SIIG CE-H27611-S1 Manuale utente

Features

• Support HDCP 1.3

• Build-in EDID, resolution up to 1080p@60Hz

• HDMI wireless transmission distance up to

656ft/200m. (In an open environment

without Wi-Fi interference.)

• Support one transmitter and multiple

receivers, up to 4 receivers.

• Support one-way IR extend

• Support PCM 2ch audio

• 5G Wireless connectivity

Package contents

1. Wireless HDMI Transmitter

2. Wireless HDMI Receiver

3. Power adapter 12V/1A x2

4. 5G WiFi antenna x4

5. IR Emitter Cable (For TX IR out)

6. IR Receiver Cable (For RX IR in)

7. Quick start guide

Layout

1. DC Power jack:

connect to power adapter

DC 12V/1A

2. Power LED:

3. RESET: Restore factory settings after long

press for 5s, and require to pair again

4. HDMI In: Connect to HDMI source

5. Loop Out: Connect to HDMI display

6. IR Out: Connect to IR Emitter Cable

Transmitter

Receiver

1. DC Power jack:

connect to power adapter

DC 12V/1A

2. Power LED:

3. RESET: Restore factory settings after long

press for 5s, and require to pair again

4. HDMI Out: Connect to HDMI display

5. IR In: Connect to IR Receiver Cable

1 2 3 4 5

6

1 2 3 4

5

Full HD Wireless HDMI

Extender with Loopout & IR Kit

Quick Start Guide

04-1368B P/N: CE-H27611-S1

Support

For more info or tech support

http://www.siig.com/support

Oct, 2022 Copyright © 2022 by SIIG, Inc. All rights reserved.

Dear Valued Customer

WE REALLY

APPRECIATE

YOUR PURCHASE

~thank you~

Pairing Instruction

1. Power on the TX & RX

2. Wait for 30 sec

3. Using an HDMI cable, Connect the TX input

on the Transmitter to the RX output on the

Receiver to be paired.

4. Wait for 10 sec

5. Remove the HDMI cable and power

from the RX and TX

6. Connect RX output into your display and

Connect the TX into your video source

7. Power on the RX & TX.

Application
