MOUNTING INSTRUCTIONS IN STEPS
Before you start mounting the GTEE1, read carefully “Safety and Precautions”and
follow these steps. Choose a smooth solid surface for installation (a wall, panel, etc.).
Follow these steps:
1. Drill holes into the surface and secure the fastenings (hooks, wall plugs, etc.)
into them. Mind the correct mounting position and unit mounting dimensions
(see Fig. 1 Mounting dimensions and Fig. 2 Mounting position).
2. Pay attention to the following instructions in order to minimize the operating
temperature:
2.1 Respect the distances both between the wall / ceiling and the device and
between two devices as shown in Fig. 2. In order to ensure sufficient
ventilation of the controller, clearance on every side has to be maintained.
2.2 When installing the device, please keep in mind that the higher you install it,
the warmer the device will get. For example, in a technical room the correct
installation height can be of great importance.
2.3 If maximum ambient temperature cannot be adhered to, please provide
extra forced ventilation / cooling.
2.4 Leave sufficient space around the unit (for load connecting to the sockets).
Allow at least 90—100 mm for connection maintenance (to insert plug/plugs
into the sockets).
Not respecting the abovelisted rules can reduce service life and relieves the
manufacturer of any responsibilities.
ATTENTION Do not install the controller above heating equipment.
Fig. 1 Mounting dimensions Fig. 2 Mounting position
135
310
198
Correct Incorrect
90 mm
90 mm
90 mm
4
5
3. Fix the unit onto the wall /panel.
ATTENTION A safety isolator / disconnect switch should be installed on the mains electricity
side of all motor drives.
NOTE e Schuko sockets are intended only for connecting a supply fan, an extraction
fan and a heater as indicated on the device. Do not plug other types of electric
appliances into them!
