Singer FEATHERWEIGHT II 118 Manuale utente

BUYER'S MODEL NO. 118 FACTORY MODEL ORIGINAL ISSUE FEBRUARY, 2004 SECTION ----

REFER TO IMPORTANT NOTICE BELO

P.NO.77339

PARTS LIST

FOR

IMPORTANT:

WHEN ORDERING THE PARTS

LWAYS CHECK THE SERIAL

NUMBER OF THE MACHINE.

FIRST DIGIT OF THE SERIAL

NUMBER MUST MATCH WITH

THE LAST DIGIT OF THE FACTOR

MODEL ABOVE.

FIRST DIGIT

CA11860,CE118S0

SERIAL

NO.

FACTORY

MODEL

×××××××

Model 118

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK

PART #

DESCRIPTION

BUYER'S MODEL NAME 35818 WASHE

FACTORY MODEL CA11860,CE118S0 60786 M4 SCRE

ORIGINAL ISSUE March, 2004 67447 M5 SCRE

77042 M4 PHILLIPS SCRE

81018 SHUTTLE SHAFT PLATE

81019 SHUTTLE SHAFT BASE

81314 EXTENSION TABLE

SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK

PART #

DESCRIPTION

BUYER'S MODEL NAME 1513 E4 CLIP-ON-WASHE

FACTORY MODEL CA11860,CE118S0 10963 E6 CLIP-ON-WASHE

ORIGINAL ISSUE March, 2004 43389 WASHE

43390 WASHE

43930 SPRING PIN

64637 WASHE

66474 M5 SCRE

66725 M3 SCRE

67447 M5 SCRE

73472 COLLAR

79447 REAR COVER FIXING PLATE

81008 TAKE-UP LEVER CRAN

81009 BELT PULLEY

81057 NEEDLE BAR CRAN

81062 TAKE-UP LEVE

81063 CRANK SHAF

81064 SHAFT

81065 BLANCE

81082 BELT GUIDE PLATE

81097 BALL BUSHING

81098 SECURING PLATE

81099 SPRING GEA

81100 COLLAR

81101 TORSION SPRING

81102 CLUTCH

81103 HAND WHEEL SCRE

81135 MAIN SHAFT

81232 SCRE

81258 SCRE

81267 E9 CLIP-ON-WASHE

81315 HAND WHEEL

81332 BELT PULLEY

SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK

PART #

DESCRIPTION

BUYER'S MODEL NAME 1513 E4 CLIP-ON-WASHE

FACTORY MODEL CA11860,CE118S0 1520 E3 CLIP-ON-WASHE

ORIGINAL ISSUE March, 2004 39817 SCRE

61222 M4 PHILLIPS SCRE

64653 M3 SCRE

66725 M3 SCRE

67232 NEEDLE

77042 M4 PHILLIPS SCRE

80046 EXTENSION SPRING

81004 SUPPORT BUSH

81005 SUPPORT FIXING PLATE

81006 COLLAR

81007 STOPPER

81010 PIN

81011 SUPPORT CONNECTION PLATE

81012 SUPPORT CONNECTION SHAFT

81055 NEEDLE BA

81056 NEEDLE CLAMP

81058 NEEDLE BAR CLAMP

81061 NEEDLE BAR SUPPOR

81074 COMPRESSION SPRING

81075 THREADER SHAFT SET

81087 LEVER

81142 LIMITING PLATE

81144 BOBBIN WINDER COMPLETE

81145 RATCHET

81162 SUPPORT SHAFT

81191 EXTENSION SPRING

81192 THREADER ASSEMBL

81215 TORSION SPRING

81216 NEEDLE CLAMP SCRE

81234 M3.5 HEX SCREW

81253 COLLAR

85061 PIN

85075 PIN

SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK

PART #

DESCRIPTION

BUYER'S MODEL NAME 1513 E4 CLIP-ON-WASHE

FACTORY MODEL CA11860,CE118S0 67447 M5 SCRE

ORIGINAL ISSUE March, 2004 68891 WASHE

76250 PRESSER FOOT HOLDE

77035 M4 PHILLIPS SCRE

79456 NEEDLE PLATE

79491 SCRE

79495 ZIGZAG PRESSER FOOT

81013 IDLER UNIT

81021 RELEASE LEVE

81024 SHUTTLE RACE COVE

81053 PRESSER BA

81066 IDLER BRACKE

81092 COMPRESSION SPRING

81133 PRESSER BAR HOLDER

81134 PRESSER BAR BLOC

81202 TIMING BELT

81256 SCREW FOR SHAN

81257 SET SCRE

81333 THREAD GUIDE

81334 SHUTTLE COVER SPRING PLATE

81373 M2 SCRE

81374 SCRE

SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK

PART #

DESCRIPTION

BUYER'S MODEL NAME 1520 E3 CLIP-ON-WASHE

FACTORY MODEL CA11860,CE118S0 43389 WASHE

ORIGINAL ISSUE March, 2004 62215 M4 NUT

66725 M3 SCRE

77042 M4 PHILLIPS SCRE

81003 STUD SCRE

81042 CHECK SPRING GUID

81091 PRESSER FOOT LIFTER

81093 TENSION SHAFT FIXING PLATE

81094 THREAD TENSION SHAF

81095 COMPRESSION SPRING

81096 COMPRESSION SPRING

81136 THREAD TENSION BASE

81137 TENSION RELEASE LEVE

81138 TENSION RELEASE LEVE

81139 TENSION SPRING BASE

81161 SHAFT

81179 THREAD GUIDE PLATE

81188 GUIDE PLATE

81189 SLIDE SCRE

81209 CHECK SPRING

81228 TENSION PLATE

81239 M3.5 SCRE

81240 M3 SCRE

81241 M3 SCRE

81250 TENSION PLATE

81316 DIAL

81317 DIAL RING

81324 THREAD GUIDE PLATE

81358 WASHE

85075 PIN

SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK

PART #

DESCRIPTION

BUYER'S MODEL NAME 10963 E6 CLIP-ON-WASHE

FACTORY MODEL CA11860,CE118S0 43393 WASHE

ORIGINAL ISSUE March, 2004 56858 M2 PHILLIPS SCRE

61221 M4 PHILLIPS SCRE

64637 WASHE

66725 M4 SCRE

67251 M3.5 SCRE

67444 COLLAR

67447 M5 SCRE

76281 BOBBIN

81014 SHUTTLE RACE

81015 WASHE

81016 SHUTTLE RACE SHAFT

81017 BOBBIN CASE

81025 BOBBIN CASE STOPPE

81026 SPRING PLATE

81027 BOBBIN CASE LIMITING PLATE

81028 BALL BUSHING

81029 BEVEL GEA

81030 FEED-DOG LIFTING CAM

81031 LOWER SHAFT BELT GEAR

81068 LOWER SHAFT

81105 SECURING PLATE

81125 WASHE

81185 FEED-DOG FEEDING CAM

81232 SCRE

85075 KNOCK PIN

SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK

PART #

DESCRIPTION

BUYER'S MODEL NAME 1513 E4 CLIP-ON-WASHE

FACTORY MODEL CA11860,CE118S0 59221 WASHE

ORIGINAL ISSUE March, 2004 66474 M5 SCRE

66725 M4 SCRE

76111 HEADED PIN

76197 HEADED PIN

81034 FEED DOGS

81035 FEED DOG BASE

81036

DJUSTING SCRE

81037 SHAFT

81038 FEED REGULATING BRACKE

81039 FEED REGULATING SHAFT

81040 FEED REGULATING ARM

81041 FIXING PLATE

81043 SPRING

81044 FEED REGULATING LINK L.

81045 PIN

81046 FEED REGULATING LINK R.

81047 BALL BUSHING

81049 TORSION SPRING

81054 COLLAR

81069 HORIZONTAL FEED SHAFT

81105 SECURING PLATE

81232 SCRE

81244 SCRE

81254 SCRE

85075 KNOCK PIN

SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK

PART #

DESCRIPTION

BUYER'S MODEL NAME 1513 E4 CLIP-ON-WASHE

FACTORY MODEL CA11860,CE118S0 1520 E3 CLIP-ON-WASHE

ORIGINAL ISSUE March, 2004 1615 WASHE

2206 WASHE

8400 E5 CLIP-ON-WASHE

9122 WASHE

28735 CRINKLE WASHE

31246 WASHE

32316 WASHE

43392 WASHE

46411 SPRING WASHE

61222 M4 PHILLIPS SCRE

61381 CRINKLE WASHE

62215 M4 NUT

66318 M4 SCRE

66727 HEX SCRE

67447 M5 SCRE

72858 WASHE

76482 WASHE

77042 M4 PHILLIPS SCRE

77403 SCRE

79411 SELECTOR CAM BASE

79412 PATTERN INDICATOR SUPPOR

79413 FEED LEVER

79414 OPERATING ARM

79416 OPERATING ARM B

79417 SPRING

79418 SHAFT

79425 OPERATING PLATE

79433 BELT ADJUSTMENT PLATE

79434 SHAFT

79435 GEAR SHAFT

79436 SHAFT

79440 HORIZONTAL SHAFT LINK PLATE

79442 SUPER CHANGE LEVER

79445 M4 SHOULDER SCRE

79448 OPERATING ARM A ASS

79450 NOTCHED SPRING

79458 OPERATING ARM

79459 PATTERN SELECTING DIAL

79464 DIAL INDICATO

79469 BEVEL GEA

79473 BELT

79478 PATTERN DIS

79479 SEAL

81337 BEVEL GEA

SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK

PART #

DESCRIPTION

BUYER'S MODEL NAME 1504 E7 CLIP-ON-WASHE

FACTORY MODEL CA11860,CE118S0 1513 E4 CLIP-ON-WASHE

ORIGINAL ISSUE March, 2004 1520 E3 CLIP-ON-WASHE

8400 E5 CLIP-ON-WASHE

8466 WASHE

9122 WASHE

10963 E6 CLIP-ON-WASHE

58220 WASHE

61221 SCRE

61222 M4 PHILLIPS SCRE

61228 SCRE

61341 M4 SCRE

66318 M4 SCRE

66725 M3 SCRE

66727 M4 SCRE

68439 M4 NUT

73299 M4 TORQUE NUT

77042 M4 PHILLIPS SCRE

79401 FOLLOWER

79402 PATTERN CAM BASE

79403 PATTERN CAM BASE B

79404 FOLLOWER SUPPORT

79405 NOTCHED SPRING

79410 SHAFT

79419 SUPER CHANGE LIN

79421 SUPER CHANGE ARM

79423 LENGTH OPERATION PLATE

79424 LENGTH OPERATION LEVER

79432 SUPER CHANGE ASS

79437 SUPER STITCH FOLLOWER

79438 FOLLOWER BASE

79443 SUPER LINK PLATE

79446 COLLAR

79449 COIL SPRING

79457 SUPER STITCH CAM

79466 PATTERN CAM

79467 PATTERN SELETION CAM

79468 CAM GEAR

81054 COLLAR

81256 SCRE

81338 SCRE

81340 PIN

81353 OPERATING PLATE

81354

DJUSTING PLATE

81355 SHAFT

81371 CAM BUSH

81375 WASHE

81376 M4 SCRE

81377 SPRING

81378 SCRE

SERIAL NO.
