MZM-1 Mini Zoom Mic Instruction sheet
Battery Installation: The MZM-1 zoom microphone requires 1
AAA battery. To insert the battery:
1. Unscrew the knob on the end of the microphone.
2. Remove the battery cover as shown.
3. Insert battery according to polarity markings
in the battery compartment.
4. Replace the battery cover and
knob.
To operate the MZM-1:
1. Install 1 AAA battery (as shown below.)
2. Slide the rubber insulated shoe mount onto the camcorder
and tighten by turning the adusting wheel clockwise.
3. Plug the audio jack into the mic input of your camcorder.
3. Turn the microphone on by sliding the setting switch from
the OFF position to the NORM position.
4. To increase the zoom listening profile of the MZM-1 move
the setting switch to the ZOOM position.
5. To save battery life, turn the switch to OFF when finished
using.
Troubleshooting
Specifications
Freq. response: 100 - 10KHz
Low impedance electret microphone
Battery: 1 AAA battery. Battery life = 300 hrs.
Power consumption: 2mA
Plug: 3.5 mm
Weight: 30g (w/out battery)
Effective output level
Normal: -50 dB unbalanced 0dB =1v/Pa
Zoom: -46dB unbalanced 0dB =1v/Pa
Dynamic Range: 80 dB
90 Day Limited Warranty
Sima Products Corp. (“Sima”) warrants that if the accompanying product proves to
be defective to the original purchaser in material or workmanship within 90 days
from the original retail purchase, Sima will, at Sima’s option, either repair or replace
same without charge (but no cash refund will be made). To enforce this warranty
you must deliver, mail or ship the product, together with both the original bill of sale
and this limited Warranty statement as proof of warranty coverage to:
Sima Products Corp.
Att: Customer Service
140 Pennsylvania Ave. Bldg. #5
Oakmont, PA 15139
To receive special offers and discounts, register your product online at
www.simacorp.com
Limitation of Liability and Remedies
Sima shall have no liability for any damages due to lost profits, loss of use or
anticipated benefits, or other incidental, consequential, special or punitive damages
arising from the use of, or the inability to use, this product, whether arising out of
contract, negligence, tort or under any warranty, even if Sima has been advised of
the possibility of such damages. Sima’s liability for damages in no event shall
exceed the amount paid for this product. Sima neither assumes nor authorizes
anyone to assume for it any other liabilities.Some states do not allow the exclusion
or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you. This warranty gives you specific legal rights, and
you may also have other rights which vary from state to state.
Possible Cause and Solution
* Make sure a fresh AAA battery is installed
* Make sure audio jack is plugged into
camcorder
Problem
No audio
Copyright 2005 © Sima Products Corp.
140 Pennsylvania Ave. Bldg #5 Oakmont, PA 15139
www.simacorp.com 800-345-7462 PN21716
