825 S

The 825 S is a general purpose microphone ideal for

vocal and instrument miking and club PA. The balanced

frequency response produces a warm, smooth sound.

The cardioid pick-up pattern provides e

xcellent feedback

and spillage rejection

. The rugged metal construction and

internal damping isolates handling noise.

The 825 S features a silent

ON/OFF switch

Features

yRugged metal body

yExcellent feedback and spillage rejection

yGood suppression of handling noise

yBalanced frequency response

yWarm transparent tonal response

ySilent ON/OFF switch

e 825s_511654_0706_Sp6.book Seite 1 Dienstag, 25. Juli 2006 5:11 17

Delivery includes

y825 S microphone

yMZQ 800 microphone clamp

yPouch

yInstructions for use

yWarranty Certificate

ON/OFF switch

Use the screw to lock the switch in the ON position. With

the switch set in the ON position, gently turn the screw

head 90° to lock the switch in position.

Removing the sound inlet basket

e 825s_511654_0706_Sp6.book Seite 2 Dienstag, 25. Juli 2006 5:11 17

Positioning the microphone

If sibilance or „popping“ occurs, position the microphone

not directly in front of the mouth but slightly to the side.

In order to prevent feedback, position monitor

loudspeakers so that they are located in the angle area of

the highest cancellation of the microphone.

In order to prevent interference due to crosstalk between

adjacent sound sources, try to position the microphone so

that the interfering sound source is located in the angle

area of the highest cancellation of the microphone

(approx. 180°; see polar diagram).

Position Resulting sound Commentary

High proximity effect

(much bass/

fundamental)

powerful, direct sound

Very little crosstalk

from other sound

sources

Less proximity effect

(less bass/

fundamental)

Some room ambience,

natural, balanced sound

More crosstalk from

other sound sources

Very little proximity

effect (little bass/

fundamental)

More room ambience,

indirect sound

Much crosstalk from

other sound sources

e 825s_511654_0706_Sp6.book Seite 3 Dienstag, 25. Juli 2006 5:11 17

Polar diagram

Frequency response curve

000

8000

6000

500

000

- 7

500

000

5000

0000

- 4

e 825s_511654_0706_Sp6.book Seite 4 Dienstag, 25. Juli 2006 5:11 17

Specifications

Transducer principle dynamic

Frequency response 80.....15,000 Hz

Pick-up pattern cardioid

Sensitivity

(free field, no load at 1 kHz) 1.5 mV/Pa

Nominal impedance 350 Ω

Min. terminating impedance 1 kΩ

Connector XLR-3

Operating temperature 0°C to +40°C

Weight 330 g

Dimensions Ø 48 x L 180 mm

Pin assignment of XLR-3 connector

XLR 6,3 mm

XLR

6,3 mm

symmetrisch

XLR

balanced

e 825s_511654_0706_Sp6.book Seite 5 Dienstag, 25. Juli 2006 5:11 17

Overview of microphone applications

Variant

Application

e602-II

e604

e606

e608

e614

e815

e825

e835

e840

e845

e865

Vocals xxxxxx

Choirs x

Studio,

acoustic instruments

Orchestra x

Brass / Saxophone xx x

Acoustic guitar x

Acoustic bass x

Guitar amplifiers x

Bass amplifiers x

Leslie xxx

Piano, grand piano x

Kick drums x

Snare drums xxx

Rack toms xxx

Floor toms xxx

Congas xxx

Cymbals x

Percussion xxxx

Overheads x

e 825s_511654_0706_Sp6.book Seite 6 Dienstag, 25. Juli 2006 5:11 17

Manufacturer declarations

Warranty

2 years

Approval

Sennheiser electronic GmbH & Co. KG declare that

this device is in compliance with the applicable CE

standards and regulations.

Before putting the device into operation, please observe the respec-

tive country-specific regulations!

WEEE Declaration

Please dispose of this product at the end of its operati-

onal lifetime by bringing it to your local collection point

or recycling centre for such equipment.

e 825s_511654_0706_Sp6.book Seite 7 Dienstag, 25. Juli 2006 5:11 17

Sennheiser electronic GmbH & Co. KG

30900 Wedemark, Germany

Phone +49 (5130) 600 0

Fax +49 (5130) 600 300

www.sennheiser.com

Printed in Germany Publ. 07/06 511654/A02
