Seville Classics WEB178 Manuale utente

Step 6:

On the narrow side, fasten 4 pairs of slip

sleeves at the desired height of 4 poles.

Slide a small shelf over the top of 4 poles

until it rests snugly over the sleeves.

Fasten 6 pairs of slip sleeves at the very

top of 6 poles. Slide a large shelf over the

top of 6 poles until it rests snugly over the

sleeves.

Step 7:

Secure Hooks (G) on the top large shelf

and the medium shelf. Install Hanging

Rods (H) using Screws (I).

Step 8:

Put the Fabric Cover (L) on the unit. At 4

bottom corners, fasten Velcro to the poles

underneath the bottom shelf.

Note: The fabric cover is slightly longer

than the unit to keep dust out.

Overall weight capacity on wheels: 54.4 kg

Overall weight capacity on feet: 170.1 kg

Weight capacity per large shelf (E): 34 kg

Weight capacity per small shelf (F): 18.1 kg

Customer Service Informaon

Telephone: (800) 323-5565

Fax: (310) 533-3899

Hours: 8:30 AM – 4:30 PM (PST)

Email: Support@SevilleClassics.com

Homepage: www.SevilleClassics.com

Garment Rack with Cover

46.7in W x 18in D x 75.5in H /

118.7cm W x 45.7cm D x 191.7cm H

Model #: WEB178 / ITM: 747698

Thank you for choosing Seville Classics! We hope that you enjoy your

closet organizer! Please read through this guide for parts list, assembly

instructions, frequently asked questions and further contact

information.in

Please make sure you have all the parts before assembly

A 6 pcs B 6 pcs C 24 pairs D 2 pcs

Top Poles Bottom Poles Slip Sleeves Large Shelves

Plastic cap (top)

Threaded end (bottom)

E 1 pc F 2 pcs G 4 pcs H 2 pcs

Medium Shelf Small Shelves Hooks Hanging Rods

I 4 pcs J 3 pairs K 6 pcs L 1 pc

Screws Wheels Leveling Feet Fabric Cover

locking

Step 1:

Screw Wheels (J) or Leveling Feet (K)

into Bottom Poles (B).

Step 2:

Starting from the bottom, fasten 6 pairs of

Slip Sleeves (C) around the grooves of 6

bottom poles.

Note: The poles have double grooves every

5 inches for easy assembly.

Step 3:

Slide a Large Shelf (D) over the top of 6

bottom poles until it rests snugly over the

sleeves.

Tip: If necessary, use a rubber mallet to

further secure the shelf.

Step 4:

On the narrow side, fasten 4 pairs of slip

sleeves at the desired height of 4 poles.

Slide a Small Shelf (F) over the top of 4

poles until it rests snugly over the sleeves.

Step 5:

Screw Top Poles (A) into bottom poles. On

the wide side, fasten 4 pairs of slip sleeves

at the desired height of 4 poles. Slide the

Medium Shelf (E) over the top of 4 poles

until it rests snugly over the sleeves.

Note: A hanging rod secures to this shelf

and its height should be adjusted to your

need for hanging garments.
