Sennheiser ME 67 Manuale di istruzioni

Cat. No. 003285

ME 67

Microphones | Back-Electret Microphone Head Suitable

for K6 and K6P Powering Modules

General Description

The ME 67 is a long gun microphone head designed for use with the K6

and K6P powering modules. A highly directional microphone, it can be

used where the microphone must be placed at a distance from the sound

source. Matt black, anodised, scratch-resistant finish.

Features

j

Lobar pick-up pattern

j

Highly directional

j

Very low inherent self-noise

j

High sensitivity factor

j

Wide frequency response

j

Delivery includes: 1 ME 67

Recommended Accessories

j

MZW 67 pro foam windshield Cat. No. 003832

Profile

Lobar (long gun) microphone head suitable for K6 and K6P

powering modules. Frequency response 50 Hz – 20,000 Hz

± 2.5 dB, sensitivity (free field, no load) 50 mV/Pa ± 2.5 dB

at 1 kHz, nominal impedance 200 Ω(with K6), min. termi-

nating impedance 1 kΩ(with K6), equivalent noise level

A-weighted 10 dB, CCIR-weighted 21 dB, max. SPL 126 dB

at 1 kHz (THD = 1 %), dimensions Ø 22.5 x 343 mm, weight

100 g.

Technical Data

Pick-up pattern ....................................................... lobar (long gun)

Frequency response .................................40 – 20,000 Hz ± 2.5 dB

Sensitivity

(free field, no load) (1 kHz) ............................ 50 mV/Pa ± 2.5 dB

Nominal impedance ............................................... 200 Ω(with K6)

Min. terminating impedance...................................1 kΩ(with K6)

Equivalent noise level

A-weighted (DIN IEC 651)........................................................ 10 dB

CCIR-weighted (CCIR 468-3).................................................... 21 dB

Max. SPL (1 kHz)...............................................126 dB (THD = 1 %)

Dimensions .............................................................Ø 22.5 x 343 mm

Weight ......................................................................................... 100 g

Pictured with K6 powering module and cable (available separately)
