FDT181 Heat Detector

ProductManual

Overview

Theheat detector FDT181 isanintelligent detector.Itisused for earlyfire detection

inside abuildingandparticularlysuitablefor useinplaceswhere other typesof

detectorsare notsuitablebecausetheycanbe misled bythesmoke, dust andgas

generated duringworkthere.

Characteristics

Withbuilt-inCPU, signalsreceived are processed byintelligent algorithm

Twooperationmodes: A2S/A2R

Automaticallyaddresssettingwithout encoder settingor DIPswitch

All-aroundvisiblealarmindicator

Resistant toenvironment andinterferencefactorssuchashumidity, electro-magnetic

interference, corrosiveandvibration.

CommunicationviaFD18-BUS, polarityfree connection

“Sticker Method”easyfor commissioning

Functions

Thedetectionbehaviorofthedetectorsisinfluenced bythe parameter sets,sothatit

canbe specificallyadjusted tothefire phenomenaandenvironmentalconditionsto

be expected intheenvironment tobe monitored

UniqueIDofeachdetector, controllercanidentifythedetector type accordingtothe

IDandassignaddress

BuildingTechnologies A6V10214490_a_en_--

Firesafetyandsecurityproducts 03.2010

Application

Suitablefor useinplaceswhere theambient temperature canchange rapidlyor

smokedetector are notsuitable

Dust cap protectsthedetector frombeingcontaminated byconstructionwork

Indicator

Thedetector isprovided withaninternalalarmindicator toshowitsoperatingstatus.

(See table

DetectorIndicator

NormalOff

Locate/Test Flashing

AlarmSteadyon

Installation

lEasy andtime-saving mounting

Install thebaseandfinishthewiringduringtheconstructionphase.

1. Point theretainingnest tothepositioningpointer andinsert itintothebase.

2. Turnit clock wiselyuntilitstops.

Uninstallation:

1. Turnit counterclockwiselyuntilitstops.

2. Pullthedetector out.

After all theconstructionisfinished, thedust cap must be takenaway!

Dimensions

In：mm（withbase

Detector

Retainingnest

Base

Positioningpointer

BuildingTechnologies A6V10214490_a_en_--

Firesafetyandsecurityproducts 03.2010

Connectiondiagram

Maintenance

lPerformance test

Recommendation:

Submit alldetectorstoanannualvisualcheck. Detectorsthat are stronglysoiled or

mechanicallydamaged must be replaced.

Anydetectorsshouldbe replaced after 7to10 yearsofservice, independent from

theenvironmentalconditions.

Longtermauxiliarydetectorsshouldbe stored withplasticbag.

Carryoutheat test eachyear.

Teconicaldata

Operatingvoltage 12 …32 VDC

Operatingcurrent (quiescent) 0.26 mA

Activationcurrent 1.2mA

Operatingtemperature 10 ... +50 °C

Storage temperature 20 ... +75 °C

Humidity ≤96%(40±2 ℃)

Communicationprotocol FD18-BUS

Color White, RAL9010

ProtectioncategoryGB4208-93 IP44

Detailsforordering

TypeMaterial No. PartNo. DesignationWeight

FDT181 S54320-F3-A1 100856212 Heat detector 0.064Kg

FDB181 S54320-F1-A1 100856213 Detector base 0.027Kg

A5Q00022001 100566011 FDT181 dust cap

Beijing SiemensCerberusElectronics Ltd.

No.18 XinxiRoadShangdi Information IndustryBase,

Haidian District,Beijing100085 China

Tel.: +1062962255

Fax:+1062987387

www.sbt.siemens.com

©Dataanddesignsubjecttochangewithoutnotice.

DocNo. A6V10214490_a_en_-- Version a ManualFD18

Edition 03.2010
