Simrad RS25-E Manuale utente

RS25-E

Quick Reference Guide

1Power and volume knob

2Squelch/treshold level knob

3DSC Distress calls key

Priority channel key. When pressed all other modes are cancelled, and the

unit is tuned in to channel 16 on high power. Pressed again the unit will

return to normal operation

5Favourite channels key, used to toggle between favorite channels

6Scan key

7Menu key. A short press opens the DSC menu used to make DSC calls. A

long press displays the radio menu

8Intercom key. Used with the optional AHK05E handset

9Escape key, used to clear incorrect entries, to exit from a menu without

saving changes, and to back up to the previous screen

10 Rotary key. Turn to select a channel or a menu item, push to activate the

Enter function

11 Transmission Power key. Press to toggle between high or low transmission

power

12 Information key. Press to toggle through the INFO displays for

environmental and radio data

13 Push To Talk (PTT) key

Channel select keys. Use single presses to step through available

channels one at a time, or hold down to scroll rapidly through available

channels

15 Alpha-numeric keys used to enter the channel numbers and text

1 9 12 13

7 8654

Turning the unit ON

Operating the menu system

Entering your MMSI number

ON/OFF Adjust volume Adjust squelch

OFF

Exit menuDisplay DSC CALL

Display RADIO menu

ESC < CLR

* Handset only

** Base unit only

NOTE:

Only 4 menu items can be displayed at

any one time on the LCD.

CALL

INFO DATA *

BUDDY LIST

LOCAL/DIST

BACKLIGHT

CONTRAST

GPS/DATA

DSC SETUP

RADIO SETUP

HS SETTING

GPS SIM

RESET **

CALL

2 s

INDIVIDUAL

LAST CALL

GROUP

ALL SHIPS

CALL LOG

DIST LOG

LL REQUEST

TRACK BUDDY

Select menu item Conrm

selection

or ENT >

or -

MENU SELECT

INDIVIDUAL

LAST CALL

GROUP

MENU SELECT

INDIVIDUAL

LAST CALL

GROUP

CALL

2 s

MENU SELECT

CONTRAST

GPS/DATA

DSC SETUP

USER MMSI

GROUP SETUP

INDIV REPLY

INPUT USER

MMSI

___________

123456789

MMSI

STORE

CANCEL

Setting the backlight level

Send and receive DSC calls

NOTE: You need to enter your MMSI number into the system to make any calls.

Send a distress call

Favorite channels

Repeat for favorite channel 2 (CH2) and channel 3 (CH3).

Select channel Conrm entry Toggle favorite

channels

= CH1

3CH

2 s

3CH

Sending a call Acknowledging an incoming call

CALL

Alternating

RCV:INDIV

54321987

ROUTINE

ENT -> ACK

13 CHANNEL

REQUEST

ESC -> EXIT

MENU SELECT

INDIVIDUAL

LAST CALL

ALL SHIPS

2 s

Cancel by pressing the PTT key.

DISTRESS CALL

ABANDONING

PIRACY

OVERBOARD

DISTRESS CALL

OVERBOARD

HOLD DISTR

2 SECONDS..

ENT >

CALL

2 s

CH -

CH +

MENU SELECT

LOCAL/DIST

BACKLIGHT

CONTRAST

BACKLIGHT

...

LO HI

PRESS ENT

*988-10033-001*

www.simrad-yachting.com Abrand by Navico - Lead er in Marine Electronic s

Manual

Simrad IS20 Graphic

Multifunction display

English

User manual available on:

Scanning channels

Creating your buddy list

The AHK05 Handset (Opional)

Pairing handset and base unit

Scan all channels Stop scanningScan favorite channels

SCAN

2 s

SCAN

3CH SCAN

2 s

IC H/L

Calling handset/main unit

ESC

Exiting intercom/

conference mode

2 s

H/L

2 s

Entering intercom/conference mode

NOTE:

Select second handset for

conference calling

CALL

2 s

SCAN

2 s

MENU SELECT

HS SETTING

GPS SIM

RESET

HS SETTINGS

CLEAR CODE

YES

WAITING

EXIT -> CANCEL

CALL

2 s

MENU SELECT

BUDDY LIST

LOCAL/DIST

BACKLIGHT

BUDDY LIST

MANUAL NEW

DON

KENT

TOM

987654321

STORE

CANCEL

ENTER NAME

_________

ENTER MMSI

_________
