Sinar Sinarback S 30 Manuale utente
Sinarback S 30|45
Mobile and Versatile
Sinar Photography AG
We do everything for the perfect picture
Manual
FCC Note:
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
To assure continued compliance, follow the attached installation
instructions and use only shielded interface cables with ferrite core
when connecting to computer or peripheral devices. Any changes
or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equip-
ment.
Trade Name: Sinar
Model No.: Sinarback S 30|45
Contains FCC ID: 2AJ8SS3045
This transmitter must not be co-located or operated in conjunction
with any other antenna or transmitter. This equipment complies with
FCC radiation exposure limits set forth for an uncontrolled environ-
ment and meets the FCC radio frequency (RF) Exposure Guidelines.
This equipment is tested for speci c absorption ratio (SAR) and com-
plies with FCC/IC radiation exposure limits set forth for an uncon-
trolled envi- ronment. This device complies with FCC/IC SAR limit of
1.6 W/kg. For body worn operation, this equipment has been tested
and meets the FCC/IC RF exposure guidelines when used with the
Sinar Photography AG accessories supplied or designated for this
product that have no metallic component in the assembly. Use of
other accessories may not ensure compliance with FCC/IC RF expo-
sure guidelines.
For Canada only:
CAN ICES-3 (B)/NMB-3(B)
This device complies with RSS-210 of the IC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation of the device. This
equipment complies with IC radiation exposure limits set forth for
an uncontrolled environment and meets RSS-102 of the IC radio
frequency (RF) Exposure rules. This equipment is tested for specific
absorption ratio (SAR) and complies with FCC/IC radiation exposure
limits set forth for an uncontrolled environment. This device com-
plies with FCC/IC SAR limit of 1.6 W/kg. For body worn operation,
this equipment has been tested and meets the FCC/IC RF exposure
guidelines when used with the Sinar Photography accessories sup-
plied or designated for this product that have no metallic component
in the assembly. Use of other accessories may not ensure compli-
ance with FCC/IC RF exposure guidelines.
3 — Legal Information
3 — Legal Information
3 — Table of Content
3 — Table of Content
DISPOSAL OF ELECTRICAL AND ELECTRONIC EQUIP-
MENT
(Applies within the EU, and for other European countries
with segregated waste collection systems.)
This device contains electrical and/or electronic components and
should therefore not be disposed of in general household waste.
Instead it should be disposed of at a recycling collection point pro-
vided by the local authority. This costs you nothing. If the device itself
contains replaceable (recharge- able) batteries, these must be re-
moved rst and, if necessary, also be disposed of in line with the rel-
evant regulations. Further information on this issue is available from
your local administration, your local waste collection company, or in
the store where you purchased this device.
Warning Messages
• Modern electronic components react sensitively to electrostatic
discharge. As you can easily pick up charges of tens of thousands
of volts by walking on synthetic carpets, for example, a discharge
can occur when you touch your Sinarback S 30|45, particularly if it
is lying on a conductive surface. If only the housing is touched, this
discharge is harmless to the electronics. However, despite built-in
safety circuits, outer contacts such as those in the bottom of the
camera should not be touched if at all possible for safety reasons.
• For any cleaning of the contacts, please do not use an optical
microfiber cloth (synthetic); use a cotton or linen cloth instead!
Before touching the contacts, you can make sure you discharge
any electrostatic charge by deliberately touching a heating or water
pipe (conductive, earthed material). You can also avoid soiling and
oxidization of the contacts by storing your Sinarback S 30|45 in a
dry place with contacts covered.
• Use only the recommended accessories to prevent faults, short
circuits or electric shock.
• Do not attempt to remove parts of the body (covers); qualified re-
pairs can be carried out only at authorized service centers.
Legal information:
• Please ensure that you strictly observe copyright laws. The record-
ing and publication of prerecorded media such as tapes, CDs, or
other published or broadcast material may contravene copyright
laws.
• This also applies to all of the software supplied.
• The SD, HDMI, CF and USB logos are trademarks.
• Other names, company and product names referred to in these
instructions are trademarks or registered trademarks of the rele-
vant companies.
The CE identification of our products documents compliance
with the fundamental requirements of the respective valid EU
directives.
The production date of your camera can be found on the stickers in
the warranty card and/or on the packaging.
The date convention is: Year/Month/Day
In the menu, under Camera Information, you will find the specific
approvals for this Sinarback under the point Regulatory Information.
Package Contents:
Before using your Sinarback S 30|45 for the first time, please check
that the accessories supplied are complete.
• Digital Back Sinarback S 30|45
• Quick Charger S with interchangeable mains plugs (16009)
• Sinar Software (SIN-551.043-090)
• Lemo USB-3.0-cable for Sinarback S 30|45 (Typ 007) (16040)
• WhiteShadingDiffusor 100 (S07043)
3 — Legal Information
Note:
Additional information
Important:
Failure to observe the instructions may cause damage to the digital
back, camera, accessories or the photos.
Caution:
Failure to observe the instructions may cause personal injury.
Meaning of the different note categories in this manual:
3 — Legal Information
1 2 3 4 5 6
7
8
9
10
11
12
13
14
15
16
17
18
3 — Legal Information
Main switch with stop position
Monitor
Live view button
Video record button
Joystick
Rear setting dial
Flash synchronization socket
Lemo® audio socket
HDMI socket
Menu control / function button
Lemo® USB 3 socket
Menu control / function button
Lemo® remote control out socket
Lemo® CPL socket
Speaker
Review / menu control / function button
menu control / function button
LED for recording dada storage on card
1
5
3
7
9
2
6
4
8
10
12
14
16
18
11
13
15
17
3 — Legal Information
Serial number / WiFi antenna
CF-card slot with ejection slide
SD card slot
1
3
2
1
2
3
3 — Legal Information
Main switch with stop position
Monitor
Live view button
Video record button
Joystick
Rear setting dial
Flash synchronization socket
Lemo® audio socket
HDMI socket
Menu control / function button
Lemo® USB 3 socket
Menu control / function button
Lemo® remote control out socket
Lemo® CPL socket
Speaker
Review / menu control / function button
menu control / function button
LED for recording dada storage on card
1
5
3
7
9
2
6
4
8
10
12
14
16
18
11
13
15
17
54a
54b
54
53
53a
49a
49
51
50
52
48
46
47
53b
