Shockwave BODY TRACKING AND HAPTIC SUIT Manuale utente
BODY TRACKING AND HAPTIC
SUIT
USER MANUAL
COMPLIANCE
FCC Compliance Statements
Contains FCC ID:2A094-MK02
The equipment has a model number assigned as SS00 .
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including, an interference that may Cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B Digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential Installation. This equipment generates, uses and can radiate radio frequency Energy and, if not installed
and used in accordance with the instructions, may cause Harmful interference to radio communications. However, there is no guarantee that Interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the Receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
Any changes or modifications not expressly approved by the party
Responsible for compliance could void the users’ authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other Antenna or transmitter.
Radiation RF exposure statements:
This equipment complies with FCC radiation exposure limits set fourth for an Uncontrolled environment. This equipment should be installed and operated with Minimum
distance 20cm between the radiator & your body.
ISED Compliance Statements
Contains IC: 26442-MK02
This device complies with ISED's license-exempt RSSs. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the device.
Cet appareil est conforme aux RSS exemptés de licence de l’ISED.
L’opération est soumise aux deux conditions suivantes :
(1) cet appareil peutne pas causer d’interférences nocives, et
(2) cet appareil doit accepter toute interférence, y compris les interférences qui peuvent provoquer un fonctionnement non désiré de l’appareil.
Radiation Exposure Statement:
This equipment complies with ISED radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Déclaration sur l’exposition aux rayonnements :
Cet équipement est conforme aux limites d’exposition aux rayonnements
ISED établies pour un environnement non contrôlé. Cet équipement doit être
installé et actionné avec la distance minimale 20cm entre le radiateur et votre corps.
Detachable Antenna Usage:
This radio transmitter(IC: 26442-MK02/ Model: MK02D ) has been approved by ISED to operate with the antenna type listed below with maximum permissible gain
indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
Antenna name Antenna type Antenna
gain(dBi)
Transmitting
power level
Data Rate
MK02D
PCB Antenna
-
0.1dB
4dBm
BLE 1Mbps
CONTENTS
1. Accessories
2. Setting up your Shockwave Suit
Putting on your suit
Strapping the lower body straps
Inserting the batteries
Powering the suit
Calibrating the suit
3. Wash care instructions for your Shockwave Suit
How to wash
How to dry
Don’ts
4. Health and safety warnings
Conditions for use
Storage
Power Source and Cables
Heating and Overuse
Battery Warnings and Safety
1. Accessories
The Shockwave suit comes with the following accessories
•Battery compartment for 3 x AA batteries (not included) with cable and connector
•1 x USB to 2.1mm DC Jack power cable
•1 x Tightening Belt
•1 x Silicone Cap
2. Setting up your Shockwave Suit
Setting up your Shockwave suit involves the following steps
•Putting on your suit
•Strapping the lower body straps
•Inserting the batteries
•Powering the suit
•Calibrating the suit
Putting on your suit
Wear the suit on your upper body (like any jacket) and fasten the zipper
If required, use the belt provided to tighten the suit around your waist for a body-tight fit
Strap the hanging lower body pieces around your legs and fasten them with the Velcro
Insert 3 x AA batteries in the battery box provided with the suit and secure the cover
Put the battery compartment inside the side pocket of the suit
Connect the power cable of the battery compartment to the power connector in the suit and switch the power
button to ‘on’
ON
