SICK GRTB18 Manuale utente
GRTB18(S)
Operating Instruction
DE/EN/FR/PT/IT/ES/ZH/JA/RU
8019057.16B5
OPERATING INSTRUCTION
Described product
GR18(S)
GRTB18(S)
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is only
permissible within the limits of the legal determination of Copyright Law. Any modifica‐
tion, abridgment or translation of this document is prohibited without the express writ‐
ten permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
2006/42/EC
NO
SAFETY
8019057.16B5 | SICK
Subject to change without notice 1
Photoelectric proximity sensor
Operating instructions
1Safety notes
■Read the operating instructions before commissioning.
■Connection, mounting, and setting may only be performed by trained specialists.
■Not a safety component in accordance with the EU Machinery Directive.
■UL: Only for use in applications in accordance with NFPA 79. These devices shall
be protected by a 1 A fuse suitable for 30 V DC. Adapters listed by UL with connec‐
tion cables are available. Enclosure type 1.
■When commissioning, protect the device from moisture and contamination.
■These operating instructions contain information required during the life cycle of
the sensor.
2 Correct use
The GRTB18(S) is an opto-electronic photoelectric proximity sensor (referred to as "sen‐
sor" in the following) for the optical, non-contact detection of objects, animals, and per‐
sons. If the product is used for any other purpose or modified in any way, any warranty
claim against SICK AG shall become void.
Photoelectric proximity sensor with background suppression.
8019057.16B5 | SICK
Subject to change without notice 1
Dimensional drawing see page 55.
+–
Sensitivity
Sensitivity
+–
Image: A -2
3 Commissioning
1 Check the application conditions: Adjust the sensing range and distance to the
object or background and the remission capability of the object according to the
corresponding diagram [H] (x = sensing range, y = transition range between the set
sensing range and suppression of the background as a % of the sensing range
(object remission / background remission). Remission: 6% = black , 18% = grey
, 90% = white (referring to standard white as per DIN 5033).
The minimum distance (= y) for background suppression can be determined from
diagram [H] as follows:
Example: x = 40 mm, y = 10% => 10% % of 40 mm = 4 mm. That is, the back‐
ground is suppressed at a distance of > 44mm from the sensor.
6%/90%
18%/90%
90%/90%
25
20
15
10
5
0
mm
(inch) 50
(1.57) 100
(3.94) 150
(5.91) 200
(7.87) 250
(9.84) 300
(11.81)
Distance in mm (inch)
1
2
3
Image: H
2 Mount the sensor using a suitable mounting bracket (see the SICK range of acces‐
sories).
The maximum permissible tightening torque is listed in Table K.
Note the preferred direction of the object relative to the sensor.
3 The sensors must be connected in a voltage-free state (VS = 0 V). The information
in the graphics [B] must be observed, depending on the type of connection:
– Male connector connection: pin assignment
– Cable: core color
2 CORRECT USE
2 8019057.16B5 | SICK
Subject to change without notice
+ (L+)
-(M)
Q
brn
blu
blk
Image: B GRTB18(S)-
x13xx,GRTB18(S)-
x14xx
+ (L+)
- (M)
Q
brn
blu
blk
1
3
4
Image: B-2 -x23xx
+ (L+)
Q
- (M)
brn
wht
blu
Q
blk
Image: B-3 -x11xx,-
x12xx
+ (L+)
Q
- (M)
brn
wht
blu
blk
1
2
3
Q
4
Image: B-4 -x24xx
Only apply voltage / switch on the power supply (VS > 0 V) once all electrical con‐
nections have been completed. The green LED indicator lights up on the sensor.
Explanations of the connection diagram (graphic B):
Switching outputs Q and /Q (according to graphic B):
GRTB18(S)-P (PNP)
GRTB18(S)-F (PNP)
GRTB18(S)-N (NPN)
GRTB18(S)-E (NPN)
L: light switching
D: dark switching
Q: light switching
Q/: dark switching
Q: dark switching/, object will not be detected
4 Align the sensor with the object. Select the position so that the red emitted light
beam hits the center of the object. You must ensure that the optical opening (front
screen) of the sensor is completely clear [E]. We recommend making the adjust‐
ments using an object with a low remission.
Image: E
5
y
x
Image: F
COMMISSIONING 3
8019057.16B5 | SICK
Subject to change without notice 3
Sensor with potentiometer:
The sensing range is adjusted with the potentiometer (type: 270°). Clockwise rota‐
tion: sensing range increased; counterclockwise rotation: sensing range reduced.
We recommend placing the switching state in the object, e. g., see graphic F. Once
the sensing range has been adjusted, the object is removed from the path of the
beam, which causes the background to be suppressed and the switching output to
change (see graphic C).
The sensor is adjusted and ready for operation. Refer to graphics C and G to check
the function. If the switching output fails to behave in accordance with graphic C,
check application conditions. See section Fault diagnosis.
Image: C
Image: G
5 Fault diagnosis
Table indicates which measures are to be taken if the sensor stops working.
4
4 8019057.16B5 | SICK
Q
(PNP)
(NPN)
Q
q1
0
q
1
0
1
0
1
0
Q (PNP)
L1
0
1
0
1
0
1
0
Q (NPN)
L
Q (PNP)
Q (NPN)
D
D
GRTB18(S)-x24xx
GRTB18(S)-x11xx
GRTB18(S)-x12xx
GRTB18(S)-x23xx
GRTB18(S)-x13xx
GRTB18(S)-x14xx
Subject to change without notice
6 Table Fault diagnosis
LED indicator/fault pattern /
LED indicator/fault pattern
Cause /
Cause
Green LED does not light up No voltage or voltage below
the limit values
Measures /
Measures
Check the power supply,
check all electrical connec‐
tions (cables and plug connec‐
tions)
Green LED does not light up Voltage interruptions Ensure there is a stable power
supply without interruptions
Green LED does not light up Sensor is faulty If the power supply is OK,
replace the sensor
Yellow LED flashes Sensor is still ready for opera‐
tion, but the operating condi‐
tions are not ideal
Check the operating condi‐
tions: Fully align the beam of
light (light spot) with the
object. / Clean the optical sur‐
faces . / Readjust the sensitiv‐
ity (potentiometer) / Check
sensing range and adjust if
necessary; see graphic F.
Yellow LED lights up, no object
in the path of the beam
Distance between the sen‐
sor and the background is too
short
Reduce the sensing range,
see graphic F
Object is in the path of the
beam, yellow LED does not
light up
Distance between the sensor
and the object is too long or
sensing range is set too
short
Increase the sensing range,
see graphic F
7 Disassembly and disposal
The sensor must be disposed of according to the applicable country-specific regula‐
tions. Efforts should be made during the disposal process to recycle the constituent
materials (particularly precious metals).
TABLE FAULT DIAGNOSIS 6
8019057.16B5 | SICK
Subject to change without notice 5
8 Maintenance
SICK sensors are maintenance-free.
We recommend doing the following regularly:
•Clean the external lens surfaces
•Check the screw connections and plug-in connections
No modifications may be made to devices.
Subject to change without notice. Specified product properties and technical data are
not written guarantees.
9 Technical data
GRTB18(S)-
Sensing range 3 ... 300 mm
Sensing range max. 3 ... 300 mm1)
Light spot diameter/distance 7 mm / 100 mm
Supply voltage VSDC 10 ... 30 V2)
Output current Imax. 100 mA3)
Max. switching frequency 1,000 Hz4)
Max. response time < 0.5 ms5)
Enclosure rating IP 67
Protection class III
Circuit protection A,B,D6)
Ambient operating temperature -25 °C ... +55 °C
1) Object with 90 % remission (based on standard white DIN 5033)
2) Limit value: operation in short-circuit protection mains max. 8 A; residual ripple max.
5 Vss
3) When UV > 24 V and ambient temperature > 49°C IAmax. = 50 mA.
4) With light / dark ratio 1:1
5) Signal transit time with resistive load
6) A = UV-connections reverse polarity protected
B = inputs and output reverse-polarity protected
D = outputs overcurrent and short-circuit protected
8 MAINTENANCE
6 8019057.16B5 | SICK
Subject to change without notice
Reflexions-Lichttaster
Betriebsanleitung
10 Sicherheitshinweise
■Vor der Inbetriebnahme die Betriebsanleitung lesen.
■Anschluss, Montage und Einstellung nur durch Fachpersonal.
■Kein Sicherheitsbauteil gemäß EU-Maschinenrichtlinie.
■UL: Nur zur Verwendung in Anwendungen gemäß NFPA 79. Diese Geräte müssen
mit einer für 30V DC geeigneten 1A-Sicherung abgesichert werden. Von UL gelis‐
tete Adapter mit Anschlusskabeln sind verfügbar. Enclosure type 1.
■Gerät bei Inbetriebnahme vor Feuchte und Verunreinigung schützen.
■Diese Betriebsanleitung enthält Informationen, die während des Lebenszyklus des
Sensors notwendig sind.
11 Bestimmungsgemäße Verwendung
Die GRTB18(S) ist ein optoelektronischer Reflexions-Lichttaster (im Folgenden Sensor
genannt) und wird zum optischen, berührungslosen Erfassen von Sachen, Tieren und
Personen eingesetzt. Bei jeder anderen Verwendung und bei Veränderungen am Pro‐
dukt verfällt jeglicher Gewährleistungsanspruch gegenüber der SICK AG.
Reflexionslichttaster mit Hintergrundausblendung.
8019057.16B5 | SICK
Subject to change without notice 7
Maßzeichnungen siehe Seite 55.
+–
Sensitivity
Sensitivity
+–
Abb.: A -2
12 Inbetriebnahme
1 Einsatzbedingungen prüfen: Schaltabstand und Distanz zum Objekt bzw. Hinter‐
grund sowie Remissionsvermögen des Objektes mit dem zugehörigen Diagramm
[vgl. H] abgleichen (x = Schaltabstand, y = Übergangsbereich zwischen eingestell‐
tem Schaltabstand und Ausblendung des Hintergrundes in % des Schaltabstands
(Remission Objekt / Remission Hintergrund)). Remission: 6 % = schwarz , 18 % =
grau , 90 % = weiß (bezogen auf Standardweiß nach DIN 5033).
Die minimale Distanz (= y) für die Hintergrundausblendung kann aus dem Dia‐
gramm [vgl. H] wie folgt ermittelt werden:
Beispiel: x = 40 mm, y = 10% => 10% % von 40 mm = 4 mm. D. h. der Hintergrund
wird ab einer Distanz von > 44 mm vom Sensor ausgeblendet.
6%/90%
18%/90%
90%/90%
25
20
15
10
5
0
mm
(inch) 50
(1.57) 100
(3.94) 150
(5.91) 200
(7.87) 250
(9.84) 300
(11.81)
Distance in mm (inch)
1
2
3
Abb.: H
2 Den Sensor an einen geeigneten Befestigungswinkel montieren (siehe SICK-Zube‐
hör-Programm).
Für das maximal zulässige Anzugsdrehmoment, siehe Tabelle K.
Vorzugsrichtung des Objektes zum Sensor beachten [vgl. A].
3 Anschluss der Sensoren muss spannungsfrei (UV = 0 V) erfolgen. Je nach
Anschlussart sind die Informationen in den Grafiken [vgl. B] zu beachten:
– Steckeranschluss: Pinbelegung
– Leitung: Adernfarbe
11 BESTIMMUNGSGEMÄSSE VERWENDUNG
8 8019057.16B5 | SICK
Subject to change without notice
