Sinexcel INTERSTELLAR Series Manuale utente
1
INTERSTELLAR EV AC CHARGER
User manual
2
Contents
Contents ............................................................2
About the document .........................................3
Symbol conventions .........................................4
1. Safety ............................................................5
2. Description ...................................................6
3. Operation Ⅰ ................................................ 15
4. Sinexcel AC APP .......................................28
5. Maintenance and cleaning ......................... 34
6. Troubleshooting ......................................... 38
7. Cyber security ............................................ 41
8. Warranty .....................................................42
9. Contact us ...................................................44
3
About the document
1)
This user manual is specifically for the interstellar
AC charger series products (SEA400/32Y-E-P or
SEA230/32Y-E-P) developed and produced by
Sinexcel, and provides comprehensive guidance for
new energy vehicle users to use and maintain this
charging device.
2)
This manual will provide detailed product
information and operating instructions for users. Please
read the contents of the manual carefully before use
this product and ensure that you understand all the
instructions. Please store this manual in a safe place
for maintenance personnel for the easy installation,
operation and maintenance.
3)
The copyright of contents, pictures, logos, symbols,
etc. used in this manual are all owned by Sinexcel.
Without authorization, it is forbidden to disclose,
excerpt and copy part or all of the contents of this
manual (including materials and publications).
4)
The contents of this manual will be adjusted, revised
and updated according to product upgrades. Please use
this manual refer to the actual product purchased.
445544545645645645454 545645 4
4
Symbol conventions
Symbol
Description
Warning
If you do not obey the instruction it might cause injury
or death.
Danger
Risk of electrocution
Caution of fire
Note
A note gives more details for easy use.
It means that the machine cannot be discarded randomly after use
and should be delivered to a dedicated recycling place, otherwise it
may cause environmental pollution.
Grounding identification
This indicates that the product must be grounded during
installation. If it is not properly grounded, it may cause death or
serious injury.
5
1. Safety
1.1 General safety instructions
●This product is an integrated charger that can charge electric vehicles in indoor and outdoor areas.
●Please use and save the product information and accessories that are shipped with the device properly.
●If any problem or failure occurs during use, please consult the manufacturer directly. If the user resorts
to a third party or a non-professional person for maintenance during the warranty period, any security
consequences shall be borne by the user.
●The installation environment of charging equipment should be far away from fire and other dangerous
sources.
1.2 Safety instructions for use
●Please read the user manual carefully before use, and strictly follow the steps.
●Without the permission of the manufacturer, it is strictly forbidden for the user to disassemble the product
and do other improper operations. Any undesirable consequences caused by improper operation shall be
borne by the user.
●Do not touch the charging plug or the charging socket of the electric vehicle. Keep the charging plug in a
dry state. Do not touch the charging plug with water.
●Do not use the charging device when the connector is damaged or the insulation is damaged.
●Ensure that nothing remains in the charging plug and the charging socket on the vehicle side.
●Lock the door correctly after installation or maintenance operations.
In these situations, do not use the EVSE and contact to the manufacturer immediately
：
●Damage on the enclosure
●Damage on the AC charger or connector
●Lighting hits the EVSE
●Accident or fire near the EVSE
●Water has entered the EVSE
If an emergency occurs during the operation
of this product, please press the emergency
button immediately. Do not use the emer-
gency button in non-emergency situations!
5452
6
162mm
406mm
RFID area
emergency button
breathing light
connector
logo
2. Description
2.1 General description
Interstellar is an AC charger supplies electricity to the EV. The product adopts DLM system and IMD
technology which makes strong charging performance with great quality. It has multiple safety protection
functions with a protection rating of IP65, suitable for indoor or outdoor use.
2.2 Overview
2.2.1 Overview of EVSE, outside
The emergency button is not a reset button so it is forbidden to press it in non-emergency situations.
After pressing it, the EVSE will stop charging immediately. If the emergency button is pressed by
mistake, please turn it gently in the direction of the arrow on the button to reset.
7
2.2.2 Overview of EVSE, inside
Smart meter(optional)
Circuitbreaker
Maintenance
cover
Mainboard
Light board
Terminal block
RFIDreader
Part
Function
Maintenance cover
For maintenance and operation of on&off
Circuit breaker
For short circuit protection, overload protection and leakage
protection
Smart meter
For metering
Mainboard
To control the EVSE
RFID reader
To start or stop charging session with the RFID card
Light board
To show the operation status of EVSE
Terminal block
To connect the cable of alternating current input from grid
Display
To show the operation status and parameter of EVSE
8
2.2.3 Pedestal
2.2.4
Nameplate
9
2.3 Specification
Interstellar (Residential Use)
Rated Power
7kW
22kW
Input/Output
Voltage
Single-Phase 230V
Three-Phase 400V
Input/Output Current
32A
32A
Weight
5KG
7.5KG
Dimensions
W406*H450*D162
Frequency
50Hz
Connector
IEC Type 2
Cable Length
3m(5m optional)
Charging Status
Information
LED
Authorization
Plug and Charge
Metering
MID Meter(optional)
Installation
Floor-mounted/Wall-mounted
Protection Function
Over current protection, over/under voltage
protection, over temperature protection,
lighting protection, short circuit protection,
etc.
Protection Rating
IP65 /IK10
Operation
Temperature
-30 ℃~+55 ℃
Operation Altitude
<2000m
Relative Humidity
5%-95%
RCD
Type A+DC 6mA
EMC
Class B
Certification
CE/TR25/TUV Mark/RCM
Color
Black/White/Silver
10
Interstellar (Commercial Use)
Rated Power
7kW
22kW
Input/Output
Voltage
Single-Phase 230V
Three-Phase 400V
Input/Output Current
32A
32A
Weight
5KG
7.5KG
Dimensions
W406*H450*D162
Frequency
50Hz
Connector
IEC Type 2
Cable Length
3m (5m optional)
Charging Status
Information
LED/Display(optional)
Authorization
NFC/RFID/Plug and Charge/APP（optional）
Metering
MID Meter(optional)
Communication
Method
LAN/Wifi/4G(optional)
Communication
Protocol
OCPP1.6J(can be updated to 2.0)
Installation
Floor-mounted/Wall-mounted
Protection Function
Over current protection, over/under voltage
protection, over temperature protection,
lighting protection, short circuit protection, etc.
Protection Rating
IP65/IK10
Operation
Temperature
-30 ℃~+55 ℃
Operation Altitude
<2000m
Relative Humidity
5%-95%
RCD
TypeA+DC 6mA
EMC
Class B
Certification
CE/TR25/TUV Mark/RCM
Color
Black/White/Silver
Note 1 DC 6mA has an automatic start test function, which is performed every time when the
relay is closed, and the intervals is not more than at least once a day.
