SAFETY WARNINGS
1. Always wear safety equipment such as a helmet,
knee pads and elbow pads. DO NOT lend the scooter
to people who don’t know how to ride it.
2. It is recommended to ride at low speeds until you
are familiar with the scooter. The recommended speed
is below 15KM/h.
3. DO NOT ride in the rain.
4. Pay attention to obstacles while riding, to avoid
collision.
5. Ride at low speed on unconventional roads such as
speed humps.
6. Reduce speed when going downhill, use both EABS
and foot brake. The faster you ride the longer the
braking distance you need.
7. DO NOT hang heavy objects on the handlebars.
8. DO NOT press electronic accelerator while walking.
9. DO NOT ride on one foot.
10. CHECK LOCAL LAWS REGARDING SCOOTER USE.
Check local laws and regulations to see where and
how you may use your scooter legally. DO NOT ride on
roads.
11. DO NOT ride with more than one person on the
scooter at any time (including children).
12. DO NOT ride in water.
13. DO NOT step on the folding mechanism whilst riding.
14. Keep both hands on the handlebar at all times.
15. No sharp turns while riding at high speeds.
16. DO NOT touch the front wheel motor, as it may get
very hot after riding.
17. DO NOT perform any jumps or stunts of any kind
whilst riding.
Battery
1.DO NOT use different brands of batteries.
2.DO NOT open and puncture the battery case. Avoid the
risk of short circuit caused by metal objects touching the
battery contacts.
3.Improper disposal of used batteries may pollute the
environment. Observe the local regulations for disposal of
batteries.
4.DO NOT place the battery in a high temperature or low
temperature environment. DO NOT place the battery into
the fire.
Power Adapter
1.Only use the original power adapter to charge the
battery, other power adaptors may over heat and
cause fire.
2. DO NOT disassemble the charger casing and avoid
contact with the metal port when the power is on,
otherwise there is a risk of electric shock or damage to
the charger.
Daily maintenance
1. Check the scooter before riding for any loose nuts, bolts
or fittings. Do not use the scooter if you are unsure.
2.Do not use alcohol, gasoline, kerosene or other
corrosive liquids to clean your scooter. This may damage
the appearance and internal structure of the scooter
body. DO NOT use a pressure washer to wash scooter.
3. Before cleaning, please make sure that the scooter is
turned off, the charger has been unplugged, and the
rubber plug of the charging port is covered. Failure to do
so may cause damage to the electronic components.
4. Charge the battery after each ride to avoid battery
drain.
5. In standby mode, the low battery should be charged
every 30-60 days.
6. DO NOT try to disassemble the battery.
7. DO NOT use the electric scooter in low temperature or
high temperature environment. Extreme temperature may
effect the performance and function of the scooter.
Specifications Table
The scooter Item Number ES40
Unfolded Size 102.5cm x 43cm x 101.5cm
Folded Size 101.5cm x 43cm x 35cm
Net Weight 11.6KG
Max Load 100KG
Max Speed 25Km/h (Subject to rider weight and terrain)
Max Distance 20-25Km (Subject to rider weight and terrain)
Max Climbing Degree 14°+
Operating Temperature -10-40°
Storage Temperature -20-50°
Battery Rated Voltage 36V
Max Charging Voltage 42V
Battery Capacity 36V 7.5AH lithium battery
Charging Temperature 0-40°
Battery Management System Overheat/short circuit/overcurrent/overcharge protection
Motor Rated Power 250W
Max Power 500W
Charger Output rating 63W
Rated voltage range 100-240V
Rated output voltage 42V
Rated current 1.5A
Charge time 3.5h
