Sennheiser TeamConnect Ceiling Mic M Guida utente

Sennheiser electronic GmbH & Co. KG

Am Labor 1, 30900 Wedemark, Germany

www.sennheiser.com

Printed in Germany, Publ. 04/23, 597211/A02

TeamConnect

Ceiling Mic M

TCC M

Mounting instruction

Montageanleitung

Notice de montage

Istruzioni di montaggio

Instrucciones de montaje

Instruções de montagem

Montagehandleiding

Instrukcja montażu

Monteringsanvisning

Monteringsvejledning

Asennusohje

Οδηγίες συναρμολόγησης

Montaj kılavuzu

Инструкция по монтажу

安装指南

組立説明書

조립 지침

Sennheiser Documentation App

or online at

www.sennheiser.com/download

TCCM_

Flush MountedInterfaces

Swappable logo plateMicrophone alignment

ø 390 mm

ANALOGOUTPOE OUT STAT.RESE T POE IN/CTRL

POE

*push*

ANALOGOUTPOE OUT STAT.RESET POE IN/C TRL

POE

*unfold* *push*

Align with camera control.

Check 0˚ mark before fastening!

4. Pull ropes to tension.

1. Attach safety ropes.

ø 15.35"

1Analog OUT

3Daisy Chain Status

5Reset

2PoE Out / Dante II

4PoE Staus

1 2

4 5 6

6PoE IN / CTRL /

Dante I

hard ceiling

suspended

ceiling

0˚

Use drilling template Art. no. 594561!

Use drilling template

Art. no. 594561!

Lefthand drive!

ANALOGOUTPOE OUT STAT.RESE T POE IN/CTRL

POE

optional

cover

Attach safety rope and suspension ropes!

Follow mounting steps in chapter “Suspended”.

Attach pipe clamps if

needed (not included). 5. Fasten microphone.

Analog OUT

Reset

PoE IN/CtrlPoE OUT

Plug and eyebolt

are not included.

2. Connect cable(s).

Cut o

overhanging rope!

1. 2.

3. Lift microphone up towards ceiling.

Check Quick Guide Art. no.

592867 for scope of delivery!

Safety

Guide

Surface Mounted

Suspended

VESA Mounted

ANALOGOUT POE OUT STAT.RESET POE IN/CTRL

POE

*push*

*use cable conduit

(not included)

15x

Use drilling template

Art. no. 594561!

or:

Use drilling template

Art. no. 594561!

or:

VESA Standard MIS D

Bushing M4 x 0.7 x 10 mm

Use distance holder (not included) in

combination with cable ducts.

15x

or: Lefthand drive!

Lefthand drive!

Cut o

overhanging rope!

ANALOGOUT POE OUT STAT.RESET POE IN/CTRL

POE

1. 2.

4. Pull rope to tension.

1. Attach safety rope.

5. Fasten microphone.

2. Connect cable(s).

3. Lift microphone up towards ceiling.
