SKYLOTEC LORY Manuale utente

27.03.19 Staut

Use only compatible ropes.

press

& slide

EN 15151-1:2012

dyn. 8.9-11.0mm

stat. 9.0-12.0mmø

EN 341:2011/2A

11mm, 30-180kg

H 190m, Tmin -20°C

EN 12841-C:2006

10-12mm, 225kg

A-040

xxxxxx-zzz

mm/yyyy

MAT-BA-0173-00

Stand 09.04.2019

Instruction for use

Gebrauchsanleitung

Istruzioni d‘uso

Instructions d‘utilisation

Instrucciones de uso

Instruções de serviço

Gebruiksaanwijzing

Brugsanvisning

Bruksanvisning

Käyttöohjeet

Bruksanvisning

Οδηγίες χρήσης

Talimatlar

Instrukcje

Használati útmutató

Návod k použití

Návod na použitie

Instrucţiuni de utilizare

Navodila

Инструкция за употреба

Upute za uporabu

GEBRAUCHSANLEITUNG

LORY PRO

LORY

PSA- VO (EU) 2016/425

07.06.16

27.03.19 Staut

xxxxxx-zzz

mm/yyyy

EN 12841-C:2006

10-12mm, 225kg

EN 341:2011/2A

11mm, 30-180kg

H 190m, Tmin -20°C

ANSI/ASSE Z359.4

11mm, H 190m

1-person load, 59-141kg

Max. n. of descents, 28

ANSI/ASSE Z359.3

10.5-11mm, 59-141kg

meets CSA Z259.11-05, Class F

Avoid descending into el.,

therm., and chem. hazards.

EN 795-B:2012

Single person use

With Rope for Lory Pro

Use only compatible

ropes and lanyards.

press

& slide

SKYLOTEC GmbH

Im Mühlengrund 6-8

56566 Neuwied · Germany

Fon +49 (0)2631/9680-0

Mail [email protected]

Web www.skylotec.com

Informationen/ Informations

GB Instructions for use

Icons Seite 4-11

Explanation Seite 12-16

DE Gebrauchsanleitung

Icons page 4-11

Erklärung page 17-22

IT Istruzioni per l‘uso

Icons pagina

4-11

Delucidazion pagina 22-26

FR Instructions d´utilisation

Icônes page 4-11

Explications page 27-31

ES Instrucciones de uso

Icons página 4-11

Declaración página 32-37

PT Instruções de serviço

Icons página 4-11

Declaração página 38-42

NL Gebruiksaanwijzing

Pictogrammen pagina 4-11

Uiteenzetting pagina 43-47

DK Brugsanvisning

Icons side 4-11

Forklaring side 48-52

NO Bruksanvisning

Ikoner side 4-11

Forklaring side 53-57

FI Käyttöohjeet

Icons sivu 4-11

Selitys sivu 58-62

SE Bruksanvisning

Icons sida 4-11

Förklaring sida 63-67

EL Οδηγίες χρήσης

 Εικονίδια Σελίδα4-11

 Επεξήγηση Σελίδα68-73

TR Talimatlar

Icons sayfa 4-11

 Açıklama sayfa74-78

PL Instrukcja obslugi

Icons strona 4-11

 Wyjaśnienie strona79-84

HU Használati útmutató

Jelek 4–11. oldal

 Magyarázat 85-90.oldal

CS Návod k použití

Ikony Strana 4–11

 Popis Str.91-95

SK Návod na použitie

Ikony Strana 4 – 11

 Vysvetlenie strana96-100

RO Instrucțiuni de utilizare

Pictograme Paginile 4-11

 Notăexplicativă Paginile101-105

SL Navodila

Icons Page 4-11

 Izjava Page106-110

BG Инструкции за употреба

 Иконки страница4–11

 Обяснение страница111-116

HR Upute za uporabu

Ikone Stranica 4-11

Objašnjenje Stranica 117-121

Nutzung in Ordnung

Vorsicht bei der Nutzung

Lebensgefahr

+Zusätzliche Absturzsicherung erforderlich

Standards/Normen

Norm LORY LORY

PRO Use

EN 341

Class A Rescue

EN 12841

Type C Rope access

EN 795

Type B

Anchoring

device

ANSI/ASSE

Z359.3

Work

positioning and

restraint

ANSI/ASSE

Z359.4:2013 Rescue system

meets CSA

Z259.11-05

Work

positioning and

restraint

EN 15151-1 Belay device

with assisted

locking

EN 341:2011 Class 2A Ropes diameter Ø 11 mm

EN 12841:2006

Type C Ropesdiameter10mm< Ø < 12 mm

EN 15151-1:2012

Type 8

Dynamic ropes diameter 8.9 mm < Ø

<11.4mmlowstretch9mm<Ø<12mm

EN 795:2012

Type B RopesdiameterØ10.5mmand11mm

ANSI/ASSE Z359.3-2007 RopesdiameterØ10.5mmand11mm

ANSI/ASSE Z359.4-2013 Ropes diameter Ø 11 mm

CSA Z259.11-05, Class F RopesdiameterØ10.5mmand11mm

WARNING: Activities done at heights are inherently dangerous.

Understand and accept the risks involved before participating. You

are responsible for your own actions and decisions. Before using

this product, read and understand all instructions and warnings that

accompany it and familiarise yourself with its proper use, capabilities

and limitations. We recommend that every climber seeks proper

training in the use of the equipment. Failure to read and follow

these warnings can result in severe injury or even death!

EN 341:2011 Class 2A

Working load:

minimumratedloadis30kg,

maximumratedloadis180kg.

Maximum descent distance:

190m(inthiscaseapprovedfor22consecutivedescents)

Approved temperature range:

-20°C≤approvedtemperature≤+60°C

Rope Type (S):

TestsaccordingtothenormEN341:2011havebeenperformed

withthefollowinglowstretchkernmantelropes(concordantwith

EN1891).

Rope model Static R44 11.0

Diameter 11,2 mm

Sheath slippae Ss 0,1%

Elongation E 3,2%

Mass per metre m 77 g/m

Sheath proportion Sp 38%

Core proportion 62%

Shrinkage R 3,7%

Material PA

Tested and approved for descents with a released energy of 7,5 MJ

(accordingtoEN341ClassA).

W = m x g x h x n

m: mass(kg)

g: accelerationofgravity=9,81m/s2

h: height(m)

n: number of descents

EN 12841:2006 Type C

Certied for use with low stretch (EN 1891 TypeA) ropes with

diametersbetween10mmand12mm.

Diameter Maximum rated load

10mm-12mm 225 kg

EN 795:2012 Type B

CertiedforusewithRopeforLORYPRO.

ANSI/ ASSE Z359.4-2013

Single-personuse:(130lbto310lb,59kgto141kg);

Maximumdescentdistance:620ft=190m;

Maximumdescentrate:6.6ft/s≈2m/s;

Maximumnumberofdescents:28;

Rope: low-stretch, Ø = 11 mm.

Tested and approved for multiple descents with a released

energyof5500000foot-pounds.Thedescentenergyratingis

determined by:

E = W x H x N

W:Testweight(lb)

H:Descentheight(ft)

N: Number of descent

ANSI/ ASSE Z359.3-2007

Single-personuse:(130lbto310lb,59kgto141kg);

To be combined with Rope for LORY PRO only.

LORY PRO is a multi purpose device for single rope. In the EU it is

certied according to the standards EN 341:2011 Class 2A EN

12841:2006TypeC,EN795:2012TypeB.Whiletherststandard

is meant for rescue purposes only the second implies rope access.

The third standard covers temporary anchor devices. Additionally,

onlyLORYiscertiedaccordingtothestandardEN15151-1:2012

as a belay device with assisted locking. In North America LORY

PRO is certied according to ANSI/ASSE Z359.4 for assisted-

recueandself-rescuesystems,ANSI/ASSEZ359.3forpositioning

andtravelrestraintsystemsandmeetsCSAZ259.11-05,classFas

an adjustable positioning lanyard.

1.) Installation of the rope/ Anbringung des Seils

Rope outlet

(workingend)

Rope inlet

(freeend)

Eyelet for drop prevention cord

Brake handle

Carabiner

attachment hole

Pivoting cam

Opening

button

1.c

1.a 1.b

Model

Read the instructions sign

Body controlling the manufacturing of PPE

Manufacturer or supplier

Information about the several standards and

the acc.rope diameter and temperature

Batch number - serial number - year and month

of the manufacture

27.03.19 Staut

Use only compatible ropes.

press

& slide

EN 15151-1:2012

dyn. 8.9-11.0mm

stat. 9.0-12.0mm

EN 341:2011/2A

11mm, 30-180kg

H 190m, Tmin -20°C

EN 12841-C:2006

10-12mm, 225kg

A-040

xxxxxx-zzz

mm/yyyy

Data on LORY/ Beschriftung LORY

Manufacturer´s adress

2. Functional principles/ Funktionsprinzip

3. Operational check/ Funktionsprüfung

4. Descent and short ascents/ Der Abstieg und kurze Aufstieg

4.a

4.b

4.c

Stop Position

Stop

Position

5. Accompanied descent/ Abstieg mit Rettungshelfer

max. 1 m/s

> 11 mm

6. Hauling and progress capture systems/

Einfache Flaschenzüge und Flaschenzüge mit Bremse

Pulley/AR-35

Bloquer/AB-20

Maximum load = 225 kg

7. Rigging for rescue/ Anbringung der Rettungsausrüstung

LORY

8. Work on wind turbines

WORK ON WIND TURBINES

LORY

9. Belaying/ Sicherung

10. Temporary anchoring around a structure/

Vorübergehende Verankerung um die Struktur

10.a 10.b

NO!

Girth hitch

Protector

Unsecured

10.d10.c

EN 358 device

(e.g.LORYWP)

Attachment

termination

Sliding

protector

Rope

Stopper

termination

Rope for LORY PRO

Certied for use only with

Rope for Lory Pro.
