PC-GP Series Quick Setup Guide

Thank you for purchasing a SHARP PC-GP Series personal computer. Follow the instructions below to use the computer for the first time.

Be sure to check all the

following items are included:

• Notebook Computer

• AC Power Code

• AC Adapter

• Battery Pack

• Modem Cable

• Core for a IEEE1394 cable

• Core for a LAN cable

• Recovery CD-ROM Pack

• Windows XP Quick Start Guide

• Operation Manual

• Supplement Booklet

Carefully inspect each component to make

sure nothing is missing or damaged. If any of

these items is missing or damaged, notify

your dealer immediately. Be sure to save the

shipping materials and carton in case you

need to ship or store the computer in the

future.

Attach the included cores to your LAN cable

and IEEE 1394 cable to insure compliance

with requirements of EMC regulations for

computing equipment.

Some other brochures or supplements may

also be contained.

Install the battery pack included

with your computer.

1. Slide the battery lock lever to the left.

2. Install the battery into the computer.

3. Push the battery pack into the computer

until you hear the clicking sound.

4. Slide the battery lock lever to the right. The

battery pack is locked.

5. Turn over the computer and go to the

next section.

Connect AC adapter to the computer.

1. Plug the AC adapter cable to the AC

adapter jack on the rear side of your

computer.

2. Plug the AC power cord into the AC

adapter.

3. Plug the AC power cord into a wall

outlet.

• Always use the AC adapter included with

the computer or the optional one (may not

be available in some countries). Using

other AC adapters may damage the

computer.

• Always hold the AC power cord by its plug

when removing it from the wall outlet.

Never pull on the cord.

• When using the computer for the first time,

be sure to connect it to AC power. If using

the battery instead, you may not be able to

complete the Windows XP setup if the

battery does not have enough power.

Battery Lock Lever

AC Adapter

AC Power Cord

To Wall

Outlet

AC Adapter Jack

Please turn over and

go to the next section

PC-GP Series Quick Setup Guide

Open the display cover and turn

on the computer.

1. Slide the display cover lock lever to the

right until the display cover releases, and

raise the cover.

2. Press the power button to turn on your

computer.

Remove the optical drive

protection sheet.

Press the eject button to draw out the

tray; then, remove the sheet.

Setup Windows XP

After completing a self test to detect any

problems, Welcome to Microsoft Windows

screen appears. For the detail, refer to

Windows XP Quick Start Guide.

1. Follow the instruction on the screen.

2. Select your country, language and

keyboard type; then, click Next.

3. Select your time zone; then, click Next.

4. Accept the license agreement; then, click

Next.

5. Name your computer if you will be

connecting to a LAN; then, click Next. If

you want to skip, click Skip.

6. Click Skip on An Internet connection

could not be chosen dialog box. You will

be able to set up your internet connection

once you have completed Windows

setup.

7. Select No… and click Next. You can

8. Register a user account. You can add the

account except User1 after you finish the

Windows setup. Type a name and click

Next.

9. Click Finish. Windows XP will start.

10. Double-click the time appearing in the

lower right of the screen to open Date

and Time Properties dialog box.

11. Confirm Time Zone is correctly selected,

and set date and time.

Now your PC-GP series personal

computer is ready!

Enjoy your comfortable

computing.

For more information, please refer

to the Operation Manual or

Windows XP Quick Start Guide.

Protection Sheet

Eject Button

561867182001

Display Cover Lock Lever

Power Button
