Singer PERFECT FINISH ET-1 Manuale utente
Feature Benefit
Over 1,000
Stitch Functions
Select from over 1,000 Stitch Functions. Fulfill your creative dreams with a
large selection of decorative stitches, alphabet stitches, and construction
stitches.
Large Back-Lit LCD
Screen
Provides clear and easy viewing of stitch functions including stitch width and
length, tension settings, and the recommended presser foot.
Four Memory Modules
Four Memory Modules each hold up to 20 entries. Place names, simple
phrases and decorative stitch sequences in each of these four modules, then
retrieve them anytime you want to personalize your projects.
Mirror Imaging and
Elongation Function
With just a touch of a button selected stitches can be mirrored imaged, add-
ing even more stitch variety. Want to make a stitch longer yet keep the stitch
intact? Select the Elongation button and select stitches can be made up to 5
times longer.
Electronic Auto Pilot Unplug the foot control, press the Start button and the machine sews. You
are still in complete control over the speed - just slide the Speed Limiting
Lever to the desired speed.
Programmable Needle
Up/Down
The needle can be programmed to stop in the highest up position when your
foot is lifted from the controller, making it easier for removing the fabric from
the machine. Or program the needle to stop in the down position, which is
ideal for pivoting, appliquéing or quilting.
Heavy Duty Metal Frame The internal rigid support holds all the mechanisms in perfect alignment for
skip-free sewing and overall durability.
Extension Table Provides a larger working area, an essential for quilting, home decor sewing,
or when working with a larger project.
Perfect Finish Model ET-1
Feature Benefit
2 Built-In Alphabets Personalize projects by adding a monogram, name or phrase with the
built-in block or script style alphabets, both available in upper and lower
case.
Horizontal Threading
Quality stitches begin with proper thread delivery. Placing the thread
spool in the horizontal position allows for the thread to feed more
evenly, reducing poor stitch formation and thread breakage.
Automatic Needle Threader
Makes threading the eye of the needle quick and painless.
Top Drop-in Bobbin
This mechanism incorporates a magnet-type vertical axis rotating hook
that ensures smooth, quiet, thread jam resistant sewing. The bobbin
loads from the top, so it is easy to insert the bobbin. The clear cover
makes it easy to monitor the bobbin thread supply.
Automatic Bobbin
Winding Declutching The needle bar automatically disengages when winding the bobbin.
This keeps the needle from moving up and down while winding the
bobbin, therefore making bobbin winding safer.
9 Fully Automatic
1-Step Buttonholes Buttonhole sewing is a one-step simple process, providing reliable re-
sults every time.
Built-In Stretch Stitches Specially designed stitches that add strength and flexibility to seams,
especially useful when sewing on knitwear and super-stretch fabrics.
Adjustable Stitch Length Automatic settings for length can be overridden to personalize length
choice.
Adjustable Stitch Width Automatic settings for width can be overridden to personalize width
choice.
Perfect Finish Model ET-1
Feature Benefit
Center Zigzag Taper
When tapering with the zigzag stitch, the stitch tapers to the center,
not the left or right. This feature is especially valuable when appliqué-
ing, because it provides a more attractive look when tapering into or
out from a point.
Automatic Locking
Stitch Function Tie-off decorative and utility stitches with just a push of a button.
Three tiny tacking stitches, reinforce patterns and stitches to prevent
unraveling.
Automatic Reverse Push the conveniently located Automatic Reverse Button to sew in
reverse and reinforce the stitch.
7mm Stitch Width Select stitches can be set for a maximum width of 7mm creating
attractive satin and decorative stitches.
Electronic Twin
Needle Control Select stitches automatically adjust for twin needle sewing with just
the touch of a button.
13 Needle Positions Needle position can be changed for individual projects like inserting
zippers, cording and topstitching.
Editing Capabilities It’s easy to make changes or replace your selections within the Mem-
ory Module.
Error Warning An audible warning alerts the sewer if something is incorrect. The
audible warning can be deactivated, if desired.
Pattern Override Memory Select a pattern, override the width and/or length, place the stitch in a
Memory Module, and the machine will remember those changes for
future use.
Sewing Speed With a maximum sewing speed of 750 stitches-per-minute, projects
can be sewn quickly.
Automatic Presser Foot
Pressure Control
The amount of pressure exerted on the fabric by the presser foot
against the feed dogs is adjusted automatically. Sew from the lightest
weight tricots to the heaviest denim, without making presser foot
pressure adjustments.
Perfect Finish Model ET-1
Feature Benefit
Automatic Tension This system ensures stable stitch quality regardless of the type of
fabric.
Extra-High Presser Foot Lifter Advantageous when placing multiple layers or bulky fabric under the
presser foot.
Free Arm Provides professional results and easy access to cuffs, collars, pant
hems and other difficult-to-reach areas.
7-Segment Feeding System This is a specially designed feed dog that ensures that the fabric is
picked up and supported from the front of the presser foot to the rear.
This provides for much more accurate feeding of the fabric.
Box Feed
This is a function that moves the feed dogs in a box motion, rather than
the historic arc motion. Box motion assures perfect feeding throughout
the entire feed process, as the feed dogs are always in perfect and
equal contact with the fabric and presser foot.
Drop Feed A conveniently located lever lowers the feed dogs for free-motion
embroidery, monograms and button sewing.
On Board Storage Accessories can be conveniently stored in the removable sewing table.
Snap-On Presser Feet Easily change snap-on presser feet without use of a screwdriver.
Thread Cutter Located on the machine for precise thread cutting, eliminating the extra
step of cutting thread with scissors.
Perfect Finish Model ET-1
Feature Benefit
DC Motor Provides instant start up and stop with no coasting, for accurate and
precise stitch placement.
Standard Accessories
All-Purpose Foot (on machine)
Satin Stitch Foot
Zipper Foot
Blind Hem Foot
Overcasting Foot
Button Sewing Foot
Buttonhole Foot
Edge / Quilting Guide
Auxiliary Spool Pin
Thread Spool Caps (2)
Spool Pin Felt
Screwdrivers (2)
4 Standard Bobbins
Pack of Needles
Seam Ripper / Lint Brush
Extension Table
Soft-Sided Dust Cover
Foot Control
Instruction Manual
Power Cord
Value-Added Accessories
Darning & Embroidery Foot
Open Toe Foot
Rolled Hem Foot
Roller Foot
Pintuck Foot
Invisible Zipper Foot
Cording Foot
Gathering Foot
Quilting Foot
Value-Added Instructions
Warranty Limited 25-year warranty including 5-year electronic components and
1-year adjustments
SINGER and Perfect Finish are exclusive trademarks of The Singer Company Limited or its affiliates. © 2011 The Singer Sewing Company. All rights
reserved.
Perfect Finish Model ET-1
Feature Benefit
2-3-4 Stitch Configuration The 6 different stitch types ensure the perfect stitch, regardless of the project:
Blind Hems, Rolled Hems, Flatlocking, finishing raw edges and sewing seams
1,300 Stitches-Per-Minute Sews up to 1,300 stitches per minute—a real time-saver
Color-Coded Lay-In
Threading Makes threading a snap— just follow the color-coded diagram on the
machine
One-turn Numbered
Tension Dials Makes adjusting the tension effortless when sewing a variety of fabrics
Differential Feed Ensures an even feed for perfect seams on every fabric; useful for keeping
stretch fabrics and bias cut fabrics from becoming “stretched out”
Moveable Upper Knife Can easily move knife to prevent trimming of fabric while sewing
Stitch Length Dial
Effortlessly adjust the length of a stitch pattern
Electronic Speed Control Guarantees consistent sewing speed with no jump starts
Free Arm Sewing Makes it easy to sew hard-to-reach areas such as armholes, cuffs and
smaller projects
25 Year Limited Warranty 25-year manufacturer’s defects, 2-year electric and electronic components,
90-day parts and labor
Perfect Finish Serger Model 14ET754
Feature Benefit
Portable Carry handle makes for trouble-free to transporting
Extra-High
Presser Foot Lifter Offers extra clearance needed when placing multiple layers of fabric
under the presser foot
Accessories Tweezers, Needle Set, Spreader, Screwdriver and Dust Cover
Built-in Rolled Hem Converting to the Rolled Hem sewing mode is effortless. An easy
access lever moves the stitch finger in position for rolled hemming.
Four Thread Mock
Stretch Stitch A favorite when sewing a knit fabric because the stitch stretches as the
fabric stretches providing a strong and professional finish that will not
“pop” when the fabric is stretched.
Three Thread Overlock Stitch Provides a wonderful professional seam finish, helps prevent loosely
woven fabrics from unraveling, and offers unlimited decorative
capabilities
Three Thread Mock Stretch
Safety Stitch Ideal for finishing fine fabrics or highly stretchable fabrics
Two Thread Overlock Stitch Use as a lightweight seam finish or a lightweight seam on woven fabrics
Rolled Hem Stitch
Adds an elegant fine finish to table linens, scarves, and much more
Flatlock Stitch Special decorative threads can be used to add texture and a dramatic
embellishment effects
Perfect Finish Serger Model 14ET754
Feature Benefit
Standard Accessories
All Purpose Foot
Spreader
Tweezers
Needles
Screwdriver
Spools of Thread (4)
Foot Control
Power Cord
Instruction Manual
Perfect Finish Serger Model 14ET754
SINGER and Perfect Finish are an exclusive trademark of The Singer Company Ltd. or its affiliates. ©2011 The Singer Company Limited or its affiliates.
