Product

Specification

Page

1

|

8

June

2012

Mena Computers

Wageningselaan 46=D

3903 LA Veenendaal

|

The Netherlands

Tel

.

+31 (0) 318 518720

sales@shuttleshop.nl

w w w . s h u t t l e s h o p . n l

F

e

ature

Highlights

S

lim

-D

es

ig

n

 Slim 3.5 litre

chassis,

black



Dimensions:

24 x 20 x 7.2 cm (L/W/H)

 Bays: 2x

6.35cm/2.5”

for

hard

disks or

SSDs

and

1x slim

optical

drive

Processor



Supports Socket

1155 CPUs, max. 65W

TDP



Supports Core

i7 / i5 /

i

3,

Pentium,

Celeron



Supports

32nm

and 22nm

processors



Including heat-pipe cooling

system

Chipset

 Intel H61 Express

Chipset

Memory

 2x 204 pin

SO-DIMM

slots



Supports DDR3-1333/1600,

m

a

x.

2x 8 GB

Graphics



In

tegrated

Intel HD

graphics

(features depends

on

proces

sor)



Video-outputs:

HDMI

and

DVI-I

Drive

Connectors

 3x

SATA II

(3 Gbit/s) with

UEFI

support

 Two

pre-installed

SATA

cable

s (HDD+ODD)

Other

Connectors

 5.1 HD Audio

(

d

igital

audio

via S/PDIF)

 2x

USB

3.0, 4x

USB

2.0, 2x

USB

2.0

onboard

 Dual

Gigabit

L

A

N

(R

J45

)

,

supports

WOL,

PX

E

 2x COM ports

(RS232

+

RS

232

/

RS

42

2/

RS

485

)

Power

Supply

 External 90W

f

a

n

l

ess

power

adapter

Application

 Home, office,

vertical

marke

t

Ivy Bridge

performanceand

extensive

connectivity

packed

in

a

3.5-litre

chassis

The

ultra-compact

Shuttle Slim-PC

Barebone

XH61V

is the

ideal

basis to set up

a

small, but

powerful

PC. Be it for the

hom

e

environment

i

n

form of

a

HT

PC,

an

office PC for

enterprises

or

a

platform

to

be used

for industrial

applications,

the

XH61V

delivers.

W

i

th

Dual-LAN

for server

applicationsand

two serial ports

to

connect

it to

professional devices, there

is

also two digital

video

outputs

to use multiple monitors

at once.

Driven by

a 22nm

Intel

Ivy Bridge

processorand

in

a team

with

a

2.5" SSD,the

XH61V

is

an

efficient system that

banks

its reliability on Shuttle’s

w

e

ll-tried

heatpipe

coolin

g.

Shuttle Slim-PC

Barebone

XH

61

V

Images

for

illustration

purposes

only.

The

optical

drive

and

the

vertical

stand are available

o

p

tion

ally.

Product

Specification

Page

2

|

8

June

2012

Mena Computers

Wageningselaan 46=D

3903 LA Veenendaal

|

The Netherlands

Tel

.

+31 (0) 318 518720

sales@shuttleshop.nl

w w w . s h u t t l e s h o p . n l

Shuttl

e

Slim-PC

Barebone

XH61V

–

Product

Features

The 3.5-litre chassis - a clean and modern look

Shuttle has

alwaysplaced great emphasis

on the

i

n

terio

r

and

exter

i

or

aesthetics

of their

M

i

n

i

-PCs with the belief that

a good blend

of

style

7.3

and

form

factor

allow the

Min

i

-PC to

be attractive, versatile and

work

well in

almost any environment. And

the

XH61V

was

designed

j

u

st

like

that

and

shines in

a clean and modern

appearance.

The

optical

drive

and

front

panel connectors are

elegan

tly

concealed behind

drive

doors

to

provide maximum protection.

This

tiny tot

barely stands

7.3

c

m

in

height

w

i

th

a volume

of 3.5 litres.

What does Barebone mean?

The Shuttle Slim-PC

Barebone

XH61V

consists

of

a

stylish

case

with

pre-

installed mainboard, cooling

system

and externalpowe

r

adapter.

Despite

its small form

factor

it offers

outstanding

connec

t

ivity,

functionality

and performance.

For

a complete

M

i

n

i

-PC system,

a

few

components

still

need

to

be added.

The Mini-PC is

customisable

and

takes socket

1155

processors,

DDR3

SO-DIMM

memories,

slim-li

n

e

SATA

optical

drive, 2.5”

hard

disk

(

or

SSD).

Once

the

desired

operation

system is

installed,

the

XH61V

is

ready

to

use. Moreover,

the

system

features pre-routed cables

that

are

tied

down

from

factory

to

reduce

clutter,

i

n

crea

s

e

airflow

and ease component

i

n

stallatio

n

.

Supports LGA1155 processors and up to 16 GB DDR3

A

wide

range

of

socket

1155 Intel

processors

is

available

starting

from

Celeron

up to

Core processors

with

a

maximum

TDP

of 65W. Plus,

the

system

memory can be

i

n

sta

lled

according

to

i

n

dividual

needs

up to

a

maximumcapacity

of 16 GB DDR3

mem

o

ry

.

Traditional Planar

Transistor

22nm Tri-Gate

Transistor

Supports Intel 22nm Ivy Bridge Processors

Ivy Bridge

(IVB)

is the

codename

for Intel's new 22nm

processor

microarchitecture introduced

in April 2012

along

w

i

th

the

7-series

chipsets.

Ivy

Br

idge

is the first

chip

to use Intel's 22nm tri-g

a

te

transistors,

wh

i

c

h

will

help scale frequencyand reduce

p

o

wer

consumption.

At

a

high level Ivy

Bri

dge

looks

a

lot like

Sandy

Bridge -

one

mo

nolith

i

c

die

i

ncorpor

ates

up to four CPU

cores, the shared

L3

cache,

the

memory

co

ntroll

e

r,

PCIe

li

nks

and

the

graphics processor.

Compared

to its

predecessor Sandy

Bridge, the

new design

brin

gs

some improvements

in

overa

ll

performance, overcloc

ki

ng,

power

management and

also

features

PCIe v3.0

and

DDR3-1600

capability,

an updated

DirectX 11

graphics, new

security

features and

CPU

instructions.

Ivy Bridge

still

uses the known

L

G

A1155

socke

t

.

Great Connectivity

On the front,

e

l

egan

tly

hidden

from view

behind

drive

doors,

the

pa

n

e

l

reveals

two

USB

2.0 ports for

external

drives, MP3

players etc.

There

are

also two

3.5mm

jacks for

headphone and microphone.

I

n

addition,

the

back panel

offers

a

wide

range

of I/O

connectivity

as

we

ll.

Product

Specification

Page

3

|

8

June

2012

Mena Computers

Wageningselaan 46=D

3903 LA Veenendaal

|

The Netherlands

Tel

.

+31 (0) 318 518720

sales@shuttleshop.nl

w w w . s h u t t l e s h o p . n l

2x USB 3.0

The Shuttle Slim-PC

Barebone

XH61V

sports two

USB

3.0

ports

besides

four

USB

2.0 ports.

USB

3.0

achievesa

maximum

data rate

of up

to

5.0Gbps (640MBytes/sec)

which is ten tim

e

s faster

than

USB

2.0.

USB

3.0

is fully

compatible

to

USB

2.0. At

a glance,

USB

3.0

connectors seem no

different

to

USB

2.0

connectors, however

USB

3.0

connectors have 5

more

pins

placed

inside the

connector

its

e

lf.

USB

2.0

can provide

a

maximum

of 500mA to the

USB

device

whil

e

USB

3.0

can provide

a

maximum output

of 900mA, which is

important

for

portable hard

drives.

USB

3.0 also

comes

with

better power saving features

to let y

o

ur

devices

run

more

efficiently when

i

n

idle

m

o

de.

Dual Gigabit LAN Network

Today’s

media-rich communications across

the

i

nternet

and

within

enterprisescreate

new

demands

for

c

lie

nts

in Local Area Networks. For

that

reason,

Shuttle

applies Gigabit

LAN

performance

to their

M

i

n

i

-PCs

and

XH61V

even supports

two of

them.

Dual

networking

allows

the

computer

to

connect

to

a

single network using two

cables at once

with

an appropriate

switch

(teaming mode

with

load balancing

or

failover

function) or to two

different

networks

depending

on the

needs

of

the

user.

Dual View Technology with HDMI and DVI (or VGA)

Dual View

technology

offers multiple

display support

on up to

two

separate

monitors.

This

helps to

improve

on

productivity by allowing

for

spreading

multiple windows

across

two monitors

whi

l

e

working

w

i

th

them simultaneously.

XH61V

features

two

video outputs:

HDM

I

and

DVI-

I.

DVI-I

HDMI

D-Sub

(VGA)

DVI-D

Video outputs

W

i

th

optional adapters

DVI-D

devicescan be connected

to the

HDM

I

port or

VGA

devices

to the

DVI-I

port,

resp

ectively.

DVI-D

means the connector

only

outputs

digital

video

signals.

DVI-

I

means

digital

and analog video

signals

are

put

out.

HDMI

supports

digital

video

plus

multi-chan

n

e

l

digital

audio

output.

Digital

Audio 1

Digital

Audio 2

Analog

Audio 1

Digital Audio

Beside the

analog audio,

XH61V

can provide

digital

multichan

n

e

l

audio

in two

w

a

ys: via the

optical

S/PDIF

output

(Toslink)

or

through

HDMI.

Therefore,

two

audio devices are

shown

i

n

the Windows

device

manager. Connect

the

HDMI

to your

TV

set

and

you

will

have

both

digital

audio and video.

For

better audio expierience

you may use

a

n

audio receiver

(amplifier) with

a bunch

of

speakers around

which is

probably connected

via

S/PDIF. XH61V

is flexible

enough

to

support

both

options.

Two serial ports

M

a

ny

PCs do not

have these legacy

ports

any longer, since

they

have

been supersededand replaced

by

USB

for most

consumer

appli-

cations,

but they

are

still

common

l

y

used

for

applications

such

as

industrial

automation

systems, scientific

analysis,

POS systems

and

other industrial

applications.

XH61V

features

two serial RS-232

ports

Product

Specification

Page

4

|

8

June

2012

Mena Computers

Wageningselaan 46=D

3903 LA Veenendaal

|

The Netherlands

Tel

.

+31 (0) 318 518720

sales@shuttleshop.nl

w w w . s h u t t l e s h o p . n l

which also

support both

5 or 12V. The lower COM port also

supports

the

RS422

and

RS485

standard.

2x expansion slots for Mini-PCI-Express cards

XH61V

features

two

expansion

slots for Mini-PCIe

cards. One

is

a

half

size slot

dedicated

for

an optional

W

i

reless

LAN

adapter.

The

secon

d

has full size format

and

not only

featuresa

PCIe

interface,

but

also

mSATA

(M

in

i

Serial

ATA),

supporting

the

new generation

of Solid

State

Drives

(SSD)

in

a compact

Mini PCIe

card

f

orm

factor.

Photos: half

siz

e

WLAN

card

(left)

and

mSATA SSD

card

(right).

Kensington Lock

This

is

a

small,

metal-reinforced

hole as part of

an

an

ti-th

e

ft

sy

stem.

(The

lock-and-cable are

not in

cluded)

Heat pipe cooling

XH61V

featuresa

highly

effic

i

ent

heat pipe cooling.

A

heatpipe

is

a

hollow

tube containing a heat

transfer

liqu

i

d.

As the liquid

evaporates,

it

carries heat

to the

cool end, where

it

condensesand

then returns

to

the hot

end. Heatpipes

thus

have a much higher effective

thermal

conductivity than

solid

materials.

Pl

ease

keep

the vent holes

clear

of

obstructions.

Optional Stand for vertical operation (PS01)

XH61V

can be used

for

horizontal operation

by

default.

W

i

th

the

optional stand accessory

(PS01), it

can

also

be placed

in

vertical

position

.

Optional VESA mount (PV02)

Its

optional

VE

SA75/100

wallmount

allows

it

to

be

i

n

stalle

d

on to walls

o

r

j

u

st

affixed on the rear side of

a

mon

i

tor

which is

particularly

in

terestin

g

for the industry

segment, company buildings and public

institutio

ns.

Product

Specification

Page

5

|

8

June

2012

Mena Computers

Wageningselaan 46=D

3903 LA Veenendaal

|

The Netherlands

Tel

.

+31 (0) 318 518720

sales@shuttleshop.nl

w w w . s h u t t l e s h o p . n l

Connectivity

/

Applications

The

XH61V's

g

r

eat

connectivity makes

it

well-suited

for

a

wide

field

of

applications and externaldevices

.

Point-of-Sales

(POS)

Office Display Dual Network

DV

I-I

2x RJ45 PC Speakers

Audio

RS232

RS422/485

S/PDIF

HDMI

USB 2.0

USB 3.0

Peripherals

Automation

Digital Audio

Home Cinema &

Digital Signage

USB Hard Disk

The

XH61V

is your powerful 3.5-litre Slim-PC

solut

i

on

for

h

i

gh

performance

driven

applications,

e.g.:

 Digital

Signage

 In-store

Audio/Video

entertain

m

ent



Gambling



Home-Media



Office

 Call

Center



Education

 Kiosk

 Point of Sales (POS)



Medical



Automation

 Small

server

Product

Specification

Page

6

|

8

June

2012

Mena Computers

Wageningselaan 46=D

3903 LA Veenendaal

|

The Netherlands

Tel

.

+31 (0) 318 518720

sales@shuttleshop.nl

w w w . s h u t t l e s h o p . n l

Shuttle 3.5-litre Slim-PC

Barebones

Comparison

with

predecessor models

Barebone model

XG41

XH61

XH61V

Availability

June 2011

Dec. 2011

June 2012

UPC bar code

811686003472

811686003588

811686003830

Chassis

Steel, black

3.5L (24.2 x 20 x 7.3 cm)

Steel, black

3.5L (24.2 x 20 x 7.3 cm)

Steel, black

3.5L (24.2 x 20 x 7.3 cm)

Intel processor support

LGA775, max. 65W

FSB: 800, 1066, 1333MHz

Core 2 Duo, Pentium,

Celeron

LGA1155, max. 65W

32nm Sandy Bridge

Core i7, i5, i3, Pentium,

Celeron

LGA1155, max. 65W

32nm Sandy Bridge

22nm Ivy Bridge

Core i7, i5, i3, Pentium,

Celeron

Processor cooling

Heatpipe cooling system

with two 6 cm fans

Provided cooling fan:

80 x 80 x 15 mm

Heatpipe cooling system

with two 6 cm fans

Chipset

Intel G41 + ICH7

Intel H61

Intel H61

Mainboard

Mini ITX

All solid capacitors

Mini ITX

All solid capacitors

Mini ITX

All solid capacitors

Integrated graphics

GMA X4500, DX10

HD graphics (CPU)

HD graphics (CPU)

Memory support

Max. 2x 4GB

DDR3-800/1066

240 pin DIMM

Max. 2x 8GB

DDR3-1333

240 pin DIMM

Max. 2x 8GB

DDR3-1333/1600

204 pin SO-DIMM

Audio codec

Realtek ALC662

Realtek ALC887

Realtek ALC662

Ethernet (LAN)

Dual Gigabit, Teaming

2x Realtek 8111E

Single Gigabit

1x Realtek 8111E

Dual Gigabit, Teaming

2x Realtek 8111E

Storage bays

1x Slim optical drive

2x 2.5”hard disk / SSD

1x Slim optical drive

1x 2.5”hard disk / SSD

1x Slim optical drive

2x 2.5”hard disk / SSD

Preinstalled SATA cables

2x (for Slim ODD & HDD)

2x (for Slim ODD & HDD)

2x (for Slim ODD & HDD)

Mini-PCIe slot

1x full/half size

None

1x half size

1x full size (mSATA)

Front panel

Power button

Power & HDD LED

2x USB 2.0

2x Audio (Line-out/Mic)

Power button

Power & HDD LED

2x USB 2.0

2x Audio (Line-out/Mic)

Power button

Power & HDD LED

2x USB 2.0

2x Audio (Line-out/Mic)

Back Panel

HDMI

DVI-I

4x USB 2.0

2x Gigabit LAN (RJ45)

3x Audio (Mic, Line in/out)

Optical S/PDIF out

RS232 + RS232/422/485

Hole for Kensington lock

HDMI

D-Sub (VGA)

4x USB 2.0

1x Gigabit LAN (RJ45)

2x PS/2 (keyb.+mouse)

3x Audio (Mic, Line in/out)

Hole for Kensington lock

HDMI

DVI-I

2x USB 3.0

2x USB 2.0

2x Gigabit LAN (RJ45)

3x Audio (Mic, Line in/out)

Optical S/PDIF out

RS232 + RS232/422/485

Hole for Kensington lock

Onboard connectors

3x SATA 2.0 (300MB/s)

2x USB 2.0

Clear CMOS jumper

4x SATA 2.0 (300MB/s)

2x USB 2.0

S/PDIF out

Clear CMOS jumper

TPM header (7x2 pin)

3x SATA 2.0 (300MB/s)

2x USB 2.0

Clear CMOS jumper

TPM header (10x2 pin)

External Power adapter

Output: 90W, 19V DC

Input: 100~240VAC

Output: 90W, 19V DC

Input: 100~240VAC

Output: 90W, 19V DC

Input: 100~240VAC

Optional accessories

Vertical stand (PS01)

VESA mount kit (PV02)

Vertical stand (PS01)

VESA mount kit (PV02)

Vertical stand (PS01)

VESA mount kit (PV02)

Product

Specification

Page

7

|

8

June

2012

Mena Computers

Wageningselaan 46=D

3903 LA Veenendaal

|

The Netherlands

Tel

.

+31 (0) 318 518720

sales@shuttleshop.nl

w w w . s h u t t l e s h o p . n l

Shuttle Slim-PC

Barebone

XH61V

Specifications

Chass

i

s

Nettop

PC, slim

X-ty

pe

chassis,

black

Dimensions:

24 x 200 x 72 mm

(LWH)

=

3.5 litres, Weight: 2.2 kg net, 3.5 kg

gross

Front

doors

for

optical

drive

and

front

panel

connectors

Hole for

K

e

n

s

ington

Lock

at

the

back

pan

e

l

Operation

pos

i

tion

horizontal

or

vertical

with the

optional stand

PS01

Storage

Bays

1x for

optical

drive (ODD)

i

n

slimline

f

orma

t

with 12.7 mm

heig

ht

2x

6.35c

m/2.5

"

for

hard

disk or

SSD

(max.

height:

9.5 mm,

upper bay:

12.7

mm)

Two

pre-installed

SATA

cable

s (ODD,

HDD)

and mounting

screws in

clude

d

Mainboard

Chipset

BIOS

Mini-ITX

Mainboard

“FH61V”:

17 x 17

cm

Chipset:

Intel® H61 Express

Chipset

AMI BIOS

in 8Mbit

EEPROM

with

SPI

i

n

terface

All

capacitors are

high quality solid

capacitors

Supports hardware

mon

i

torin

g

and watchdog

fun

c

tionality

Supports

Unified Extensible Firmware

Interface

(UEFI)

**)

Supports resume

after

power

failure

Power

Adapter

External 90W

power

adapte

r

(fan

less)

Input:

100~24

0V

AC, 50/60 Hz

Output:

19V DC, 4.74A, max.

90

W

Internal DC-DC

daughter

board

Processor

Su

pport

Socket

1155

(LGA

1155)

supports

the

second and

third

generation

of

Intel

Core

i3 /

i

5

/ i7 / Pentium /

Celeron processors

with

a power consumption

of up to 65W

T

D

P

-

Codename

"Sandy Bridge", 32nm

process technology

a

n

d

-

Codename

"I

vy Bridge",

22nm process

te

chnology

Not

compatible

with

older Socket-1156

pro

c

essors.

The

Processor

i

n

tegrates

PCI-Express,

memory

co

ntrol

ler

and

the

graphics engine

on the

same

die

(depends

on

processor

t

y

pe)

Please

refer to the

support

list for

detailed processor support

informatio

n.

Heat-pipe

C

oolin

g

Processor cooling

with

heat pipe technologyand

two fans

(6cm)

Memory

Su

pport

2x

SO-DIMM

slots with 204

pins

Supports DDR3-1066/1333/1600

SDRAM

memory

(PC3

-8500/10600/1280

0)

The

maximum memory clock

rate depends

on the

processor

type.

Supports

Dual

Chann

e

l

mod

e

Supports

max. 8 GB per DIMM,

maximum

total size of 16 GB

Supports

two

unbuffered

DIMM

modules

of

1.

5V

Product

Specification

Page

8

|

8

June

2012

Mena Computers

Wageningselaan 46=D

3903 LA Veenendaal

|

The Netherlands

Tel

.

+31 (0) 318 518720

sales@shuttleshop.nl

w w w . s h u t t l e s h o p . n l

Mini-P

CIe

slots

XH61V

features

two

M

i

n

i

PCI Express

expansion

slots:

1) half size,

supports

PCIe 2.0

and

USB

2.0,

e.g.

for

WLAN

cards

[5]

2) full size,

supports

PCIe 2.0,

SATA

3G

and

USB

2.0

e.g.

for

M

i

n

i

SATA (mSATA) fl

ash

memory cards

[6]

Integrated

Graphics

The

features

of the

integrated graphics

fun

c

tion

[3]

depends

on

the used processor

type.

"Sandy

B

r

idge"

processor:

Int

e

l® HD

Graphics 2000/3000,

DirectX

10.1

"Ivy

Bridge"

processor:

Intel® HD

Graphics 2500/4000,

DirectX

11

Maximum

shared memory

siz

e

:

1692MB

Supports

HDMI

,

max.

resolution

up to

1920x1200

@ 60Hz

Supports

DVI,

max.

resolution

up to

1920x1200

@ 60Hz

Supports

D-Sub, max.

resolution

up to

2048x1536

@ 75Hz

(option

a

l

VGA-to-DVI-adapter

required)

Supports

Blu-ray

Stereoscopic

3D

w

i

th

HDMI

1.4a

[1]

Supports

HDCP

fun

c

tion

with

DVI

and

HDM

I

ports

Supports

Full HD

1080p

Blu-r

a

y

(BD)

/

HD-DVD

playback

with

DVI

and

HDMI

ports

Supports Dual-Independent-Display

via

HDM

I

and

DVI-I

p

ort

HDM

I

supports

HD

video

plus

multi-chan

n

e

l

digital

audio

via

a single

cable

Au

di

o

Audio

Realtek®

ALC

662

6-channel

High-Definition

Audio

Three

analog audio connectors

(3.5mm)

a

t

the

Back-Panel:

1) Front

Lin

e

out

(head phone)

2) Rear Surround

li

ne-out

(sh

a

red

with

microphone

i

n

put)

3)

Center

line-out

(shared

with

Lin

e

in

)

Digital

audio output:

S/PDIF

(optical)and

via

HDM

I

Mini-P

CIe

slots

XH61V

features

two

M

i

n

i

PCI Express

expansion

slots:

1) half size,

supports

PCIe 2.0

and

USB

2.0,

e.g.

for

WLAN

cards

[5]

2) full size,

supports

PCIe 2.0,

SATA

3G

and

USB

2.0

e.g.

for

M

i

n

i

SATA (mSATA) fl

ash

memory cards

[6]

Dua

l

Gigabit

LAN

Contro

ll

er

Dual

Realtek

8111E Ethernet

n

e

twork

co

n

t

r

o

ller

(Gigabit)

Supports

10 / 100 /

1.000

MBit/s

operation

W

i

th

two RJ45 ports (dual

n

e

twork)

supports Teaming

[4]

Supports

WAKE

ON

LAN

(WOL)

Supports

network

boot

by

Pr

eboot

eXecution

E

n

viro

nment

(PXE)

Drive

Connectors

3x

Serial-ATA II,

3 Gb/s (300

MB/s)

bandwidth

Supports

Unified Extensible Firmware

Interface

(UEFI)

[2]

Note:

This

barebone

system

comes

with two

pre-installed

SATA

cables:

for

one

2.5"

hard

disk

and

f

or

one optical

slim

drive.

Front

Pa

ne

l

Connectors

M

i

cropho

n

e

input, Audio Line-out

(headph

on

e)

2x

USB

2.0

Power

button

Power

LED

(blue), HDD

LED

(yellow)

Product

Specification

Page

9

|

8

June

2012

Mena Computers

Wageningselaan 46=D

3903 LA Veenendaal

|

The Netherlands

Tel

.

+31 (0) 318 518720

sales@shuttleshop.nl

w w w . s h u t t l e s h o p . n l

Back

P

ane

l

Connectors

DVI-I

connector (supports

VGA

with

optional

adapter)

HDM

I

1.4

connector

[1]

(supports

DVI-D

with

optional

adapter)

2x

USB

3.0, 2x

USB

2.0

2x GigaBit

LAN

(RJ45)

2x RS232

seria

l

ports (5V/12V, 1x

switchable

to RS422 / RS485)

Audio

Lin

e

-in, Audio

Lin

e

-out,

Audio

M

i

c-in

S/PDIF

output

(

o

ptical)

Perforation

for Wireless

LAN

antennas

(2

hol

e

s)

Hole for

Kensington

Lock

Other

Onboard

Connectors

6x

USB

2.0 (two 2x5 pin

header)

-

two of

them are occupied by

the front

panel

USB

ports

2x5 pins

+

3 pins

power

connectors

2x fan

connectors

(4 pin) -

one

is

occupied

for the system

fans

Clear

CMOS

j

u

mper

(2

pin

s

)

Connector

for CMOS

battery

TPM

module header

(2x10 pins LPC in

terface)

2x front

panel connectors

(2x5 pins

each,

f

or

audio and power

button

/

LED)

Accessories

Multi-language

user

guide

Driver

DVD

(

W

i

n

dows

7 32/64 bit, Windows Vista 32/64 bit

and

Windows XP 32 bit)

2x

cable

for

SATA

(preinstalled

for 2.5

HDD/SSD

drive

and optical

slim

drive)

1x 4 pin to

SATA

power

cable

External

power adapter

with

power

cord

CPU

heat-pipe cooling

syste

m

Screws

Optio

n

a

l

Accessories

Vertical

stand

(PS01)

VESA

mount

(PV02)

Conform

i

ty

Cer

t

if

ic

atio

ns

EMI:

FCC, CE,

BSMI,

C-T

i

ck

Safety:

C

B

,

BSM

I

,

ETL

Others: RoHS, Energy

S

t

a

r

V

5.0,

EuP

L

o

t

6

This

device

is

classed

as

a

techn

i

cal

information equipment

(ITE)

in class

B

and

is

intended

for

use

in

livin

g

room

and

office. The CE-mark

approves

the

conformity

by

the

EU-guidelines:

- EMV-guideline 89/336/EWG

electromagnetic

tolerance

- LVD-guideline 73/23/EWG

use

of

electric

devices

within

certain

voltage-limits

[1] HDMI

version

supported

HDMI

1.4 is

o

n

l

y

supported

by all

L

G

A1155

processors.

Some

models support

HDMI

1.3

onl

y

.

[2]

Unified Extensible Firmware

Interface

(UEFI)

-

required

when

booting

from

hard

disks

larger than

2.2

TB

u

n

der

Windows 64 bit

operating

systems such as Windows 7, Windows Vista SP1

and

Windows Server

2008/2003

SP1.

[3

]

In

tegrated

video outputs

(HDM

I

and

DVI

-

I

)

Not all

L

G

A1155

Intel

processors support integrated graphics. Please check

the

specification

of the

used

processor.

If

you want to use the

video outputs,

then

please make

sure, that the

used processor provides integrated graphics.

[4]

Teaming

Modu

s

The

teaming

fun

c

tion

allows you to

group both available n

e

twork

adapters together

to

fun

c

tion

as

a single

adapter

-

a method

of

creatinga

virtual

LAN.

The

benefit

of this

approach

is that it

enables load balancing and

failover.

[5]

Optional

Wireless

LAN

module:

this Slim PC

supportsan optional

WLAN

module,

which

consists

o

f

a

half-size Mini-

PCIe

card

with

IEEE

802.11n

f

u

n

c

tio

n

ality

and an externalantenna

with

appropriate antenna

cable.

[6] mini-SATA

(mS

A

T

A)

not to

be confused

with the "micro

SATA"

connector,

is

a newer

industry

standard

which

converts

the

electrical

SATA

interface

(1.5 or 3.0 Gbit/s) to the

pysical

"Mi

n

i

P

C

I

Express" mini

card

f

orm

factor.

Product

Specification

Page

10

|

8

June

2012

Mena Computers

Wageningselaan 46=D

3903 LA Veenendaal

|

The Netherlands

Tel

.

+31 (0) 318 518720

sales@shuttleshop.nl

w w w . s h u t t l e s h o p . n l

Shuttle Slim-PC

Barebone

XH61V

–Front

and

Back

Panel

Front Panel

4 1 Power Button

1 2 Power LED

5 3 Bay for optical Slim DVD drive

2 (the optical drive is not included)

4 Front door for DVD drive

5 Front door for I/O connectors

36 Two bays for 2.5“hard disk drives or

SSDs

7 2x USB 2.0 ports

4 8 Microphone input

9 Headphone output

5

10 11

12

7 8 9 7

15 17 10

Back Panel

10 Two thumbscrews

11 Hole for Kensington Lock

12 Digital audio: S/PDIF (optical)

13 RS232 serial interface (COM port)

14 RS232 / RS422 / RS485 ser. (COM)

23 15 DVI-I –digital video output

(supports VGA with optional adapter)

16 HDMI –digital video/audio output

17 Dual Gigabit network (RJ45)

13 14 16

36

18 19 20 21 22

6

18 2x USB 3.0

19 2x USB 2.0

20 Microphone input

21 Headphone / line-out

22 Audio line-in

23 Connector for the power adapter

Note: the storage drives (hard disk and

optical slimline drive) are not included in

the delivery of XH61V. For a second 2.5”

drive you will need another SATA cable.

COM port Pin 9 Configuration

Pin 9 is a multi-functional signal. Based on Jumper 3 configuration on the

mainboard, it can be configured as Ring Indicator (RI) or external power supply

with either 5V or 12V voltage level (each COM port separately).
