Sharp 56FW-53H Manuale utente
56FW-53H
COLOUR TELEVISION
QUICK
START
GUIDE
for easy installation
● Fitting the batteries into the remote control
●Connecting the aerial cable
●Tuning the TV channels
Using this installation
guide should enable you
to set up your TV in less
than 15 minutes - - -
- - - Please refer to your
operation manual for
more tips and advice
PRINTED IN SPAIN
TINS-6774BMN3
5/01
SHARP ELECTRONICA
ESPAÑA, S. A.
SHARP ELECTRONICS
(U.K.) LTD.
Sharp House, Thorp Road, Newton Heath,
Manchester M40 5BE
5
NOW LET’S GET STARTED
Refer to the Operation Manual for:
Channel selection .................................. P.11
Picture adjustments............................... P.12
Audio adjustments.................................. P.16
Timer settings (ON/OFF Timer)............... P.20
Child lock................................................ P.22
Menu structures...................................... P.24
Teletext mode......................................... P.25
A scart lead (not supplied) is recommended for use with
this TV, to obtain the best communication between your
TV and VCR, please refer to page-37 of the operation
manual.
INSTALLATION IS COMPLETE!
SAFETY WARNINGS
1 Select a well-ventilated location.
2 Avoid exposing this set to direct sunlight,
dust, heat sources or moisture.
3 Do not place objects containing liquids on
top of the TV.
4 Never open the back cover.
5 Never insert objects into the TV.
6 Take care not to damage the power cord.
7 Keep the TV from strongly magnetic
objects.
If problems persist contact the SHARP (office hours) Helpline on tel:08705 274277
(or (01) 676 0648 if telephoning from Ireland) and/orWEB-SITE: www.sharp.co.uk/support
Power indicator
Main power button
1Press the main power button (®)
to start the AUTO INSTALLATION.
2The red power indicator will light.
3The AUTO INSTALLATION
message will appear on your TV
screen.
The AUTO INSTALLATION function will tune all available
TV stations into your TV.
The TV is ready to preset automatically all local channels
for you.
SUPPLIED ACCESSORIES
Fitting the batteries
1. With your thumb nail, pull
up the slit as shown.
2. Insert the two batteries as
shown.
3. Replace the cover.
1TYPICAL CONNECTIONS
2
TURN TV ON FOR THE FIRST TIME
Check List:
● Is the TV connected to the mains?
● Is the aerial connected to the TV?
3
AUTO INSTALLATION
4
If you do not intend to use your TV with
a VCR then please proceed to stage 4.2
1If the TV is being used
with a VCR, turn on the
VCR and play back a
pre-recorded tape.
2Now, press any button
on the TV remote
control and follow the
instructions on the
screen, to start Auto
Channel Preset.
This tuning process may
take several minutes to
perform.
3After searching has
finished the channels will
be stored in the following
order:
Pr01 - BBC1
Pr02 - BBC2
Pr03 - ITV
Pr04 - CH4
The "Stored programmes" menu will appear on screen
and you can change the order of the channels and change
or give the channels a four letter name.
If you wish to rename the channels, or change the order,
refer to the pages 9 and 10, chapter Stored programmes
in the Operation Manual
If you wish exit from the menu, press the BLUE button.
Note:
If you need to repeat the “AUTO INSTALLATION”, please
refer to the relevant section on page 29 of the operation
manual.
VCR
Remote control
Type-AA Dry Batteries
Operation Manual
Back of TV
Automatic searching and sorting
Press the menu button to cancel
56FW-53H
COLOUR TELEVISION
OPERATION MANUAL
Printedon recycled paper
TV set
Pr 01
