long Wall Support 1 x 5 x 46 -1/4" 3641812 Box 1

A11

(110) Truss Screw #8 x 7/8" (9229505)

(5) Flat Head Screw #8 x 1 3/4" (9260513)

S15

S13

(2) Pan Screw #6 x 5/8" (9264990)

(46) Flat Head Screw #8 x 1 1/2" (9260512)

(1) Stool Seat Set (2 Green Steel Supports

2 Yellow Seats w. steel brace) 3320190 Box 1

(9) Pan Screw #12 x 2" (9264620)

(1) Flower Box Set Green

3320401 Box 1

(5) Cedar Siding 3/8 x 3-1/2 x 46 -5/8" 3631801 Box 1

(2) CE Siding 3/8 x 1-1/4 x 17 -7/8" 3631803 Box 1

(46) Flat Head Screw #8 x 1 1/8" (9290514)

(1) Table Top 5/4 x 3 x 45 -1/4" 3632012 Box 1

A17

1" x 3½"

1" x 2½"

1" x 1½"

(2) Window Trim 1 x 4 x 11 -1/8" 3641810 Box 1

A13

A18

Actual Size

⅝" x 1⅜"

⅝" x 4½"

1⅜" x 3⅜"

1½" x 5⅜"

5/4" x 4"

(12) CE Siding 3/8 x 3-1/2 x 36 -3/4" 3631802 Box 1 1" x 5"

5/4" x 3"

5/4" x 2"

1" x 2"

(6) CE Siding 3/8 x 3 -1/2 x 17 -7/8" 3631804 Box 1

(12) CE Siding 3/8 x 3 -1/2 x 25 -1/2" 3631800 Box 1

(1) Wall Top 5/4 x 4 x 46 -5/8" 3641817 Box 1

(2) Long Trim 1 x 2 x 38 -3/4" 3641816 Box 1

(2) Window Bottom 1 x 4 x 37 -3/4" 3641815 Box 1

(2) Wall Support 1 x 4 x 45 -1/2" 3641814 Box 1

(2) Short Wall Support 1 x 4 x 24 -1/4" 3641813 Box 1

A10

(2) Window Top 1 x 5 x 37 -3/4" 3641811 Box 1

A12

(2) Door Trim 1 x 2 x 36 -1/2" 3641809 Box 1

A14

(1) Door Top 1 x 4 x 21" 3641806 Box 1

(2) Top Trim 1 x 2 x 39 -1/8" 3641807 Box 1

A16

(2) Short Trim 1 x 2 x 19 -5/8" 3641808 Box 1

A15

Nominal Size

2" x 6"

2" x 4"

A19

(1) Table Support 5/4 x 2 x 44" 3642013 Box 1

 9

PRODUCT NUMBER:

CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 1)

CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 2)

CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 3)

CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 4)

CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 5)

CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 6)

If you have missing, damaged or require replacement parts DO NOT contact your

retailer. Please visit www.selwoodproducts.com and select the Parts Centre.

You can then complete a quick online order form or make direct contact with the

Selwood Products Part Team.

www.selwoodproducts.com

A24670E

 10

Questo manuale è adatto per i seguenti modelli

Indice

Manuali Altalena popolari di altre marche

Ledon

Ledon 1185 Manuale utente

Backyard

Backyard LITTLE BRUTUS 2051171 Manuale per l'uso e la cura

Component Playgrounds

Component Playgrounds CP-PS24-8x10 Manuale utente

Kettler

Kettler 0S01053-0000 Manuale utente

Lemeks

Lemeks Palmako MV70-3121-4 Manuale dell'installatore

Lifetime

Lifetime 90143 Manuale utente

Belleze

Belleze 014-HG-14340 Manuale utente

Elvox

Elvox RS07 Manuale utente

gartenpirat

gartenpirat Premium 4.2 GP1305 Manuale utente

Taizhou Taiyan Swing

Taizhou Taiyan Swing 805-447 Manuale utente

KidKraft

KidKraft LAUREL F29715 Manuale utente

Plum

Plum Roloway Manuale utente

Component Playgrounds

Component Playgrounds AF30 Manuale utente

OOGarden

OOGarden FOSSA Manuale utente

Lakeland Mills

Lakeland Mills CF1128 Manuale utente

Backyard Discovery

Backyard Discovery MONTPELIER 30211F Manuale utente

LifeSpan Kids

LifeSpan Kids AMBER PE83 Manuale utente

SPORTSPOWER

SPORTSPOWER MSC- 4132 Istruzioni per l'installazione
