Silvercrest SHLF 2000 A1 Manuale utente

FAN HEATER WITH REMOTE CONTROL

SHLF 2000 A1

IAN 74284

FAN HEATER WITH

REMOTE CONTROL

Operating instructions

VÄRMEFL ÄKT MED

FJÄRRKONTROLL

Bruksanvisning

HEIZLÜFTER MIT

FERNBEDIENUNG

Bedienungsanleitung

KAUKO-OHJATTAVA

KUUMAILMAPUHALLIN

Käyttöohje

VARMEBLÆSER MED

FJERNBETJENING

Betjeningsvejledning

RP74284_Heizluefter LCD_FB_Cover_LB3.indd 2 27.04.12 10:01

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Be sure to note the fold-out page.

Suomi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Huomioi taittosivu

Svenska . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Beakta utvikssidan

Dansk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Læs den udklappelige side

Deutsch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Bitte beachten Sie die Ausklappseite

SHLF 2000 A1_12_V1.4_GB_FI_SE_DK_DE

RP74284 HL mit FB LB3 Seite 1 Freitag, 25. Mai 2012 3:18 15

345

15 14

RP74284 HL mit FB LB3 Seite 1 Freitag, 25. Mai 2012 3:18 15

RP74284 HL mit FB LB3 Seite 2 Freitag, 25. Mai 2012 3:18 15

SHLF 2000 A1

Contents

1. Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. Names of parts (see fold-out page). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3. Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4. Safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

5. Unpacking, setting up and inserting the battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

6. Operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

7. Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

8. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

9. Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

10. HOYER Handel GmbH Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Congratulations on the purchase of your

new product.

You have selected a high-quality product.

The operating instructions are a constituent

part of this product. They contain important

information about safety, use and disposal.

Familiarize yourself with all the operating

and safety instructions before using the

product. Use the product only as described

and for the stated spheres of application.

If you pass the product on to a third party,

always pass on all the documentation as

well.

1. Description

1.1 Intended purpose

This SilverCrest SHLF 2000 A1 fan heater

may be used to heat dry rooms.

This appliance is intended for private use

and is not suitable for commercial purposes.

The appliance is suitable for providing

auxiliary heating. It is less suitable for use

on its own to heat large spaces.

The appliance is ﬂoor standing only.

1.2 Scope of supply

• 1 fan heater

• 1 remote control

• 1 CR2032 button cell

• 1 set of operating instructions

1.3 Symbols on the appliance

The adjacent symbol

warns

against covering the appliance as

this could cause a build up of heat

leading to damage and the risk of

ﬁre.

RP74284 HL mit FB LB3 Seite 3 Freitag, 25. Mai 2012 3:18 15

2. Names of parts

(see fold-out page)

Warning symbol - “Do not cover”

Control panel

Air outlet

Compartment for remote control

Handle

Air inlet

Temperature sensor

Mains switch

Base

Display

Function selector

Increase temperature

Reduce temperature

Infrared receiver

Increase minutes

Increase hours

Swivel function

Indicator light

Remote control

Increase temperature

Swivel function

Reduce temperature

Function selector

Increase minutes

Increase hours

3. Technical data

Power supply: 220 - 240 V~/50 Hz

Output: 1,000/2,000 watts

Protection class: II

Battery for remote control: CR2032/3 V

Ambient conditions: 0 °C to +40 °C, max. 85 % relative humidity

4. Safety information

4.1 Terms used

The following signalling terms are found in

these Operating Instructions:

Warning!

High risk. Disregarding the warning

may cause injury to life and limb.

Caution!

Medium risk. Disregarding the warning may

cause damage to property.

Note:

Low risk. Circumstances that should be taken

into account when dealing with this

appliance.

4.2 General information

• Before using the appliance, be sure to

read these Operating Instructions carefully.

They are a component part of the

appliance and must be available at all

times.

• Use the appliance only for the purpose

described (see “1.1 Intended purpose” on

page 3).

• Check whether the mains voltage (see

type plate on the appliance) agrees with

your mains voltage.

• This device is not intended to be used by

individuals (including children) with

RP74284 HL mit FB LB3 Seite 4 Freitag, 25. Mai 2012 3:18 15

SHLF 2000 A1

limited physical, sensory or mental

capabilities or with a lack of experience

and/or lack of knowledge, unless

supervised by a person responsible for

their safety or they have received

instructions from such a person as to

how to use the device. Children should

always be supervised to ensure that they

do not play with the device.

• If there should be any malfunctions, the

appliance may only be repaired by our

Service Centre.

• The appliance must only be set up on a

ﬁrm, level, dry and non-ﬂammable surface.

• Check that the power socket is easily

accessible so that you can pull out the

mains plug quickly if necessary.

4.3 Protection against electric shock

Warning!

The following safety

information is intended to protect

you against electric shock.

• Only plug the appliance into a correctly

installed, earthed wall socket.

• Do not use the appliance if it has fallen

on the ﬂoor, received a hard blow or

fallen into water. In this case, please

contact our Service Centre. The contact

data can be found in “Service Centre”

on page 13.

• The appliance must not under any

circumstances be used if it is damaged.

Have the device repaired in such cases

by a qualiﬁed specialist. The contact

data can be found in “Service Centre”

on page 13.

• If the mains cable for this appliance is

damaged, it must be replaced by the

manufacturer or a person with similar

qualiﬁcations in order to avoid a

hazard.

• Never use the appliance in the

immediate vicinity of a sink, bath tub,

shower or swimming pool as splashes

might enter the appliance.

• Water or other liquids must never be

allowed to enter the appliance. For this

reason:

–never use outdoors;

–never place containers ﬁlled with

liquid, such as drinking glasses, vases

etc. on the appliance;

–never use in a very damp environment

such as a bathroom.

If nonetheless liquid does enter the

appliance, unplug the mains plug

immediately and have the appliance

repaired by a qualiﬁed specialist. The

contact data can be found in “Service

Centre” on page 13.

• Never insert ﬁngers or any objects

through the protective guards into the

inside of the appliance.

• Never touch the appliance, the mains

cord or the mains plug with moist hands.

• Always pull the mains cord out by the

plug. Never pull it by the cord itself.

• Ensure that the mains cable is not

kinked, twisted or crushed.

• Ensure that the mains cable is not

damaged on sharp edges.

• Keep the mains cord away from hot

surfaces (such as stove eyes).

• If you are not using the appliance for a

prolonged period of time, remove the

plug from the wall socket. Only then is

the appliance completely free of current.

• You should avoid using extension cords.

This is only allowed under very

particular conditions:

–The extension cord has to be suited for

the appliance's amperage.

–The extension cord must not be

installed "loose": it must not be

possible to trip over it or within the

reach of children.

RP74284 HL mit FB LB3 Seite 5 Freitag, 25. Mai 2012 3:18 15

–The extension cord must not by any

means be damaged.

–No other devices other than this

appliance must be connected to the

mains socket, as otherwise overloading

of the power supply network could

occur (multiple sockets are not

allowed!).

• The appliance must not be operated with

an external time switch or separate

remote control system, such as a wireless

remote control socket.

4.4 Protection against the danger of

ﬁre

Warning!

As the appliance works

at high temperatures, please

observe the following safety

information to prevent ﬁre.

• While the appliance is operating, there

must be no ﬂammable objects (e.g.

curtains, paper) in the immediate vicinity

of the appliance.

• Never use the appliance to dry textiles

or other items on, over or in front of the

appliance.

• To avoid overheating, the appliance must

never be covered.

• When setting up the appliance, maintain

a minimum distance of 1.5 m from other

appliances and the wall.

• Never operate the appliance in rooms

where there is a risk of explosion or in

the vicinity of ﬂammable gases or

liquids.

• The appliance must never be placed

immediately beneath a wall socket, as

the heat it generates could damage the

electrical installation.

• Always check that air can freely enter

and escape. Heat might otherwise build

up inside the appliance.

• Never leave the appliance running when

it is unattended. The presence of odour

is almost always an indication of

damage. If you notice any such odour,

unplug the mains plug immediately and

have the appliance inspected. The

contact data can be found in “Service

Centre” on page 13.

4.5 Protection against injury

Warning!

To avoid injury, please

observe the following information.

• Ensure that it is not possible for anyone to

trip over or to get caught up in or step on

the mainscable.

• Stay sufﬁciently far from the appliance to

ensure that the fan cannot suck hair or

items of clothing into the appliance.

• Once hot, if you wish to transport the

appliance, switch it off, pull out the

mains plug, and wait until the appliance

has cooled down. Otherwise you could

burn yourself on the hot surface.

4.6 For the safety of your child

Warning!

Children often cannot

assess dangers correctly and are

injured as a result. Please therefore

observe the following:

• This product may only be used under

adult supervision to ensure that children

do not play with the appliance.

• Always take care to ensure the

appliance is kept out of the reach of

children at all times.

• The remote control contains a button cell.

Ensure that it is kept out of the reach of

children at all times and is not swallowed.

Ingested batteries can be highly

dangerous. Obtain medical assistance

immediately if the battery is swallowed.

RP74284 HL mit FB LB3 Seite 6 Freitag, 25. Mai 2012 3:18 15

SHLF 2000 A1

• Ensure that the packing foil does not

become a deadly trap for a child.

Packing foils are not toys.

4.7 Handling batteries

Warning!

To prevent a risk of explosion, nor-

mal batteries must not be charged,

heated or disposed of by burning.

• Never try to open the battery.

To prevent injury, if battery acid has

leaked avoid contact with skin, eyes and

mucous membranes. In the event of

contact with the acid, rinse the affected

areas immediately with plenty of clean

water and contact a doctor at once.

Caution!

To avoid damaging the product

and ensure it functions correctly, please

note:

• Use exclusively type CR2032 batteries.

4.8 Material damage

Caution!

To avoid material damage, please

observe the following requirements.

• Never try to revolve the appliance

manually as this might damage the

motor.

• Remove the battery from the remote

control if you are not using it for a

prolonged period of time. A leaking

battery could damage the remote

control.

5. Unpacking, setting up and inserting the battery

5.1 Setting up the appliance

Note!

As the appliance and heating coils

are supplied with a thin ﬁlm of grease, there

might be a

small

amount of smoke and

odour the ﬁrst time the appliance is used.

This is not harmful and will stop after a short

while. Ensure meanwhile that there is

sufﬁcient ventilation.

1. Unpack the appliance from the

packaging.

2. Remove the transport packaging.

Note:

There is a piece of corrugated

cardboard positioned between the

appliance and the base

. This must also

be removed.

3. Check that the appliance shows no signs

of damage.

Warning!

Ensure that there is

sufﬁcient distance from the wall,

ﬁxtures and other appliances. The

distance must be at least 1.5 m to

exclude the risk of ﬁre.

4. Select a location that complies with the

safety information (see “4. Safety

information” on page 4).

5. Select a location where the ﬂow of hot

air is not directly aimed at people,

animals or plants.

6. Plug the mains plug into a wall socket

that complies with the technical data.

Note:

The appliance consumes up to

10 amperes of current (2,000 watts). If

you have plugged other power

consumers into the same circuit, check

that the maximum load for the installed

fuse is not exceeded, as otherwise the

fuse will trip.

RP74284 HL mit FB LB3 Seite 7 Freitag, 25. Mai 2012 3:18 15

5.2 Inserting the battery

If the appliance is new or the battery in the

remote control is ﬂat, a new type CR2032

battery must be inserted.

1. Press the catch

towards the

middle and pull

out the battery

compartment.

2. Remove the old battery if present.

Note:

Please observe the instructions for

disposal (see “9.2 Disposable/

rechargeable batteries” on page 11).

3. Insert a new battery.

Note:

Ensure the correct polarity (+/–)

when inserting the battery. The correct

polarity is marked on the battery

compartment. The negative pole of the

battery must point upwards.

4. Slide the battery compartment back in

again.

6. Operating

6.1 Displays

The selected function is shown in the display

Swivel function is switched on

Automatic mode. The appliance

automatically adjusts the heat output to

the room temperature. The appliance

switches off as soon as the room

reaches the required temperature.

Low heat. The appliance operates at

1000 watts

High heat. The appliance operates at

2000 watts

Operating time

Display of room temperature

Display of set required temperature

As soon as the appliance is working the

indicator light

comes on.

6.2 Remote control

The appliance can be operated using the

control panel

or the remote control

The numbers in the text below refer to the

control panel

and

the remote control

6.3 Switching the appliance on and

off

1. Insert the mains plug into a wall socket

that complies with the technical data (see

“3. Technical data” on page 4).

2. Set the mains switch

Ito switch the

appliance on.

The mains switch 8and the display 10

light up.

3. To switch the appliance off completely,

set the mains switch 8to 0.

–

ABCD

RP74284 HL mit FB LB3 Seite 8 Freitag, 25. Mai 2012 3:18 15

Altri manuali per SHLF 2000 A1

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Silvercrest Stufa

Silvercrest

Silvercrest SKT 2300 A1 Manuale utente

Silvercrest

Silvercrest SWW 1500 A1 Manuale utente

Silvercrest

Silvercrest SOR 1500 D3 Manuale utente

Silvercrest

Silvercrest SHL 2000 A1 Manuale utente

Silvercrest

Silvercrest SKHD 1800 A1 Manuale utente

Silvercrest

Silvercrest 90853 Manuale utente

Silvercrest

Silvercrest SHLF 2000 D3 Manuale utente

Silvercrest

Silvercrest SOR 1500 A1 Manuale utente

Silvercrest

Silvercrest 74200 Manuale utente

Silvercrest

Silvercrest STHL 2000 A1 Istruzioni per l'installazione

Silvercrest

Silvercrest SOR 2400 D2 Guida alla risoluzione dei problemi

Silvercrest

Silvercrest SWW 1500 A1 75784 Manuale utente

Silvercrest

Silvercrest SHLF 2000 C1 Scheda informativa del prodotto

Silvercrest

Silvercrest SKT 2000 A1 Manuale utente

Silvercrest

Silvercrest SKT 2300 A1 Manuale utente

Silvercrest

Silvercrest SHLF 2000 D1 Manuale utente

Silvercrest

Silvercrest SHLF 2000 A1 Manuale utente

Silvercrest

Silvercrest SHLF 2000 D2 Manuale utente

Silvercrest

Silvercrest SHH 1200 C1 Scheda informativa del prodotto

Silvercrest

Silvercrest SKD 2300 A1 Manuale utente

Silvercrest

Silvercrest SKHL 1800 A1 Manuale utente

Silvercrest

Silvercrest SKT 2000 A1 Manuale utente

Silvercrest

Silvercrest LHL 2000 B1 Manuale utente

Silvercrest

Silvercrest SHLF 2000 A1 Manuale utente

Manuali Stufa popolari di altre marche

oventrop

oventrop Regucor Series Manuale utente

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuale utente

ELMEKO

ELMEKO ML 150 Manuale utente

BN Thermic

BN Thermic 830T Manuale utente

KING

KING K Series Guida

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guida rapida

Well Straler

Well Straler RC-16B Manuale utente

EUROM

EUROM 333299 Manuale utente

Heylo

Heylo K 170 Manuale utente

Eterna

Eterna TR70W Manuale utente

Clarke

Clarke GRH15 Manuale di istruzioni

IRSAP

IRSAP The Radiator Company Ovali Manuale utente

Empire Heating Systems

Empire Heating Systems WCC65 Manuale utente

Wetekom

Wetekom 92 86 43 Manuale utente

Desa

Desa SPC170-F Manuale utente

Watlow

Watlow Watrod Electric Tubular Heaters Manuale utente

Haverland

Haverland ECO-DRY GPS Series Manuale elenco delle parti

Stelpro

Stelpro ASILVC2060 Series Manuale utente
