Serato Numark Manuale utente
1
Quick-Start Guide
NumarkNumark
Party Mix LiveParty Mix Live
2
Setup
Serato Software
The Numark Party Mix Live is a “Serato DJ Lite hardware unlocked” device, meaning it works with Serato
DJ Lite out of the box.
It is also a “paid upgrade to Serato DJ Pro device”, meaning it requires the purchase & activation of a Serato
DJ Pro license, in order to be used with Serato DJ Pro.
You can also trial Serato DJ Pro, for up to 14-days.
Click here to nd out more about buying or activating Serato DJ Pro
Please ensure you have the latest version of Serato DJ Lite installed:
Click here to download Serato DJ Lite
Driver Software
The Numark Party Mix Live does not require manufacturer specic drivers on macOS operating systems,
however they are required on Windows, and can be found in the link below:
Numark Support
Install any relevant drivers, then connect the device to your computer, and launch the latest version of
Serato DJ Lite.
3
#PARTY MIX LIVE CONTROL FUNCTION
1HEADPHONE Adjust headphone output level
2BROWSE Library Scroll. Press to toggle between track and crate selection
3 LIGHTS / SPEAKERS Built-in lights & speakers
4LOAD 1 / 2 Load highlighted track to respective deck. Double press to Instant Double
5 EQ / GAIN Adjust channel EQ (treble & bass) and channel gain (level)
6 FILTER Low & High pass combo lter (per channel)
7JOG WHEEL Control waveform within Serato DJ in vinyl mode, or pitch bend
8 PARTY BALL LIGHTS SEE LIGHTS FOR MORE INFORMATION
9POWER Connect AC adapter to power device
10 ON / OFF Toggle to turn device on
11 TEMPO SLIDER Adjust tempo/pitch
12 PLAY / PAUSE Toggles Play/Pause on selected deck
13 PERFORMANCE PADS SEE PERFORMANCE PADS FOR MORE INFORMATION
14 CHANNEL FADER Adjust channel volume
15 CROSSFADER Crossfade audio between channel 1-2
16 MAIN Adjust Master output level
17 CHANNEL CUE Press to cue channel for monitoring in headphones
18 CUE Cues from temp cue point/Set temp cue point
19 SYNC Press to turn SYNC on. Hold the PAD MODE button while pressing to turn SYNC o.
20 SPEAKERS ON / OFF Toggle built-in speakers
21 HEADPHONE OUT Output to headphones (3.5mm or 1/8”)
22 MAIN OUT Connect 3.5mm or 1/8” output to speakers
23 USB Connect USB data cable to PC
Overview
1 2 3 4 5 6
14 12131516171819
22
23
21
20
7
10
11
9
8
4
Performance Pads
The Numark Party Mix Live comes with 4 performance pads, that can be used across 4 dierent
performance pad modes.
Repeatedly pressing the PAD MODE button will cycle through the available pad modes, lighting up that pad
modes respective LED to indicate a selection.
These consist of:
CUE mode: Pads 1-4 trigger Serato DJ Lite Cue points, and if no Cue point is present on that slot/pad,
pressing that pad will set a Cue point.
LOOP mode: Pads 1-4 trigger triggers an autoloop of variable sizes. Use the loop selection area in the
Serato DJ Lite user interface, to inuence the 4 available autoloop sizes.
SAMPLER mode: Press pads 1-4 to trigger samples loaded into the Serato DJ Lite Sampler.
EFFECT mode: Press pads 1-4 to trigger FX via multi & single FX modes.
DJ-FX
The DJ-FX in Serato DJ Lite are powered by iZotope™. Click the FX button to open the FX panel.
Serato DJ Lite’s Multi FX Mode allows you to select up to three eects per FX bank, and adjust one
parameter, the FX Depth.
Party Mix Live Control Multi FX mode
PAD 1 Hold & release for Slot 1 Eect
On/O
PAD 2 Hold & release for Slot 2 Eect
On/O
PAD 3 Hold & release for Slot 3 Eect
On/O
PAD 4 Cycle Beats multiplier
5
Show Tooltips
Click on the button in the upper right-hand corner of Serato DJ Lite, then to enable
tooltips. Tool tips provide a handy way to learn the various features of Serato DJ Lite.
Move the mouse over a section of the screen to bring up a context sensitive tool tip.
Watch Tutorials
Click on the button in the upper right-hand corner of Serato DJ Lite, then to launch
your default internet browser and watch tutorials, to help you get familiar with Serato DJ Lite.
Get Support
Click on the button in the upper right-hand corner of Serato DJ Lite, then to launch your
default internet browser and navigate to the Serato DJ Lite knowledge base, where you can nd helpful
articles and guides on Serato DJ Lite. Alternatively, type in the box, with keywords, to
search the Serato DJ Lite knowledge base for specic, related topics.
Help
The Numark Party Mix Live comes equipped with Party Ball lights that are reactive to Serato software.
Press the button on the left side of the unit repeatedly, to cycle through the Party Ball modes.
In compatible modes, lights respond to the RGB setting from Serato software, and 3 further Programs can
be selected via Setup --> Mixer --> Lighting Control (see image below)
Program 1 turns the RGB lights on and o in a sequential order, based on the beat played.
Program 2 ashes the RGB lights rapidly in a squential order, based on the beat played.
Program 3 illuminates all 3 RGB lights at the same time, but their intensity is determined by the Master output level.
Lights
