SimpliFire SF-25 Manuale utente

Electric Fireplace Stove

Model# SF-25

CONSUMER SAFETY INFORMATION

⚫Read this manual before installing and operating this appliance

⚫Failure to follow these instructions may result in electric shock, fire property, or

personal injury

⚫Do not store or use gasoline or other flammable liquids in vicinity of this

appliance.

-1-

Getting Started

⚫Remove the appliance from the box.

⚫Remove any packaging from the product.

⚫Place the packaging inside the box and either store or dispose of safely.

Contents of Carton

⚫Heater

⚫1 Instruction Manual

⚫Four Legs

⚫8 pcs of 4*12mm screws

⚫Before operating this unit, please read these instructions completely and save them

for the future use.

⚫This appliance is not intended for use by persons ( including children ) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning use

of the appliance by a person responsible for their safety.

⚫Children should be supervised to ensure that they do not play with the appliance.

⚫In order to avoid any danger, the cable must be changed by the special person from

manufacture, maintain department or relative department if the cable there is any

broken.

-2-

Assembling

Insert the leg buckles into the holes located on the base of the stove. Fasten the legs using

the screws ( 1 screw per leg ) and tighten with a Phillips head screwdriver, as followed

picture.

Operation Procedure

ON/OFF ------POWER

The power switch supplies power to all of the functions of the fireplace and will illuminate

the flame effect. This switch must be lit for any of the functions to work.

HEAT I

Low heater, Turn on this button the power is 750W.

HEAT II

HIGH heater, Turn on this button the power is 1500W.

Temperature control

Adjust temperature as your needed.

Flame adjustment

Adjust flame brightness as your needed.

Flame Adjustment

Adjust the flame from the bright to dark according to your choice

Temperature Control .

Temperature regulated heater ensures the appliance will not overheat. Should the heater

reach an unsafe temperature, the heater will automatically off. As the heater reach the safe

temperature, the heating function will work again.

Safety Instruction

-5

When using appliance, basic safety precautions should always be followed:

1. Check that the voltage indicates on the data plate corresponds with that of the

local network before connecting the appliance to the mains power supply.

2. This appliance is not intended for use by persons ( including children ) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge unless they have been given supervision or instruction concerning use

of the appliance by a person responsible for their safety.

3. Children should be supervision to ensure that they do not play with the appliance.

4. If the supply cord is damaged, it must be replaced by a qualified engineer on order

to avoid hazard.

5. The appliance must not be located immediately below a socket outlet.

6. Keep furniture, curtains and other flammable material at least one meter away

from the appliance.

7. Keep out of reach of children and do not allow them to operate this appliance.

8. Do not operate this appliance after a malfunction or after being dropped or

damaged in any way.

Cleaning:

⚫Turn heater OFF and unplug from electrical outlet before any cleaning or

maintenance is performed. Wait at least 10 minutes to allow all components to

cool properly.

⚫Use a vacuum or duster to keep heater and vent area clean from dust and dirt.

⚫The exterior of the fireplace should be cleaned with a damp cloth or duster.

Do not use abrasive cleaners or liquid sprays.

-6-

WARNINGS AND CAUTIONS

WARNING To avoid electrical shock not open the back panel of the insert

unless the Power has been turned off.And the insert has been unplugged.

WARNING Any electrical repairs.to this electric fireplace. Should only be

Performed by a qualified technician.

WARNING Any electrical wiring repairs should only be performed by a

qualified Technician.And also must comply with local buildings codes.

WARNING Discontinue use of this electric fireplace if any of the follow has

Occurred: Water damage. If insert has been or dented. If power

cord has Become broken. If power cord becomes hot to touch, if unit smokes or Smells

like smoke.

Note: When the heat functions is used for the first time.Aslight odor may be

Present. This is normal and should be occur again unless heater is not

used For extended periods of time and dust is allowed to accumulate on heater

Element.

Technical Specification

Supply: 120V-60Hz

Rated power:1500W

-7-

Safety Cut-Off

⚫This appliance is fitted with a safety cut-off which will operate if the fire

overheats (e.g. due to blocked air vents) .For safety reasons, the fire will NOT

automatically reset.

⚫To reset the appliance, disconnect the appliance from the mains supply for at

least 15 minutes. Reconnect the supply to the mains and switch on the appliance.

Troubleshooting

Symptom

Solution

No operation/no fan,

Check fuse by replacement,

Check for safety cut-off operation,

No fire effect light,

Check the LED light with

technician.

Meaning of crossed –out wheeled dustbin:

Do not dispose of electrical appliances as unsorted municipal waste, use separate

collection facilities.

Contact you local government for information regarding the collection systems

available.

If electrical appliances are disposed of in landfills or dumps, hazardous substances can

leak into the groundwater and get into the food chain, damaging your health and

well-being.

When replacing old appliances with new ones, the retailer is legally obligated to

take back your old appliance for disposals at least free of charge.

-8-
