SKF Shaft Alignment Tool
TKSA 51
Quick Start Guide
1. Description
1
2
3
8
4
5
6
7
1. Measuring unit S 5. Connection blue LED
2. Measuring unit M 6. Status red/green LED
3. Laser adjustment 7. Power button
4. Charging connector 8. V-Bracket with locking chain
2SKF TKSA 51
2. Compatible display devices
• SKF TKSA DISPLAY2, Samsung Galaxy Tab Active 2
and iPad Mini recommended
• iPad, iPod Touch, iPhone SE, Galaxy S6 or above
(all not included)
3. Installing the apps
The SKF Shaft Alignment Tool TKSA 51
is available with multiple apps.
Note:
These apps are pre-installed
and ready to use on the
SKF TKSA DISPLAY2 device.
1. Turn on Wi-Fi and connect
to an internet network
2. Tap the App Store icon (iOS)
or Google Play Store icon (Android)
3. Tap the search area
4. Enter “SKF TKSA 51”
5. Select the app you want to install
6. Tap “GET” (iOS only) and then “INSTALL”
7. Repeat to install the other apps available
3SKF TKSA 51
4. SKF alignment apps available
Shaft alignment app
Alignment of machines
with horizontal shafts
Spacer shaft app*
Alignment of machines
with spacer shafts
Soft foot app
Identification and
correction of soft foot
Vertical shaft app
Alignment of machines
with vertical shafts
Machine train app*
Alignment of
machine trains
Values app*
Use measuring heads
like digital dial gauges
5. Support
a. Instructions for use
Complete instructions for use for the apps and the hardware can
be found in:
Help section of the apps and SKF.com/Alignment
b. Technical support
SKF Technical Support website link is available in the help
section the apps. Please visit www.skf.com/cm/tsg to find help
or file a support request.
* TKSA 71 only
4SKF TKSA 51
c. Videos
Short instructional videos are available in the help section of
the apps.
More videos can be found on SKF Maintenance Products
YouTube page: www.mapro.skf.com/youtube
6. Mounting the measuring units
Mount the Measuring unit M on the Moveable machine.
Mount the Measuring unit S on the Stationary machine.
S M
Adjust the laser lines to the center of the detectors.
Start by vertically adjusting the Measuring Unit S on the rods.
Use the laser adjustment knob on the Measuring Unit M.
The sensor status of the
App indicates the correct
position.
The TKSA 51 can be
mounted directly on
couplings when needed.
5SKF TKSA 51
Safety recommendations
• The complete instructions for use are available on
SKF.com and within the SKF TKSA 51 app.
• Read and follow all warnings in this document before
handling and operating the equipment. You can be
seriously injured, equipment and data can be damaged
if you do not follow the safety warnings.
• Always read and follow the operating instructions.
• The equipment should not be used in areas where there
is a risk for explosion.
• The tool uses two laser diodes with an output
power below 1 mW. Still, never stare directly into
the laser transmitter.
• Never aim the laser line into someone’s eyes.
• The Measuring Units contains Lithium Polymer battery.
• Do not expose the device to extreme heat.
• Do not charge the Measuring units below
+4 °C (+40 °F) or above +45 °C (+113 °F).
• Dress properly. Do not wear loose clothing or jewellery.
Keep your hair, clothing, and gloves away from
moving parts.
• Do not overreach. Keep proper footing and balance at
all times to enable better control of the device during
unexpected situations.
• Use safety equipment. Non-skid safety shoes, hard
hat or hearing protection must be used for appropriate
conditions.
• Never work on energized equipment unless authorized
by a responsible authority. Always turn off the power of
the machine before you start.
• Do not expose the equipment to rough handling or
impacts this will void the warranty.
• Avoid direct contact with water, wet surfaces, or
condensing humidity.
• Do not attempt to open the device.
• Use only accessories that are recommended by SKF.
• Device service must be performed only by qualified
SKF repair personnel.
• We recommend calibrating the tool every 2 years.
WARNING
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
P
≤
1mW
l
=
635nm
Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries.
App Store is a service mark of Apple Inc.
Android, Google Play and the Google Play logo are trademarks of Google Inc.
SKF Maintenance Products
® SKF is a registered trademark of the SKF Group.
© SKF Group 2018/03
www.mapro.skf.com • www.skf.com/mount • MP5448EN
The contents of this publication are the copyright of the publisher and may not be reproduced (even
extracts) unless prior written permission is granted. Every care has been taken to ensure the accuracy
of the information contained in this publication but no liability can be accepted for any loss or damage
whether direct, indirect or consequential arising out of use of the information contained herein.
EU Declaration of conformity
We,
SKF Maintenance Products
Kelvinbaan 16
3439 MT Nieuwegein
The Netherlands
herewith declare that the following product:
SKF Shaft Alignment Tool
TKSA 51
has been designed and manufactured in accordance with:
RADIO EQUIPMENT DIRECTIVE 2014/53/EU as outlined in the
harmonized norm
EN 61010:2010, EN 61326-1:2013 Class B, group 1 equipment,
IEC 61000-4-2:2009, IEC 61000-4-3:2006,
EN 301 489-1 v2.1.1, EN 301 489-17 v3.1.1, EN 300 328 v2.1.1
EUROPEAN ROHS DIRECTIVE 2011/65/EU
The laser is classified in accordance with the EN 60825-1:2007.
The laser complies with 21 CFR 1040.10 and 1040.11 except for
deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
The enclosed device complies with Part 15 of the FCC Rules.
47CFR: 2011 Part 15 Sub Part B Unintentional Radiators
Contains FCC ID: QOQBLE112
Certification Number IC: 5123A-BGTBLE112
Manufacturer’s Name, Trade Name or Brand Name: bluegiga
Model Name: BLE112-A
Nieuwegein, The Netherlands,
February 2017
Sébastien David
Manager Product Development and Quality
