• Sturdy metal housing

• PC-supported frequency management for transmitter and receiver

• Tunable UHF frequencies within a large switching bandwidth

• Bodypack transmitter with programmable MUTE function, external activation as an option

• Headset microphone with optimized acoustics

• NEW: Ethernet port for connecting to the Wireless Systems Manager (WSM) software for control via computer –

this delivers a good overview of monitoring and professional data management for multi-channel systems

• NEW: Wireless synchronization of transmitters via infrared interface

• NEW: Enhanced frequency bank with up to 24 compatible frequencies

• NEW: 42 MHz bandwidth  1680 switchable frequencies

• NEW: Increased range for audio sensitivity

• NEW: Large, illuminated dot matrix display with warning indicator

• NEW: More control options (menu)

• NEW: Enhanced AF frequency range

• NEW: Soundcheck mode

• NEW: Integrated equalizer

• NEW: Switchable RF output power

• 2 AA batteries for more than 8 hours of use

• 4-level charge indicator for transmitter battery

• Contacts for recharging the BA 2015 accupack directly in the transmitter

• HDX compander for crystal-clear sound

• True diversity receiver for optimum reception

• Incl. installation kit for 19” rack mounting (1 U)

The evolution wireless G3 headset is the ideal

solution for capturing rousing stage situations

with grand gestures. As a performer you have

the entire breadth of the stage at your disposal –

and even your hands are free, giving you greater

scope to speak, dance and act. The headset can

be worn inconspicuously, the bodypack trans-

mitter can be practically invisibly attached to

garments and theconnecting wire from the

headset to the transmitter can be concealed

under the clothing. The headset shows the full

extent of its professionalism in complex live

situations: A special frequency response renders

the microphone insensitive to ambient stage

noise and popping sounds, allowing even those

sitting in the back rows to experience a clean,

powerful sound.

You Know

You CanPresentation Set

300 Series

Presentation

Set

• Sturdy metal housing (transmitter & receiver)

• PC-supported frequency management for transmitter and receiver

• Tunable UHF frequencies within a large switching bandwidth

• Bodypack transmitter with programmable MUTE function, external activation as an option

Technical Data

ew 300 g

Modulation wideband FM

Frequency ranges 516-558, 566-608, 626-668, 734-776, 780-822, 823-865

Transmission/Receiving frequencies 20 channel banks, 6 xed banks, 24 factory preset channels each

Switching bandwidth 42 MHz

Noise reduction system Sennheiser HDX

AF frequency response 25 – 18.000 Hz

S/N ratio (at 1mV and peak deviation) ≥ 115 dBA

THD (at nominal deviation and 1 kHz) ≤ 0,9 %

EM 300 g

SK 300 g

Receiver principle True Diversity

Sensitivity (with HDX, peak deviation) <2 µV at 52 dBAeff S/N

Adjacent channel rejection ≥ 75 dB

Intermodulation attenuation ≥ 70 dB

Blocking ≥ 75 dB

Pilot-tone squelch detachable

Antenna inputs 4 BNC sockets

AF output voltage (at peak deviation, 1kHz AF) ¼" (6.3 mm) jack socket, unbalanced: +12 dBu XLR socket,

balanced: +18 dBu

Power supply 12 V DC

Dimensions 202 x 212 x 43 mm (7.95" x 8.35" x 1.69")

Weight approx. 980 g (2.16 lbs)

RF output power at 50 O typ. 30/10mW, switchable

AF frequency response 25 – 18.000 Hz (Line)

80 – 18.000 Hz (Mic)

Max input voltage transmitter / line 3 Veff

Input impedance transmitter / line 40 kO, unbalanced / 1MO

Power supply 2 AA batteries, 1.5 V

Nominal voltage 2.4 V

Operating time typ. 8h

Dimensions 82 x 64 x 24 mm / 3.23" x 2.52" x 0.94"

Weight approx. 160 g (5.64 oz)

Presentation Set with

ME 2 clip-on microphone

Presentation Set with

ME 4 clip-on microphone

ME 2 ME 4

Transducer principle condenser

Sensitivity 20 mV/Pa

Pick-up pattern omni-directional

Max. SPL 130 dB SPL

Transducer principle condenser

Sensitivity 40 mV/Pa

Pick-up pattern cardioid

Max. SPL 120 dB SPL

Delivery includes

• EM 300 g rack-mount receiver

• SK 300 g bodypack transmitter

• GA 3 rackmount adapter

• ME 2/ME 4 clip-on microphone

For recommended accessories please visit www.sennheiser.com

ew 312 gew 322 g
