Shehds SHE-Butt30W4D Manuale utente
1
Maintenance
1.Please keep the light in dryness and avoiding use in wet place.
2.Using intermittenlly can be extended the life.
3.Attention to clean the fan and lens usually in order to get the ventilating effects and lighting effects
better.
4.Please do not wipe the crust using organic menstruum for avoid to damaged the product.
Statement
The product has well capability and intact packing when leave factory,All of the user should comply with
above warning item and manual ,any misuse cause of the damages are not included in our
guarantee,and also can’t be responsible for any malfunction & problem owing to ignore the manual.
Please forgive that we will not be notice for technical change
Attention Item
1.For guarantee the life of product,please do not put it on the wet place and not use it the place over 40
degree.
2.Please don’t lay the product on the un-fixable or shakable place.
3.Ask for the professional to maintain the product in order to avoid the danger of get an electric shock.
LED Beam 30W Butterfly Light
2
4.Power supply should not be changed over +&-10% while the light is using,it will be decreased the life
of lamp if the power is too high,but it will be influenced the luminosity if the power is too low.
5.After power off,if it is need used again,please cool down over 20 minuter.
6.Please look round the manual for ensure the product can be used normally.
DMX Channel Summary-8 Channels Mode
Channel
Value
Function
CH1
0-255
Total dimmer, linear dimming-Dark to Bright
CH2
0-255
Strobe,Slow to Fast
CH3
0-255
Red color
CH4
0-255
Green control
CH5
0-255
Blue color
CH6
0-255
White color
CH7
0-127
128-255
RGBW rotation adjustment
RGBW auto rotation
CH8
006-042
043-080
081-117
118-155
156-255
R auto run mode
G auto run mode
B auto run mode
W auto run mode
RGBW auto run mode
Display Control Instruction
No
Display
Function
1
R001
8-channel address code
2
A1 9
R auto run mode
3
A2 9
G auto run mode
4
A3 9
B auto run mode
5
A4 9
W auto run mode
6
A5 9
RGBW auto run mode 1
7
A6 9
RGBW auto run mode 2
8
A7 9
RGBW auto run mode 3
9
Soud
Sound control mode
3
Display Control Instruction
Welcome to use our light.The light uses energy-saving LED,long Product
life,shockproof,dustproof, DMX receiver and self-running feature, which can
produce a variety of vivid lighting effects,easy to operate, suitable for all types of
entertainment decoration,architectural lighting industry.
E
A:Menu
B:Up
C:Down
D:Enter
E:LED Display
A B C D
Instructions:Press the function key MENU cycled out the eight different function
effects,digital tube first two digits on behalf of which the current function(see
menu).The last two digits represent the functions in which the address code or
speed parameters.Press the UP or DOWN key to modify the parameter
values.Press the ENTER key to confirm.
4
Product Introduction
*Power Supply:AC90--275V,50--60HZ
* Power consumption:30W
* Fixing lamp:30W RGBW 4in1 LED
* DMX-Control-channels:8 DMX Channels
* Shuttle:Flash rate:0--10HZ
* Dimmer:0-100% mechanic dimmer
* Long Lifespan LEDs(more than 60,000 hours)
