INTERMEDIATE

SNOWTHROWERS

INCLUDING

ATTACHMENTS & ACCESSORIES

555 SNOWTHROWERS

Mfg. No. Description

1692680 555M, 5 HP Manual Start

1693161 555M, 5 HP Manual Start

1693163 555M, 5 HP Manual Start (Export)

1693425 555M, 5 HP Manual Start

1693646 555M, 5 HP Manual Start

1693647 555M, 5 HP Manual Start (Export)

755 SNOWTHROWERS

Mfg. No. Description

1692681 755E, 7 HP Electric Start

1692746 755M, 7 HP Manual Start (Export)

1693162 755E, 7 HP Electric Start

1693164 755M, 7 HP Manual Start (Export)

1693426 755E, 7 HP Electric Start

1693648 755M, 7 HP OHV Manual Start

1693649 755M, 7 HP OHV Manual Start (Export)

ATTACHMENTS & ACCESSORIES

Mfg. No. Description

1693661 Universal Soft Side Snow Cab

1692921 Counterweight

1686704 Drift Cutters, 16”

1685189 Drift Cutters, 20”, Heavy Weight

1686665 Headlight Kit

1686675 Headlight Mounting Kit

1686778 Headlight Kit (OHV Engines)

1690384 Electric Start Kit

Parts Manual

Rev. 10/1999

TP 400-2001-05-IW-S

MANUFACTURING, INC.

500 N Spring Street / PO Box 997

Port Washington, WI 53074-0997 USA

TP-400-2001-05-IW-S

Table of Contents

This Manual Covers The Following Products:

555 SNOWTHROWERS

Early Models

1692680 555M, 5HP Manual Start

1693161 555M, 5HP Manual Start

1693163 555M, 5HP Manual Start (Export)

1693425 555M, 5HP Manual Start

Later Models

1693646 555M, 5HP Manual Start

1693647 555M 5HP Manual Start (Export)

755 SNOWTHROWERS

Early Models

1692681 755E, 7HP Electric Start

1693426 755E, 7HP Electric Start

1693162 755E, 7HP Electric Start

1692746 755M, 7HP Manual Start (Export)

1693164 755M, 7HP Manual Start (Export)

Later Models

1693648 755M, 7HP OHV Manual Start

1693649 755M, 7HP OHV Manual Start (Export)

ATTACHMENTS & ACCESSORIES

1686704 Drift Cutters, 16”

1685189 Drift Cutters, 20”, Heavy Weight

1692921 Counterweight

1686665 Headlight Kit

1686675 Headlight Mounting Kit

1686665 Headlight Kit for OHV Engines

1692857 Universal Soft Side Snow Cab

PAGES

2, 10, 12, 14, 16,

18, 20, 22

6, 10, 12, 14, 16,

18, 20, 22

PAGES

2, 10, 12, 14, 16,

18, 20, 22

6, 10, 12, 14, 16,

18, 20, 22

PAGES

SNOWTHROWERS..........................................PAGES

Handles and Controls (Early)..............................2

Handles and Controls (Later) .............................6

Frame...............................................................10

Engine ..............................................................12

Auger Drive and Impeller .................................14

Auger Housing and Chute ................................16

Traction Drive...................................................18

Decals ..............................................................20

Wheels & Tires.................................................22

ATTACHMENTS & ACCESSORIES

Drift Cutters .....................................................24

Counterweight..................................................24

Headlight Kit.....................................................26

Headlight Adapter Kit .......................................26

Headlight Kit for OHV Engines..........................28

Universal Soft Side Snow Cab..........................30

Part Number Index ................................................31

Torque Specification Chart ...................................33

14 15

2829

34 35 36

47 48

3838

Apply adhesive to secure grip.

Ref. 18 required

slotted holes only.

Slot in support (Ref. 37)

towards rear of unit.

Mount bushings with

flange

on inside of brackets.

Shift rod assembly (Ref. 53)

must pivot freely on pivot

blocks (Ref. 48).

Apply adhesive

to grip.

Position in slots of frame to be sure hub of gear (Ref. 32) is

tight against the inside surface of the gear support (Ref. ) show 0 -2

Use washers to shim gear

(Ref. 32) as required to ensure

proper engagement.

TP-400-2001-05-IW-S

Handles and Controls (Early)

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

The above parts group applies to the following Mfg. Nos.:

1692680 555M, 5HP Manual Start

1692681 755E, 7HP Electric Start

1692746 755M, 7HP Manual Start (Exp.)

1633161 555M, 5HP Manual Start

1693162 755E, 7HP Electric Start

1693163 555M, 5HP Manual Start (Exp.)

1693164 755M, 7HP Manual Start (Exp.)

1693425 555M, 5HP Manual Start

1693426 755E, 7HP Electric Start

TP-400-2001-05-IW-S

Handles and Controls (Early)

1 1668525 2 ROD

2 1669323 3 SPRING, Extension

3 1916621 4 NUT, Hex, #10-24 R.H.

4 1715132 1 CLUTCH ROD, Traction Drive

5 1715659 1 CLUTCH ROD, Auger Drive

6 1715444 1 HANDLE, R.H. (Auger Control side)

7 1715443 1 HANDLE, L.H. (Traction Drive Control side)

8 1715103 1 LEVER, Auger Clutch, R.H.

9 1715104 1 LEVER, Traction Drive Clutch, L.H.

10 1676954 2 GRIP, Black Vinyl

11 1715655 2 SPACER, Large

12 1923358 2 NUT, Hex, Centerlock, 1/4-20

13 8021050 1 KNOB, Int. thrd., 3/8-16

14 1715783 1 DASHBOARD & SUPPORT ASSY.

15 1714084 1 KNOB, Chute Control Spinner

16 1960093 1 NUT, Push, 3/8

17 1919438 4 NUT, Hex Lock, 5/16-18

18 1919326 3 WASHER, Flat 5/16

19 1715654 2 SPACER, Small

20 1922837 2 CAPSCREW, Hex Hd., 1/4-20 x 1-1/2

21 1960556 2 SCREW, Taptite, Pan Hd., Torx, 1/4-20 x 3/4

22 1921221 4 CAPSCREW, Hex Hd. 5/16-18 x 1-1/2

23 1930591 4 SCREW, Hex, Flange Whizlock, 5/16-18 x 1/2

24 1927557 4 NUT, Hex, Flange Whizlock, 5/16-18

25 1715658 1 ROD, Chute Control

26 1918452 2 PIN, Spring, 1/8 x 3/4

27 1718793 1 SUPPORT, Gear

28 1921319 3 WASHER, Flat 1/4

29 1916964 3 LOCKWASHER, 1/4

30 1916622 3 NUT, Hex Hd., 1/4-20

31 1667588 4 BUSHING, Nylon

32 1718593 2 GEAR, Steel, Universal (Supersedes Plastic Gear)

33 1931333 1 CARRIAGE BOLT, 5/16-18 X 3/4

34 1919326 1 WASHER, Flat 5/16

35 1917356 1 LOCKWASHER, 5/16

36 1917372 1 NUT, Hex, 5/16-18

37 1715099 1 BRACKET, Worm Support

38 1960103 2 WASHER, Flat 3/8

39 1715117 1 WORM ASSEMBLY

40 916168 1 PIN, Spring

41 1931317 2 BOLT, Rd. Hd., 1/4-20 X 3/4

42 1918447 1 PIN, Cotter

43 1715106 1 ROD, Shift

REF NO. PART NO. QTY. DESCRIPTION

Footnotes:

The above parts group applies to the following Mfg. Nos.:

1692680 555M, 5HP Manual Start

1692681 755E, 7HP Electric Start

1692746 755M, 7HP Manual Start (Exp.)

1633161 555M, 5HP Manual Start

1693162 755E, 7HP Electric Start

1693163 555M, 5HP Manual Start (Exp.)

1693164 755M, 7HP Manual Start (Exp.)

1693425 555M, 5HP Manual Start

1693426 755E, 7HP Electric Start

14 15

2829

34 35 36

47 48

3838

Apply adhesive to secure grip.

Ref. 18 required

slotted holes only.

Slot in support (Ref. 37)

towards rear of unit.

Mount bushings with

flange

on inside of brackets.

Shift rod assembly (Ref. 53)

must pivot freely on pivot

blocks (Ref. 48).

Apply adhesive

to grip.

Position in slots of frame to be sure hub of gear (Ref. 32) is

tight against the inside surface of the gear support (Ref. ) show 0 -25

Use washers to shim gear

(Ref. 32) as required to ensure

proper engagement.

TP-400-2001-05-IW-S

Handles and Controls (Early)

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

The above parts group applies to the following Mfg. Nos.:

1692680 555M, 5HP Manual Start

1692681 755E, 7HP Electric Start

1692746 755M, 7HP Manual Start (Exp.)

1633161 555M, 5HP Manual Start

1693162 755E, 7HP Electric Start

1693163 555M, 5HP Manual Start (Exp.)

1693164 755M, 7HP Manual Start (Exp.)

1693425 555M, 5HP Manual Start

1693426 755E, 7HP Electric Start

TP-400-2001-05-IW-S

Handles and Controls (Early)

44 1917421 1 NUT, Jam, 3/8-16

45 108512 1 PIVOT

46 1715536 1 ROD & ARM ASSY., Pivot

47 1715123 1 SPRING, Torsion

48 1668524 2 BLOCK, Pivot

49 1918452 1 PIN, Cotter

50 1668185 2 BUSHING

51 1924361 1 WASHER

52 1921159 4 CAPSCREW, Hex Hd. 1/4-20 x 2 1/4 G5

53 1668523 1 ROD & CLEVIS ASSY.

54 1960074 1 CLIP, Hair Pin

55 1922755 1 WASHER

REF NO. PART NO. QTY. DESCRIPTION

Footnotes:

The above parts group applies to the following Mfg. Nos.:

1692680 555M, 5HP Manual Start

1692681 755E, 7HP Electric Start

1692746 755M, 7HP Manual Start (Exp.)

1633161 555M, 5HP Manual Start

1693162 755E, 7HP Electric Start

1693163 555M, 5HP Manual Start (Exp.)

1693164 755M, 7HP Manual Start (Exp.)

1693425 555M, 5HP Manual Start

1693426 755E, 7HP Electric Start

15 16

36 24

39 40

44 45

48 49

Apply adhesive to

secure grips.

Ref. 18 required on

slotted holes only.

Shift rod assembly

(Ref. 53) must pivot freely

on pivot blocks (Ref. 49).

Slot in support (Ref. 37)

towards rear of unit.

Mount bushings with

flange on inside of

brackets.

Insert shift rod (Ref. 46)

into inner hole of Ref.

47.

49 47

Use washers to shim

gear (Ref. 34) as

required to insure proper

adjustment.

Position in slots of frame to be sure hub of gear

(Ref. 37) is tight against the inside surface of the

gear support (Ref. 29).

Locate under rear hole of

gear support (Ref. 29) only.

TP-400-2001-05-IW-S

Handles and Controls (Later)

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

The above parts group applies to the following Mfg. Nos.:

1693646 555M, 5HP Manual Start

1693647 555M, 5HP Manual Start (Exp.)

1693648 755M, 7HP OHV Manual Start

1693649 755M, 7HP OHV Manual Start (Exp.)

TP-400-2001-05-IW-S

Handles and Controls (Later)

1 1668525 2 ROD, Control, Lower

2 1669323 3 SPRING, Extension

3 1916621 4 NUT, Hex, #10-24 R.H.

4 1715659 1 CLUTCH ROD, Traction Drive

5 1715132 1 CLUTCH ROD, Auger Drive

6 1720314 1 HANDLE, R.H. (Auger Control side)

7 1720315 1 HANDLE, L.H. (Traction Drive Control side)

8 1715103 1 LEVER, Auger Clutch, R.H.

9 1715104 1 LEVER, Traction Drive Clutch, L.H.

10 1676954 2 GRIP, Black Vinyl, for 1” Tube

11 1715655 2 SPACER, Large

12 1923358 2 NUT, Hex, Centerlock, 1/4-20

13 8021050 1 KNOB, Int. thrd., 3/8-16

14 1720384 1 DASHBOARD & SUPPORT ASMY

15 1714084 1 KNOB, Chute Control Spinner

16 1960093 1 NUT, Push, 3/8

17 1919438 5 NUT, Hex Lock, 5/16-18

18 1919326 3 WASHER, Flat 5/16

19 1715654 2 SPACER, Small

20 1922837 2 CAPSCREW, Hex Hd., 1/4-20 x 1-1/2

21 1960556 2 SCREW, Taptite, Pan Hd., Torx, 1/4-20 x 3/4

22 1921221 4 CAPSCREW, Hex Hd. 5/16-18 x 1-1/2

23 1720452 2 CLAMP, Tube, Saddle

24 1917356 5 LOCKWASHER, 5/16

25 1922127 2 CAPSCREW, Hex Hd. 5/16-18 x 1 3/4

26 1921332 2 CAPSCREW, Hex Hd. 5/16-18 x 3/4

27 1715658 1 ROD, Chute Control

28 1918452 1 PIN, Cotter

29 1718793 1 SUPPORT, Gear

30 1921319 3 WASHER, Flat 1/4

31 1960518 2 NUT, Push

32 1931317 4 BOLT, Rd. Hd., 1/4-20 X 3/4

33 1667588 4 BUSHING, Nylon

34 1718593 2 GEAR, Steel, Universal (Supersedes Plastic Gear)

35 1931333 1 CARRIAGE BOLT, 5/16-18 X 3/4

36 1919326 1 WASHER, Flat 5/16

37 1715099 1 BRACKET, Worm Support

38 1960103 2 WASHER, Flat 3/8

39 1715117 1 WORM ASSEMBLY

40 916168 1 PIN, Spring

41 1960294 2 NUT, Hex, Fl., 1/4-20

42 1918447 3 PIN, Cotter

43 1666255 1 ROD, Shift, Lower

REF NO. PART NO. QTY. DESCRIPTION

Footnotes:

The above parts group applies to the following Mfg. Nos.:

1693646 555M, 5HP Manual Start

1693647 555M, 5HP Manual Start (Exp.)

1693648 755M, 7HP OHV Manual Start

1693649 755M, 7HP OHV Manual Start (Exp.)

TP-400-2001-05-IW-S

Handles and Controls (Later)

The above parts group applies to the following Mfg. Nos.:

1693646 555M, 5HP Manual Start

1693647 555M, 5HP Manual Start (Exp.)

1693648 755M, 7HP OHV Manual Start

1693649 755M, 7HP OHV Manual Start (Exp.)

15 16

36 24

39 40

44 45

48 49

Apply adhesive to

secure grips.

Ref. 18 required on

slotted holes only.

Shift rod assembly

(Ref. 53) must pivot freely

on pivot blocks (Ref. 49).

Slot in support (Ref. 37)

towards rear of unit.

Mount bushings with

flange on inside of

brackets.

Insert shift rod (Ref. 46)

into inner hole of Ref.

47.

49 47

Use washers to shim

gear (Ref. 34) as

required to insure proper

adjustment.

Position in slots of frame to be sure hub of gear

(Ref. 37) is tight against the inside surface of the

gear support (Ref. 29).

Locate under rear hole of

gear support (Ref. 29) only.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Simplicity Spazzaneve

Simplicity

Simplicity 796 Manuale utente

Simplicity

Simplicity 960 Manuale utente

Simplicity

Simplicity 350E Manuale utente

Simplicity

Simplicity 477 Manuale utente

Simplicity

Simplicity TP-1234 Scheda tecnica

Simplicity

Simplicity 2025074 Manuale utente

Simplicity

Simplicity Signature Series Manuale utente

Simplicity

Simplicity 10528 Manuale utente

Simplicity

Simplicity 1690557 Manuale utente

Simplicity

Simplicity 1690032 Manuale utente

Simplicity

Simplicity 1691522 Manuale utente

Simplicity

Simplicity 1695856 Manuale utente

Simplicity

Simplicity 1695824 Manuale utente

Simplicity

Simplicity 319E Manuale utente

Simplicity

Simplicity 1693650 860M Manuale utente

Simplicity

Simplicity Sno-Away 13781 & Up Manuale utente

Simplicity

Simplicity 1691523 Manuale utente

Simplicity

Simplicity 219-463-2191 Manuale di istruzioni

Simplicity

Simplicity 419 Manuale utente

Simplicity

Simplicity LX 2000, LX 2900 Manuale utente

Simplicity

Simplicity 1694296 Guida all'installazione

Simplicity

Simplicity 990558 Manuale utente

Simplicity

Simplicity Baker 8/24E Manuale utente

Simplicity

Simplicity H924RX Manuale utente

Manuali Spazzaneve popolari di altre marche

Murray

Murray 624504X4A Manuale utente

Blizzard

Blizzard POWER PLOW 8100PP Manuale utente

Craftsman

Craftsman 486.24837 Manuale utente

Yard-Man

Yard-Man E2B5 Manuale utente

ST ST 526 A Manuale utente

MTD

MTD 3AA Manuale utente

Toro

Toro Power TRX 1428 OHXE Manuale utente

Ryobi

Ryobi RYAC800 Manuale utente

Poulan Pro

Poulan Pro 416829 Manuale utente

Poulan Pro

Poulan Pro 437986 Manuale utente

MTD

MTD 319-180-00 Manuale utente

Brute

Brute 1695565 Manuale utente

Egholm

Egholm City Ranger 2250 Manuale utente

Poulan Pro

Poulan Pro 420915 Manuale utente

GreenWorks

GreenWorks SNF402 Manuale utente

LOFTNESS

LOFTNESS 601D1 Manuale utente

LOFTNESS

LOFTNESS 1082I Manuale utente

LOFTNESS

LOFTNESS 481EL Manuale utente
