Sierra Designs Clip Flashlight 2 Guida alla configurazione

STEP 1: Find an even

piece of ground; be sure

the area is clear of

debris. Lay out your tent

as shown. Stake the 4

corners (circled).

STEP 2: Assemble poles.

Insert long pole into

grommets at front of tent

and short pole into

grommets at rear of tent.

Congratulations on the purchase of your new Sierra Designs tent! In order to familiarize yourself with your new tent, we recommend

you “test pitch” it before embarking on your wilderness adventure.

PACKAGE INCLUDES: Tent Body, Rain Fly, 2 Poles, 4 Guy Cords, 9 Hex Peg Stakes, 1 Pole bag with attached stake bag.

STEP 3: Connect Tent Lite Hook to poles.

STEP 5: Connect the velcro loops on the underside of the ﬂy

to the rear and front hoop poles. (6 total)

STEP 6: Attach grommets/webbing on the sides of the

ﬂy to the pole tips; adjust the tension locks. Stake out

the vestibule and rear. Admire your new tent!

Clip Flashlight 2 / Light Year 1

PITCHING INSTRUCTIONS

SR Buckle

Tent Lite Hook

Long Pole

Short Pole

Velcro Loop

Tension Lock

STEP 4: Lay the rain ﬂy over the tent connecting the side-release

(SR) buckles at the rear of the tent. NOTE: clip the gray male SR

buckle to the gray female SR buckle and yellow to yellow to

ensure ﬂy is put on correctly.

USING YOUR TENT

GUYING OUT YOUR TENT: Your tent

includes guy out loops, guylines, and

stakes. It is good practice to always

guy out your tent, but is absolutely

necessary when it’s windy.

OPEN AWNING SETUP: The

vestibule panel on your tent can be

conﬁgured to provide awning

coverage in front of the door.

1. Tie guylines to yellow webbing

loops on vestibule panel corners.

2. Insert trekking pole tips through

yellowy webbing loops.

3. Stake out guylines

STRING LOCKS: The corner points

of your tent feature String Locks

providing a range of stake out

options. Lift up on the tab to

decrease tension. Pull on the

knotted end to increase tension.

Clip Flashlight 2 / Light Year 1

USING YOUR TENT

Use the black LINE-LOK to adjust the

length of the guy line.

Guy out your tent where shown below to prevent pole

rotation/breakage during high winds.

Stake out the end of the guy

line into the ground.
