Silvercrest SSMW 750 D1 Manuale utente
IAN 317891_1901
OWIM GmbH & Co. KG
Stiftsbergstraße 1
DE-74167 Neckarsulm
GERMANY
Model-Nr.: HG05427
Version: 06/2019
Page size: 143 mm x 210 mm done by Impala Services Limited
143 mm 143 mm
IAN 317891_1901
SANDWICH TOASTER SSMW 750 D1
SANDWICH TOASTER
Operation and safety notes
SZENDVICSSÜTŐ
Kezelési és biztonsági utalások
PEKAČ ZA SENDVIČE
Navodila za upravljanje in varnostna opozorila
SENDVIČOVAČ
Pokyny pro obsluhu a bezpečnostní pokyny
TOASTOVAČ
Pokyny pre obsluhu a bezpečnostné pokyny
SANDWICHMAKER
Bedienungs- und Sicherheitshinweise
143 mm 138 mm
138 mm
GB Operation and safety notes Page 5
HU Kezelési és biztonsági utalások Oldal 18
SI Navodila za upravljanje in varnostna opozorila Stran 31
CZ Pokyny pro obsluhu a bezpečnostní pokyny Strana 44
SK Pokyny pre obsluhu a bezpečnostné pokyny Strana 57
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 70
143 mm138 mm
8
5
6
7
321
4
111213
9
10
143 mm 143 mm
143 mm
5GB
Warnings and symbols used ............................................. Page 6
Introduction ................................................................ Page 6
Intended use.................................................................. Page 6
Scope of delivery.............................................................. Page 7
Description of parts ............................................................ Page 7
Technical data ................................................................ Page 7
Safety instructions......................................................... Page 7
Before first use ............................................................. Page 10
Assembly ................................................................... Page 10
Operation................................................................... Page 11
Grilling sandwiches ............................................................ Page 11
Grilling ...................................................................... Page 11
Baking waffles ................................................................ Page 12
Recipes ...................................................................... Page 12
Tuna sandwich ................................................................ Page 12
Turkey sandwich............................................................... Page 13
Belgian waffles................................................................ Page 13
Blueberry waffles .............................................................. Page 13
Ham and cheese waffles ........................................................ Page 14
Brownie Belgian waffles......................................................... Page 14
Shrimp and plum kebabs ........................................................ Page 15
Cleaning and care ......................................................... Page 15
Troubleshooting............................................................ Page 16
Storage ..................................................................... Page 16
Disposal..................................................................... Page 16
Warranty ................................................................... Page 17
6 GB
Warnings and symbols used
The following warnings are used in this user manual and on the packaging:
DANGER! This symbol in combination
with the signal word “Danger” marks a
high-risk hazard that if not prevented could
result in death or serious injury.
Voltage (alternating current)
Hertz (supply frequency)
Watts
WARNING! This symbol in combination
with the signal word “Warning” marks a
medium-risk hazard that if not prevented
could result in death or serious injury.
NOTE: This symbol in combination
with “Note” provides additional useful
information.
Use the product in dry indoor spaces only.
CAUTION! This symbol in combination
with the signal word “Caution” marks a
low-risk hazard that if not prevented could
result in minor or moderate injury.
Danger – risk of electric shock!
Caution, hot surface
This appliance is classified as protection
class I and must be connected to a
protective ground.
Food safe. This product has no adverse
effect on taste or smell.
The exchangeable plates
11
,
12
and
13
are dishwasher-safe.
SANDWICH TOASTER
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
The instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the product as
described and for the specified applications. If you
pass the product on to anyone else, please ensure
that you also pass on all the documentation with it.
Intended use
This product is designed for making waffles,
sandwiches, and for grilling food. Do not use it for
any other purpose.
This product is only intended for private household
use, not for commercial purposes.
The manufacturer accepts no liability for damages
caused by improper use.
7GB
Scope of delivery
After unpacking the product, check if the delivery
is complete and if all parts are in good condition.
Remove all packing materials before use.
1x Sandwich toaster
3x Exchangeable plate sets
1x Instruction manual
Description of parts
1Lock
2Red indicator (power)
3Green indicator (ready)
4Power cord with power plug
5Power cord retainer
6Heating element
7Large hook catches
8Release lever
9Outer catch (small)
10
Inner catch (large)
11
Sandwich plate (upper and lower plate)
12
Grill plate (upper and lower plate)
13
Waffle plate (upper and lower plate)
Technical data
Input voltage: 220–240 V~, 50/60 Hz
Power consumption: 750 W
Protection class: I
TÜV SÜD / GS-certified
Safety instructions
BEFORE USING THE PRODUCT,
PLEASE FAMILIARISE
YOURSELF WITH ALL OF THE
SAFETY INFORMATION AND
INSTRUCTIONS FOR USE! WHEN
PASSING THIS PRODUCT ON TO
OTHERS, PLEASE ALSO INCLUDE
ALL THE DOCUMENTS!
In the case of damage resulting from
non-compliance with these operating
instructions the warranty claim
becomes invalid!
No liability is accepted for
consequential damage! In the case
of material damage or personal
injury caused by incorrect handling
or non-compliance with the safety
instructions, no liability is accepted!
Children and persons with
disabilities
m WARNING! RISK OF LOSS
OF LIFE OR ACCIDENT TO
INFANTS AND CHILDREN!
Never leave children
unsupervised with the packaging
material. The packaging
material represents a danger of
suffocation.
Children frequently underestimate
the dangers. Always keep
children away from the
packaging material.
8 GB
This product can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities, or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the product in
a safe way and understand the
hazards involved.
Children shall not play with the
product.
Cleaning and user maintenance
shall not be made by children
unless they are older than 8 and
supervised.
Keep the product and its cord
out of reach of children less than
8 years.
Intended use
m WARNING! Misuse may
lead to injury. Use this product
solely in accordance with these
instructions. Do not attempt to
modify the product in any way.
Electrical safety
m DANGER! Risk of electric
shock! Never attempt to repair
the product yourself. In case of
malfunction, repairs are to be
conducted by qualified personnel
only.
DANGER! Risk of burns!
During use the product gets hot.
Do not touch the product while in
use nor immediately after use.
m WARNING! Risk of electric
shock! Do not immerse the
product in water or other liquids.
Never hold the product under
running water.
m WARNING! Risk of electric
shock! Never use a damaged
product. Disconnect the product
from the power supply and
contact your retailer if it is
damaged.
The product is not to be used if
it has been dropped, if there are
visible signs of damage.
The product is powered at all
times while it is connected to the
power supply.
