F 012 258 500
CORDLESS ROTARY HAMMER 2585
21.09.2006
16:42:40
Pa
g
e 1 of 3
9/21/2006htt
p
://le11288.le.de.bosch.com/sid/
p
rintdirect.as
p
?ID
_
PRODUCT=F012258500&ID
_
VE
R
...
Item Quantity Order No. Designation Price group Page
1 1 2 610 912 863 HOUSING SECTION 1
3 1 2 606 316 181 PINION 1
4 1 2 607 200 353 ON-OFF SWITCH 1
5 1 2 601 099 116 ADJUSTING SLIDE 1
8 1 2 610 913 252 NAMEPLATE 1
9 1 2 610 913 250 LABEL 1
20 12 610 913 251 WARNING LABEL 1
25 12 610 913 340 CHUCK 1
29 12 600 290 043 MAGNET DISK 1
32 12 601 099 098 ADJUSTING SLIDE 1
45 12 606 200 152 EPICYCLOIDAL GEAR TRAIN 1
50 12 605 719 027 INTERMEDIATE FLANGE 1
55 12 608 040 198 HANDLE COVER 1
101 72 603 490 018 TORX OVAL-HEAD SCREW 1
107 12 603 421 229 COUNTERSUNK-HEAD SCREW \ M 6x23 1
651 12 607 335 328 ACCUMULATOR BATTERY \ 14,4V,1,25Ah,NiCd 1
653 12 607 224 631 CHARGER \ USA/CAN 120/14,4V, 5h 1
655 12 602 025 067 AUXILIARY HANDLE \ M10, Ø 32,5x105 1
802 12 610 913 393 BATTERY-OPERATED DRILL 1
Pa
g
e 2 of 3
9/21/2006htt
p
://le11288.le.de.bosch.com/sid/
p
rintdirect.as
p
?ID
_
PRODUCT=F012258500&ID
_
VE
R
...
Pa
g
e 3 of 3
9/21/2006htt
p
://le11288.le.de.bosch.com/sid/
p
rintdirect.as
p
?ID
_
PRODUCT=F012258500&ID
_
VE
R
...
