Sharp 21LF-90H Manuale di istruzioni
SCART
ANT.
Aerial connection - TV set only -
Aerial IN
BACK OF TV
Aerial
(Not supplied)
Aerial Lead
(Not supplied)
ANT.
SCART
Connections - TV and VCR -
Aerial
(Not supplied)
Aerial Lead
(Not supplied)
ANT.
SCART
Aerial Lead
(Not supplied)
Scart Lead
(Not supplied)
BACK OF TV
Aerial IN
BACK OF VCR
Audio/Video
RF OUT
AV/TERMINAL
Aerial IN
Typical Connections 21LF-90H
Note: For further details, please refer to operation manual of your VCR.
-1-
Connections - TV, DVD Player and Digital Set Top Box-
BACK OF TV
ANT.
SCART
DVD PLAYER
Scart Lead
(Not supplied)
AV/TERMINAL
Aerial IN
Aerial
(Not supplied)
Satellite dish
(Not supplied)
Dish Lead
(Not supplied)
Aerial Lead
(Not supplied)
Scart Lead
(Not supplied)
Aerial Lead
(Not supplied)
DIGITAL SET
TOP BOX
RF OUT AERIAL IN
TV SCART DISH IN
Note: For further details, please refer to operation manuals of your DVD Player and Digital Set Top Box.
-2-
SCART
ANT.
-3-
FRONT TV
Audio/Video lead
(Not supplied)
Audio Input Terminal
(left)
Video Input Terminal
Audio Input Terminal
(right)
Front connections -TV and Video camera-
Note: For further details, please refer to operation manual of your Video Camera.
SHARP ELECTRONICS (U.K.) LTD.
Sharp House, Thorp Road, Newton Heath,
Manchester M40 5BE
R
SHARP CORPORATION
500*****
01/04
