Siemens Silver WD7205 Manuale utente

WD7005

Silver WD7205

WD7005

Silver WD7205

Operating and installation instructions

Please read this specification carefully before you use the product.

Any failure and losses caused by ignoring the above mentioned items and cautions

mentioned in the operation and installation instruction are not covered by our warranty

and any liability. Please keep all documents in a safety place for future reference. If

you have any doubt, please contact our local service center of dealer.

If you need an English user manual, please download it from siemens web. Or you

can send the E-mail to service department, or you can call up service hot line for free

supply. Thanks!

http://www.siemens-ha.com.cn

[email protected]

生产厂家：中德合资博西威家用电器有限公司

厂址：中国江苏省无锡市高新技术开发区旺庄路６６号

邮编： 214028

4008899999

Disposal Information. . . . . . . . . . . . . . . . . . . . . . .

Environmental Protection/Conservation Issues. .

Your New Washing Machine. . . . . . . . . . . . . . . . .

First Wash Cycle. . . . . . . . . . . . . . . . . . . . . . . . .

Laundry Detergents and Additives. . . . . . . . . . . .

Washing/drying with standard settings. . . . . . . . .

Washing/drying with individual settings. . . . . . . .

When the Programmme has Ended. . . . . . . . . . .

Individual programme. . . . . . . . . . . . . . . . . . . . . .

Cleaning and Care. . . . . . . . . . . . . . . . . . . . . . . .

Troubleshooting Minor Faults. . . . . . . . . . . . . . . .

Customer service. . . . . . . . . . . . . . . . . . . . . . . . .

Programme table. . . . . . . . . . . . . . . . . . . . . . . . .

Installation, Connection and Transport. . . . . . . . .

Technical Data. . . . . . . . . . . . . . . . . . . . . . . . . . .

Package Sheet. . . . . . . . . . . . . . . . . . . . . . . . . .

Safety Precautions and Warnings. . . . . . . . . . . . .

Preparing, Sorting and Loading the Laundry. . . .

Operating Instructions

Installation Instructions

Table of Contents

Appendix

Environmental Protection

Through the economical use of energy, water and de-

tergent, your appliance is kind to the environments as

well as your household budget.

You can increase the economy and environmental

friendliness of your washer-dryer by washing ma-

ximum loads:

refer to page 39 program table

How to save energy:

For small amounts of laundry, the automatic control

system reduces the consumption of both water and

energy. Where possible, use the 60 C Cottons/co-

loureds programme with additional function Inten-

sive Stains instead of the 90 C Cottons/coloureds

programme. The extended washing duration means

that a cleaning result comparable to that of the

90 C programme is achieved using considerably

less energy.

How to save water, energy and detergent:

Avoid using the Pre-wash function when washing

lightly normally soiled laundry.

How to save energy and time:

For lightly soiled laundry, select the short

programme appropriate to the type of textile.

How to save detergent:

Add detergent according to the degree of soiling,

amount of laundry and water hardness, and

observe the detergent manufacture s instructions.

Save energy:

If washing is then to be dried in the appliance, select

the higher spin speed - because the more water that

is spun out of the appliance, the less time and

energy is required to dry it.

Disposal Information

Dispose of packing materials in a responsible manner.

Keep packing materials out of the reach of children.

Packing materials are not toys. Reprocessing and re-

using materials saves raw materials and reduces wa-

ste. All packing materials used are environment frien-

dly and reusable. Cardboard boxes consist of 80% to

100% recycled paper. Plastic wrappings are made

from polythene(PE), the tapes are made from polyp-

ropylene(PP) and the CC-free packing is made from

foamed polystyrene (PS). These materials are pure

hydrocarbon compounds and can be recycled.

The new machine s

packaging

Render the washer-dryer inoperable when it can

no longer be used Remove the plug from the so-

cket and cut off the power cable. Destroy the catch

on the porthole door. Prevent children at play from

being locked in and risking death by suffocation.

The old machine contains valuable materials which

should be recycled. Please make your contribution

to the environment by assisting with proper dispo-

sal or recycling.

Your old machine

Precautions and Warnings

Please read the enclosed documents carefully

before using the Washer-dryer for the first time.

They contain important information on the insta-

llation, use and safety of the machine.

Before using for the first time:

The manufacturer does not accept liability if these

instructions are not followed.

Please contact an authorized technician to install

the machine and instruct the using method.

Please keep all documents in a safe place for

future reference.

Install the Washer-dryer in accordance with the

instructions (page 41-49). Remove the transit bolts

and keep them in a safe place.

The washing machine must be installed and

operated in a room with the drain.

When heating, the maximum current of the wash-

ing machine is 10A,so please make sure that the

power supply system(voltage; current and the

cable) is applicable to the load of the applied

appliance.

In order to ensure your safety, you must plug the

cable into a socket which connected to earth. And

please check your socket to make sure that it is

connected with reliable earth correctly.

If the Washer-dryer is visibly damaged, do not

connect it up. If you are in doubt, contact your

customer service representative or dealer.

This Washer-dryer use thread connection water

inlet hose, connect it to the water tap together with

the machine according to the require of page 45.

(carry out by an authorized technician)

When washing

and drying:

Operate the Washer-dryer with cold tap water only.

Your Washer-dryer is designed for domestic use

only, i.e. For washing machine-washable textiles

in a detergent solution.

Never use flammable; explosible and/or poisonous

solvents such as gasoline; alcohol etc. As the wa-

shing lotion. Please only use the lotions suitable

for using in washing machine available in

the market.

Never wash the carpet in the washing machine.

Kepp children and pets away from the washing

machine.

Due to the use of the condensation principle in

drying, please keep the connected water tap open

during the drying process.

Exercise caution when pumping out hot detergent

solution.

Never open the door when drying.

When the program

has ended: When the program has ended:

The End is indicated(If you select no final spin

function, see page 27).The buzzer of machine

sounds(the duration is 10 minutes) to remind the

user that the programme has ended. Open the

loading door after cutting the power of machine.

After the program has ended, please cut the supply

of power and water immediately.

Taking care of your

machine:

When transporting

the machine:

Do not lean against the door.

Do not climb onto the washing machine.

Do not expose the machine in the place with

causticity or explosibility gas.(e.g. dust, steam

and gas, etc.)

Do not install the washing machine in a bath-

room or a room very wet.

Insert the transit bolts by technician.

Drain any water left in the machine.

Take care when moving the machine.

Do not lift the machine by any of the protruding

parts,and the loading door.

Please close the door gently, if the door can not be

closed, please check if the laundry are balanced.

Open the loading door and close it Drain washing solution

if necessary.

Filling laundry detergent

and/or additive dispensers.

Chamber I:

Detergent for pre-wash,starch,

or pre-soaking agent.

Chamber II:

Detergent for main washing period,

water softener, blench and stain-

removing salt.

Chamber :

Additives, e.g. fabric softener or

former(Do not exceed Max )

Your new washer-dryer

Control Panel

For starting the wash/dry cycle

(program must have been

selectd).

Start button Programme selector

For switching the washer-dryer on and off and for

selecting the program. Can be rotated in either

direction. If rotate it during the washing/drying,

the program will be stopped. The program

sequence is electronically controlled.

Buttons for additional options

(In addition to the programme if

required)

Intensive Stains: extend the

washing duration

Extra Rinse: additional rinsing cycle

Less Ironing: gentle spin

Prewash: actuate prewash

Additional options can be combined.

The indicator lights of the buttons

come on if the additional options

are active.

Switching off the additional option:

Press the button again. Indicator

light goes out.

Button

Selects the the start time(delays the

start of the program).

Selects the spin speed or no final spin.

Display pannel

Indicates the settings which have

been selected(e.g. Spin speed, Time

delay, Childproof lock, Maximum load)

Select the drying time

Z

q

5.2kg*

1000rpm*

－－－*

1:00*

1 h*

－－－

E02*

120min*

Display panel Display Notes

Prewash On if selected

Washing Not on if rinse, spin or

drain additional programme

was selected

Rinse Not on if spin or drain

additional programme was

selected

Final spin/Empty Not on if a programme with

the --- setting(without

final spin)

Progress bar For the programme status

Drying Not on if dry programme

or dry time was selected.

On if too much detergent

dispensed

On if selected

Not on if rinse,spin or

drain additional programme

was selected

Overdosage

Childproof lock

Maximum load

Fan Not on if dry programme or

dry time was selected

Spin speed or

no final spin

Maximum spin speed of the

programme or selected speed

Spin speed or

no final spin

Drying time

Start time

Selected drying time

Selected start time

Other displays at this location:

Programme duration Expected programme duration

End of programme or

See page 33

End of programme without final spin or

Fault display

* Examples of the display, it will be changed

according to your selected programme.

programme status

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Siemens Rondella

Siemens

Siemens WM6HXK76NL Manuale utente

Siemens

Siemens WM14VMH4GB Manuale utente

Siemens

Siemens WM14UT71GB Manuale utente

Siemens

Siemens WM14N2M8GR Manuale utente

Siemens

Siemens iQ300 iSensoric WM14N202GB Manuale utente

Siemens

Siemens WAU28S80GB Manuale utente

Siemens

Siemens WM14UT08GR Manuale utente

Siemens

Siemens WM14N2G8 Manuale utente

Siemens

Siemens WM10N159IL Manuale utente

Siemens

Siemens WG44G20XES Manuale utente

Siemens

Siemens WM06A060HK Series Scheda tecnica

Siemens

Siemens WM16Y849II Scheda tecnica

Siemens

Siemens WM07A160IN Series Scheda tecnica

Siemens

Siemens WM16W468DN Scheda tecnica

Siemens

Siemens WM14U940 Series Scheda tecnica

Siemens

Siemens WM14LRHEDN Manuale utente

Siemens

Siemens WM14W750GB Manuale utente

Siemens

Siemens WM14Y790EU Scheda tecnica

Siemens

Siemens WA14LQHVZA Manuale utente

Siemens

Siemens WM14UTK8GR Manuale utente

Siemens

Siemens WM12S441ME Manuale utente

Siemens

Siemens WG42A1X0GC Manuale utente

Siemens

Siemens WA14LPHSZA Manuale utente

Siemens

Siemens Washing machine Manuale utente

Manuali Rondella popolari di altre marche

Tricity Bendix

Tricity Bendix AW 1000 W Guida del prodotto

Panasonic

Panasonic NA-F60L5WRB Manuale utente

GE WSLP1500 Manuale

Electrolux

Electrolux EWF1284EDW Manuale utente

Bosch

Bosch WAN2829BSN Manuale utente

LG TV2516DV3B Manuale utente

LG TH2517DSAV Manuale utente

VESTEL

VESTEL CMH-XL 7510 TE Manuale utente

AEG

AEG 74335 Manuale operativo

Johnson

Johnson JWF721A Manuale utente

Beko

Beko WTE7604XLW0 Manuale utente

Danby

Danby DTT100A1WDB Istruzioni per il montaggio

Amica

Amica WA 14 Ex Manuale utente

Daewoo

Daewoo DWD-F1222 Manuale utente

Bosch

Bosch WAS28461AU Manuale utente

Miele

Miele PW 6080 Vario Manuale utente

Finlux

Finlux FLX108CF220 Manuale utente

Whirlpool

Whirlpool 3LBR5132AN0 Manuale utente
