EN - 2

Icon Type Meaning

WARNING Serious injury or death risk

RISK OF ELECTRIC SHOCK Dangerous voltage risk

FIRE Warning; Risk of re / ammable materials

CAUTION Injury or property damage risk

IMPORTANT / NOTE Operating the system correctly

Thank you for choosing this product.

This User Manual contains important safety information and instructions on the operation

and maintenance of your appliance.

Please take the time to read this User Manual before using your appliance and keep this

book for future reference.

CONTENTS

1.SAFETY INSTRUCTIONS .................................................................................................4

1.1 General Safety Warnings ...............................................................................................4

1.2 Installation Warnings ......................................................................................................6

1.3 During Use .....................................................................................................................7

1.4 During Cleaning and Maintenance .................................................................................8

2.INSTALLATION AND PREPARATION FOR USE ............................................................10

2.1 Instructions for the Installer ..........................................................................................10

2.2 Installation of the Oven .................................................................................................10

2.3 Electrical Connection and Safety.................................................................................. 11

3.PRODUCT FEATURES ...................................................................................................12

4.USE OF PRODUCT ........................................................................................................13

4.1 Oven Controls...............................................................................................................13

4.2 Accessories ..................................................................................................................16

5.CLEANING AND MAINTENANCE...................................................................................17

5.1 Cleaning ...................................................................................................................17

5.2 Maintenance .................................................................................................................19

6.TROUBLESHOOTING&TRANSPORT ............................................................................20

6.1 Troubleshooting ............................................................................................................20

6.2 Transport ...................................................................................................................20

7.TECHNICAL SPECIFICATIONS ......................................................................................21

7.1 Energy Fiche ................................................................................................................21

EN - 4

1. SAFETY INSTRUCTIONS

• Carefully read all instructions before using your

appliance and keep them in a convenient place for

reference when necessary.

• This manual has been prepared for more than one

model therefore your appliance may not have some

of the features described within. For this reason, it

is important to pay particular attention to any figures

whilst reading the operating manual.

1.1 General Safety WarninGS

• This appliance can be used by children aged from

8 years and above and by persons with reduced

physical, sensory or mental capabilities or lack

of experience and knowledge if they have been

given supervision or instruction concerning use of

the appliance in a safe way and understand the

hazards involved. Children should not play with the

appliance. Cleaning and user maintenance should

not be made by children without supervision.

WARNING: The appliance and its accessible parts

become hot during use. Care should be taken to avoid

touching heating elements. Keep children less than 8

years of age away unless they are continually

supervised.

WARNING: Danger of fire: Do not store items

on the cooking surfaces.

WARNING: If the surface is cracked, switch off

the appliance to avoid the possibility of electric shock.

• Do not operate the appliance with an external timer

or separate remote-control system.

• During use the appliance will get hot. Care should

be taken to avoid touching heating elements inside

EN - 5

the oven.

• Handles may get hot after a short period during use.

• Do not use harsh abrasive cleaners or scourers

to clean the oven door glass and other surface.

They can scratch the surfaces which may result in

shattering of the door glass or damage to surfaces.

• Do not use steam cleaners for cleaning the

appliance.

WARNING: To avoid the possibility of electric

shock, make sure that the appliance is switched off

before replacing the lamp.

CAUTION: Accessible parts may be hot when

cooking or grilling. Keep young children away from the

appliance when it is in use.

• Your appliance is produced in accordance with all

applicable local and international standards and

regulations.

• Maintenance and repair work should only be carried

out by authorised service technicians. Installation

and repair work that is carried out by unauthorised

technicians may be dangerous. Do not alter or

modify the specifications of the appliance in any

way. Inappropriate hob guards can cause accidents.

• Before connecting your appliance, make sure

that the local distribution conditions (nature of the

gas and gas pressure or electricity voltage and

frequency) and the specifications of the appliance

are compatible. The specifications for this appliance

are stated on the label.

CAUTION: This appliance is designed only for

cooking food and is intended for indoor domestic

household use only. It should not be used for any

other purpose or in any other application, such as for

non-domestic use, in a commercial environment or for

EN - 6

heating a room.

• Do not use the oven door handles to lift or move the

appliance.

• All possible measures have been taken to ensure

your safety. Since the glass may break, care should

be taken while cleaning to avoid scratching. Avoid

hitting or knocking the glass with accessories.

• Make sure that the supply cord is not trapped or

damaged during installation. If the supply cord is

damaged, it must be replaced by the manufacturer,

its service agent or similarly qualified persons in

order to prevent a hazard.

• Do not let children climb on the oven door or sit on it

while it is open.

• Please keep children and animals away from this

appliance.

1.2 inStallation WarninGS

• Do not operate the appliance before it is fully

installed.

• The appliance must be installed by an authorised

technician. The manufacturer is not responsible

for any damage that might be caused by defective

placement and installation by unauthorised people.

• When the appliance is unpacked, make sure that

it is has not been damaged during transportation.

In case of any defect do not use the appliance

and contact a qualified service agent immediately.

The materials used for packaging (nylon, staplers,

Styrofoam, etc.) may be harmful to children and they

should be collected and removed immediately.

• Protect your appliance from the atmosphere. Do not

expose it to effects such as sun, rain, snow, dust or

excessive humidity.

EN - 7

• Any materials (i.e. cabinets) around the appliance

must be able to withstand a minimum temperature

of 100°C.

• The appliance must not be installed behind a

decorative door, in order to avoid overheating.

1.3 DurinG uSe

• When you first use your oven you may notice a

slight smell. This is perfectly normal and is caused

by the insulation materials on the heater elements.

We suggest that, before using your oven for the

first time, you leave it empty and set it at maximum

temperature for 45 minutes. Make sure that the

environment in which the product is installed is well

ventilated.

• Take care when opening the oven door during or

after cooking. The hot steam from the oven may

cause burns.

• Do not put flammable or combustible materials in or

near the appliance when it is operating.

• Always use oven gloves to remove and replace food

in the oven.

• Under no circumstances should the oven be lined

with aluminium foil as overheating may occur.

• Do not place dishes or baking trays directly onto the

base of the oven whilst cooking. The base becomes

very hot and damage may be caused to the product.

Do not leave the oven unattended while cooking

with solid or liquid oils. They may catch fire under

extreme heating conditions. Never pour water on to

flames that are caused by oil, instead switch the oven

off and cover the pan with its lid or a fire blanket.

• If the product will not be used for a long period of

time, turn the main control switch off.

• Make sure the appliance control knobs are always

in the “0” (stop) position when it is not in use.

• The trays incline when pulled out. Take care not

to spill or drop hot food while removing it from the

ovens.

• Do not place anything on the oven door when it is

open. This could unbalance the oven or damage the

door.

• Do not hang towels, dishcloths or clothes from the

appliance or its handles.

1.4 DurinG CleaninG anD MaintenanCe

• Make sure that your appliance is turned off at

the mains before carrying out any cleaning or

maintenance operations.

• Do not remove the control knobs to clean the control

panel.

• To maintain the efficiency and safety of your

appliance, we recommend you always use original

spare parts and to call our authorised service agents

in case of need.

EN - 8

EN - 9

This symbol on the product or on its packaging

indicates that this product should not be

treated as household waste. Instead it should

be handed over to the applicable collection

point for the recycling of electrical and

electronic equipment. By ensuring this product is

disposed of correctly, you will help prevent potential

negative consequences for the environment and

human health, which could otherwise be caused by

inappropriate waste handling of this product. For more

detailed information about recycling of this product,

please contact your local city office, your household

waste disposal service or the retailer who you

purchased this product from.

This appliance has been designed to be used only

for home cooking. Any other use (such as heating a

room) is improper and dangerous.

The operating instructions apply to several models.

You may notice differences between these instructions

and your model.

Disposal of your old machine

EN - 8

CE Declaration of conformity

We declare that our products meet the

applicable European Directives, Decisions

and Regulations and the requirements

listed in the standards referenced.

EN - 10

2. INSTALLATION AND

PREPARATION FOR USE

WARNING : This appliance must be

installed by an authorised service

person or qualified technician, according to

the instructions in this guide and in

compliance with the current local

regulations.

• Incorrect installation may cause harm

and damage, for which the manufacturer

accepts no responsibility and the

warranty will not be valid.

• Prior to installation, ensure that the local

distribution conditions (electricity voltage

and frequency) and the adjustments

of the appliance are compatible. The

adjustment conditions for this appliance

are stated on the label.

• The laws, ordinances, directives and

standards in force in the country of use

are to be followed (safety regulations,

proper recycling in accordance with the

regulations, etc.).

2.1 inStruCtionS for the inStaller

General instructions

• After removing the packaging material

from the appliance and its accessories,

ensure that the appliance is not

damaged. If you suspect any damage,

do not use it and contact an authorised

service person or qualified technician

immediately.

• Make sure that there are no flammable

or combustible materials in the close

vicinity, such as curtains, oil, cloth etc.

which may catch fire.

• The worktop and furniture surrounding

the appliance must be made of

materials resistant to temperatures

above 100°C.

• The appliance should not be installed

directly above a dishwasher, fridge,

freezer, washing machine or clothes

dryer.

2.2 inStallation of the oven

The appliances are supplied with

installation kits and can be installed in a

worktop with the appropriate dimensions.

The dimensions for hob and oven

installation are given below.

A (mm) 557 E (mm) 878

B (mm) 550 min./max. F (mm) 560/580

H (mm) 890 min. G (mm) 555

C (mm) 595 min. I (mm) 880

D (mm) 575 min. J/K (mm) 5/10

Indice

Altri manuali Sharp Forno

Sharp

Sharp STB-611C Manuale utente

Sharp

Sharp KA-62V19IM0-EU Manuale utente

Sharp

Sharp SMD2477AHC Manuale utente

Sharp

Sharp SUPERSTEAM AX-1500J Manuale utente

Sharp

Sharp EO-387R-BK Manuale utente

Sharp

Sharp Home Appliances K-62D19IM0-EU Manuale utente

Sharp

Sharp K-70V19BM2-EN Manuale utente

Sharp

Sharp Microwave Drawer SMD2440JS Manuale utente

Sharp

Sharp K-50M22BL2-EU Manuale utente

Sharp

Sharp R-961INW Manuale utente

Sharp

Sharp KF-66DVDD04IM1-EN Manuale utente

Sharp

Sharp Microwave Drawer SMD3070ASY Manuale utente

Sharp

Sharp SWB3085HS Manuale utente

Sharp

Sharp SuperSteam+ SSC2489DS Manuale utente

Sharp

Sharp K-60D22BM1-EN Manuale utente

Sharp

Sharp K-71Z68BNM Manuale utente

Sharp

Sharp Microwave Drawer SMD2489ES Manuale utente

Sharp

Sharp SMD2470AS Manuale utente

Sharp

Sharp SWA3052DS Manuale utente

Sharp

Sharp OVER THE RANGE MICROWAVE OVEN/HOOD SYSTEM Manuale utente

Sharp

Sharp KA-70V19IM2-EU Manuale utente

Sharp

Sharp KA-74Z68BNH-PL Manuale utente

Sharp

Sharp K-60M15BL2-EN Manuale utente

Sharp

Sharp AX-1200 Manuale utente

Manuali Forno popolari di altre marche

Bosch

Bosch HVA531NS0 Manuale utente

Electrolux

Electrolux EOF6P46X Manuale utente

NEFF

NEFF B44S32 5GB Series Manuale utente

Combi

Combi BLODGETT BC142GDS Manuale utente

AEG

AEG COMPETENCE 311704300 Manuale utente

Falcon

Falcon DOMINATOR PLUS G3106 Series Guida utente

Rational

Rational SCC WE 61G Manuale utente

Smeg

Smeg DOSPA38X Manuale di installazione e funzionamento

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manuale utente

Miele

Miele HR 1954-2 Manuale utente

KHIND

KHIND OT50 Manuale utente

Henny Penny

Henny Penny Smoker Box Manuale utente

Lang

Lang ECOD-AP Manuale utente

AEG

AEG BEK455310M Manuale utente

Frigidaire

Frigidaire FNGE90JGR Manuale utente

Hotpoint

Hotpoint FE9 S831 JSH IX Manuale utente

GE Advantium SCB2000 Manuale utente

AEG

AEG DE401301DM Manuale utente
