AsteRx-i3 D OEM & AsteRx-i3 S OEM

2AsteRx-i3 D OEM & AsteRx-i3 S OEM

2.1 AsteRx-i3 D OEM

All dimensions in millimeters.

Weight = 29 g

AUX1

MAIN

REF OUT

AsteRx-i3 D OEM & AsteRx-i3 S OEM

2.2 AsteRx-i3 S OEM

The AsteRx-i3 S OEM board has the same dimensions and connectors as the AsteRx-i3 D

OEM board, but it does not incorporate the ADIS IMU. It is designed to operate with an

external SBG Ellipse IMU (see chapter 3).

All dimensions in millimeters.

Weight = 27 g

Note: the above pictures and mechanical diagrams show both u.FL and MMCX antenna

connectors. In reality, only one type of connector is available depending on the board

variant.

AUX1

MAIN

REF OUT

AsteRx-i3 D OEM & AsteRx-i3 S OEM

2.3 Mounting

RF connectors (u.FL or MMCX type) are mounted on top side of the PCB. The 30- and 60-

pin Hirose I/O connectors are mounted on the bottom side.

The four mounting holes are compatible with M3 screws. Use M3 3.5mm spacers. An

example of applicable SMD spacer is THF-1.6-3.5-M3 from MAC8.

All mounting holes are grounded, and should preferably be connected to ground on the

host PCB. Note however that the mounting holes should not be relied on as only ground

return connection: a proper ground should be supplied to the GND pins of the I/O

connector(s) as well.

The maximum height of the components at the bottom side of the AsteRx-i3 OEM board

is within the mask shown below (applicable to both AsteRx-i3 D OEM and AsteRx-i3 S

OEM). The maximum component height is 1.1mm in the green area and 1.6mm in the

yellow area.

2.4 Environmental

Operational:

AsteRx-i3 D OEM : -40 to +85 °C

AsteRx-i3 S OEM + Ellipse2 : -20 to +85 °C

Storage: -55 to +85 °C

AsteRx-i3 D OEM & AsteRx-i3 S OEM

2.5 Power and Power Consumption

The board is powered through pin#1 and pin#2 of the 30-pin connector. Power supply

voltage must be 3.3V +/-5%.

The power consumption depends on the set of GNSS signals enabled with the

setSignalTracking command.

The following table shows the typical power consumption for selected sets of signals. The

dual antenna configuration corresponds to a receiver where the option to track from the

AUX1 antenna is enabled.

AsteRx-i3 D OEM:

Signals enabled with setSignalTracking

Power consumption

Dual antenna

Single antenna

GPS L1+L2, GLO L1+L2

1.35 W

1.00 W

All GNSS signals from all GNSS constellations

1.80 W

1.20 W

AsteRx-i3 S OEM excluding SBG IMU (add 400mW to include it):

Signals enabled with setSignalTracking

Power consumption

Dual antenna

Single antenna

GPS L1+L2, GLO L1+L2

1.15 W

0.80 W

All GNSS signals from all GNSS constellations

1.60 W

1.00 W

Enabling the built-in L-Band demodulator with the setLBandSelectMode command adds

100 mW.

Enabling wideband interference mitigation with the setWBIMitigation command adds

160 mW (dual antenna) or 80mW (single antenna).

Consumption in standby mode: 3 mW

Note that the power consumption in the above table are average values. To account for

peak currents, the minimum power supply drive capability should be 1 Ampere.

2.6 RF Interface

For illustration purposes, the above picture shows both u.FL and MMCX connectors. In

reality, only one type of connector is available depending on the board variant.

AUX1

MAIN

AsteRx-i3 D OEM & AsteRx-i3 S OEM

The main antenna must be connected to the u.FL or MMCX connector marked “MAIN” on

the PCB and the auxiliary antenna must be connected to the AUX1 connector.

2.6.1 Electrical Specifications

Antenna supply voltage

3-5.5V DC, set via pin#18 of the 30-pin connector. The same

voltage is applied to both antennas. If pin#18 is not

connected, there is no DC voltage to the antennas.

DC series impedance

2.7 Ohms

Antenna current limit

150 mA per antenna

Antenna net gain range1

15-50 dB

For optimal performances, the net gain on MAIN and AUX1

must not differ by more than 10dB.

Receiver noise figure

10 dB (with 15-dB net gain)

The receiver noise figure increases as the net gain increases,

but its contribution to the system noise figure decreases.

The worse case is for a net gain of 15dB.

RF nominal input impedance

50 Ohms

VSWR

< 2.5:1 in 1200-1251 MHz and 1560-1610 MHz range

1 The net gain is the total pre-amplification of the distribution network in front of the receiver. Typically, this

equals antenna active LNA gain minus coax losses in the applicable GNSS bands.
