SimpleTech BONZAI STI-USB2SD/1GB Manuale utente

BONZAI QUICK START

UPGRADEABLE USB FLASH DRIVE

Congratulations on purchasing the Bonzai™ flash

drive from SimpleTech®.

SimpleTech’s Bonzai upgradeable flash drive works with

virtually any PC-compatible or Apple®Macintosh®

computer with a USB port, running Microsoft®Windows

98SE, ME, 2000, XP, or Mac OS 9.2 and later. Unlike other flash drives on the market,

you can increase Bonzai’s storage capacity by simply installing a higher capacity Secure

Digital™ (SD) or MultiMediaCard™ (MMC) digital media card.

Whether you’re at home, at work, or on the road, with Bonzai you can carry you most

important data wherever you go.

What You Should Have

•Bonzai (USB 2.0 flash drive)

•SimpleTech digital media (flash) card (included with selected models)

•StorageSync CD

•USB extension cable

•Neck strap

•Quick Start guide (this guide)

If any item is missing or damaged, contact your local reseller or retailer for replacement.

This quick start guide includes instructions on connecting and using Bonzai

with Windows and Macintosh computers. You may also want to consult your

computer’s user manual to determine if there are any additional instructions

related to the installation and use of USB devices.

MINIMUM SYSTEM REQUIREMENTS

INSTALLATION REQUIREMENTS

No tools or special equipment are required to install Bonzai.

Windows ME, 2000 and XP

No drivers are required. Plug Bonzai into an available USB port and Windows will install

the files needed to use the drive.

Windows 98SE

Go to www.simpletech.com/support and download the Windows 98SE driver for Bonzai

to your local computer. To install the driver, double-click on the downloaded file and

follow the on-screen instructions. When installation completes, restart your computer.

Mac OS 9.2 and later

No drivers are required. Plug Bonzai into an available USB port and your computer will

automatically detect the drive.

VISUAL TOUR

Protective Cap

Protects USB plug when Bonzai is not in use.

USB Plug (Type A)

USB interface for connecting Bonzai to your computer.

Activity Indicator

Illuminates to indicate drive read/write activity.

Card Slot

Slot for inserting digital media into Bonzai.

Windows Users Mac®Users

•

Pentium

class, 200MHz PC or compatible

•

iMac

, G3, G4, G5 and iBook

•

32MB RAM (or as required by system)

•

32MB RAM (or as required by system)

•

Windows 98SE, ME, 2000, XP

•

Mac OS 9.2 and later

•

Available USB 2.0/1.1 port

•

Available USB 2.0/1.1 port

For optimal performance, install the latest updates from Apple on your computer.

Download the updates from www.apple.com or open the software update tool

located in the Mac OS X system preferences folder. On systems running Mac OS 9,

the software update tool is located in the control panel folder.

INSTALLING DIGITAL MEDIA CARDS

Bonzai supports Secure Digital (SD), miniSD, MultiMediaCard (MMC) and RS-MMC

digital media cards.

1Open the card slot cover. To open the cover,

slide the cover to the rear of the Bonzai drive,

then lift and rotate it to the open position.

With the label side facing up, slide the media

card into the card slot until you hear a “click”—

indicating that the card is properly seated.

2Close the card slot cover.

To remove a media card, open the card slot cover. Press the media card into the spring

loaded card slot. When you hear a click, release the card and remove it from the card

slot. Close the card slot cover.

Setting Write Protection

Bonzai models with SD or miniSD digital

media cards, provide write protection to

prevent users from accidentally erasing

the data on the card. To enable write

protection, slide the write protect switch aft

to the locked position. To disable write

protection, slide the write protect switch

forward to the unlocked position.

To use miniSD and RS-MMC digital media cards with Bonzai requires a card adapter.

Bonzai drives sold with miniSD or RS-MMC cards include the appropriate adapter.

When using miniSD and RS-MMC media cards, you must place the card in a card

adapter before inserting it into the card slot.

When write protection is enabled,

you cannot format or write data to

the digital media card.

Lock

Write

Switch

Protect

Lock

CONNECTING BONZAI

Remove the protective cap, then plug Bonzai into the USB

connector on your computer.

If necessary, use the USB extension cable to connect Bonzai

to your computer. To connect using the USB extension

cable, connect the larger socket on the extension cable to

Bonzai. Plug the other end of the cable into the computer’s

USB port.

VIEWING FILES ON BONZAI

You can save, copy, move and delete files on Bonzai just as you would on any other

drive on your computer.

Viewing Files in Windows

In Windows, Bonzai appears as a

“Removable Disk”, mapped to your computer.

To access data on Bonzai, open

My Computer to view the storage devices

attached to your computer. Then, click

Bonzai’s disk icon (the drive letter assigned to

Bonzai depends on the computer’s hardware

configuration).

Viewing Files in Mac OS

On Mac OS computers, Bonzai is

represented by a drive icon on the desktop.

Unnamed drives appear as a “NO NAME”

drive. To view the contents on Bonzai,

double-click on its desktop icon.

If you are running Windows 98SE, install the Windows 98 driver before connecting

Bonzai to your computer.

SimpleTech recommends that you avoid using the USB port on Macintosh computer

keyboards. This port may not have enough power to adequately support the USB 2.0

interface.

FORMATTING BONZAI

The optional digital media card included with selected Bonzai models is formatted at the

factory as a FAT volume—allowing you to format the drive and access data using

standard Windows and Mac OS tools. For instructions on formatting drives, refer to the

documentation provided with your computer’s operating system.

Formatting for Mac Use Only

Mac users get better performance

when Bonzai is formatted as aMac

OS Extended volume. To format

the drive in Mac OS X, do the

following:

1Open Disk Utility and select

your Bonzai.

2From the Volume Format list,

choose Mac OS Extended

(Journaled).

3Click the Erase button.

After formatting Bonzai for Mac OS, you can customize the Finder window for quick

access to the files and folders on the drive.

Formatting Bonzai’s digital media card deletes all the data stored on the card.

Mac OS Extended volumes cannot

be accessed from Windows.

DISCONNECTING BONZAI

Rapidly and repeatedly inserting and removing a USB device may stop the USB port

from responding. Once the port is in this state, it will no longer recognize any USB

device. While the computer is powered on, it is recommended that you stop the Bonzai

drive from running before unplugging it from your computer.

Shutting Down Bonzai in Windows

1In the System Tray, double-

click the Safely Remove

Hardware icon.

2In the Safely Remove

Hardware window that

appears, select the Bonzai

flash drive, and then click

Stop.

3When Windows notifies you

that it is safe to do so, unplug

Bonzai from the computer’s

USB port.

Shutting Down Bonzai in Mac OS

1Double-clickBonzai’sdesktop

icon.

2In the Finder window that

appears, click the Eject

button located to the right of

the Bonzai drive icon.

3Unplug Bonzai from the

computer’s USB port.

You can also stop Bonzai

from running by dragging

the drive’s desktop icon to

the Trash bin.

Eject button

SPECIFICATIONS

Specifications subject to change without notification.

TECHNICAL SUPPORT FROM SIMPLETECH

SimpleTech Technical Support provides customer support for the duration of the

warranty period on this product, Monday through Friday from 6:30 am until 5:30 pm

Pacific Standard Time. You can contact our Technical Support team through our Web

site, by e-mail or by phone.

Phone: 1-800-945-3444 or 949-476-1180

Email Response: Go to www.simpletech.com/support, click Return Merchandise

(RMA), and then choose Need Technical Support.

Online Chat: Go to www.simpletech.com/support. Click .

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

This equipment carries the CE marking in accordance with European Directives TBD.

Manufacturer Warranty The Bonzai drive is warrantedfor a period of two yearsfrom the dateofretail

purchase. SimpleTech digital media (flash) cards are warranted for the life of the product. A full text version of the

SimpleTech’s warranty policy is available online at www.simpletech.com/warranty.

Interface USB 2.0 compliant (USB 1.1 compatible)

Connector USB, 4-pin, Type A plug

Data Transfer Rate USB 2.0: up to 480 Mbits/sec; USB 1.1: up to 12 Mbits/sec

Operating System Windows 98SE, ME, 2000, XP, Mac OS 9.2 and later

Power Supply USB bus powered; 5V operating voltage

Data Retention 10 years

Endurance 100,000 erase cycles

Operating Temperature 32° to 158° F (0° to 70° C)

Operating Humidity 20-85% relative (non-condensing)

Dimensions 2.48 in. x 2.44 in. x 0.43 (63 mm x 62 mm x 11 mm)

Some of the Bonzai’s listed capacity is used for formatting and

other functions and therefore is not available for data storage.

October 31, 2005

Worldwide Headquarters

SimpleTech, Inc.

3001 Daimler Street

Santa Ana, California 92705 USA

Tel: (949) 476-1180

Fax: (949) 476-1209

Web: www.simpletech.com

P/N: 60000-00129-002

2077r2

The SimpleTech name, logo and design are registered trademarks of

SimpleTech, Inc. All other products and corporate names are

trademarks or registered trademarks of their respective companies.
