SMART M685i6 Manuale utente

SMARTBoard® M600i6

Interactive whiteboard systems

Configuration and user’s guide

For models M680i6 and M685i6

smarttech.com/kb/170549

FCC warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause harmful interference to radio communications. Operation of

this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Trademark notice

SMARTBoard, SMARTNotebook, SMARTMeetingPro, DViT, smarttech, the SMART logo and all SMART taglines are trademarks or registered trademarks of

SMARTTechnologiesULC in the U.S. and/or other countries. Microsoft, Windows and InternetExplorer are either registered trademarks or trademarks of Microsoft

Corporation in the U.S. and/or other countries. All other third-party product and company names may be trademarks of their respective owners.

into any language in any form by any means without the prior written consent of SMARTTechnologiesULC. Information in this manual is subject to change without notice

and does not represent a commitment on the part of SMART.

This product and/or use thereof covered by one or more of the following U.S. patents: smarttech.com/patents.

11/2013

i smarttech.com/kb/170549

Important information

Before you install and use your SMARTBoard®M600i6 interactive whiteboard system, read and

understand the safety warnings and precautions in this user’s guide and the included important

information document. These safety warnings and precautions describe the safe and correct

operation of your interactive whiteboard system and its accessories, helping you to prevent injuries

and equipment damage. Ensure that your interactive whiteboard system is always being used

correctly.

In this document, “interactive whiteboard system” refers to the following:

lSMARTBoard M600 series interactive whiteboard

lSMARTUF70 or SMARTUF70w projector

lAccessories and optional equipment

The projector included with your system is designed to work only with certain SMARTBoard

interactive whiteboard models. Contact your authorized SMART reseller (smarttech.com/where) for

more information.

Safety warnings, cautions and important

information

Installation

WARNING

lFailure to follow the installation instructions shipped with your SMART product could result in

personal injury and damage to the product.

lTo reduce the risk of fire or electric shock, do not expose the SMART product to rain or

moisture.

I M P O R T A N T I N F O R M A T I O N

ii smarttech.com/kb/170549

lTwo people are required to mount your SMART product because it may be too heavy for one

person to safely maneuver.

When you lift your interactive whiteboard, you and your assistant should stand on either side

of the screen, supporting its weight at the bottom while balancing the top with your other

hands.

lWhen mounting the projector boom on a framed or hollow wall, attach the mounting bracket to

a stud to safely support the projector’s weight. If you use only drywall anchors, the drywall can

fail, resulting in possible personal injury, and damage to the product which may not be covered

by your warranty.

lDo not leave cables on the floor where they can be a tripping hazard. If you must run a cable

over the floor, lay it in a flat, straight line and secure it to the floor with tape or a cable

management strip of a contrasting color. Handle cables carefully and avoid excessive

bending.

C A U T I O N

lDo not operate this unit immediately after moving it from a cold location to a warm location.

When the unit is exposed to such a change in temperature, moisture can condense on the lens

and crucial internal parts. Allow the system to stabilize to room temperature before operation

to prevent possible damage to the unit.

lDo not place the unit in hot locations, such as near heating equipment. Doing so could cause a

malfunction and shorten the life of the projector.

lAvoid setting up and using the SMART product in an area with excessive levels of dust,

humidity and smoke.

lDo not place your SMART product in direct sunlight or near any appliance that generates a

strong magnetic field.

lYou must connect the USB cable that came with your SMARTBoard interactive whiteboard to

a computer that has a USB compliant interface and that bears the USB logo. In addition, the

USB source computer must be compliant with CSA/UL/EN 60950 and bear the CE mark and

CSA and/or UL Mark(s) for CSA/UL 60950. This is for operating safety and to avoid damage to

the SMARTBoard interactive whiteboard.

I M P O R T A N T

lMake sure an electrical socket is near your SMART product and remains easily accessible

during use.

I M P O R T A N T I N F O R M A T I O N

iii smarttech.com/kb/170549

lUsing your SMART product near a TV or radio could cause interference to the images or

sound. If this happens, move the TV or radio away from the projector.

Operation

WARNING

lIf you are using an external audio system, use only the power supply included with that

product. Using the wrong power supply might create a safety hazard or damage the

equipment. If in doubt, refer to the specification sheet for your product to verify the power

supply type.

lDo not climb (or allow children to climb) on a wall- or stand-mounted SMARTBoard interactive

whiteboard.

Do not climb on, hang from or suspend objects from the projector boom.

Climbing on the interactive whiteboard or projector boom could result in personal injury

or product damage.

C A U T I O N

lDo not block the projector’s ventilation slots and openings.

I M P O R T A N T

lKeep your remote control in a safe place because there is no other way to access menu

options.

lDisconnect the product from its power source when it’s not used for a long period.

Other precautions

If you own a SMARTproduct other than a SMARTBoard M680i6 and M685i6 series interactive

whiteboard system, refer to the installation manual for your product for relevant warnings and

maintenance instructions.

I M P O R T A N T I N F O R M A T I O N

iv smarttech.com/kb/170549

Environmental requirements

Before you install your SMARTBoard M600 interactive whiteboard system, review the following

environmental requirements.

Environmental

requirement

Parameter

Operating temperature l41°F to 95°F (5°C to 35°C) from 0' to 6000' (0 m to 1800 m)

l41°F to 86°F (5°C to 30°C) from 6000' to 9800' (1800 m to 3000 m)

Storage temperature l-4°F to 122°F (-20°C to 50°C)

Humidity l5% to 95% storage relative humidity, non-condensing

5% to 85% operating relative humidity, non-condensing

Water and fluid

resistance

lIntended for indoor use only. Doesn’t meet any salt-spray or water

ingress requirements.

lDon’t pour or spray liquids directly onto your interactive whiteboard,

the projector or any of its sub-components.

Dust lIntended for use in office and classroom environments. Not for

industrial use where heavy dust and pollutants can cause

malfunctions or impaired operation. Periodic cleaning is required in

areas with heavier dust. See Cleaning the projector on page 24 for

information on cleaning the projector.

Electrostatic discharge

(ESD)

lEN61000-4-2 severity level 4 for direct and indirect ESD

lNo malfunction or damage up to 8kV (both polarities) with a 330ohm,

150 pF probe (air discharge)

lUnmated connectors meet no malfunction or damage up to 4kV (both

polarities) for direct (contact) discharge

Cables lAll SMARTBoardM600i6 interactive whiteboard system cables

should be shielded to prevent potential accidents and degraded video

and audio quality.

Conducted and radiated

emissions

lEN55022/CISPR 22, Class A

v smarttech.com/kb/170549

Contents

Important information i

Safety warnings, cautions and important information i

Environmental requirements iv

Chapter 1: About your interactive whiteboard system 1

SMARTBoardM600i6 interactive whiteboard system features 2

Included accessories 4

Chapter 2: Installing your interactive whiteboard system 5

Choosing a location 6

Choosing a height 6

Securing the projector to the boom 6

Routing the cables 7

Installing SMART software 7

Chapter 3: Using your interactive whiteboard system 9

Using your projector 9

Using your interactive whiteboard 21

Chapter 4: Maintaining your interactive whiteboard system 23

Maintaining your interactive whiteboard 23

Cleaning the projector 24

Focusing and adjusting the projector image 25

Replacing the projector lamp 26

Chapter 5: Troubleshooting your interactive whiteboard system 31

Before you start 32

Determining you interactive whiteboard system’s status 33

Resolving interactive whiteboard issues 34

Resolving projector issues 35

Accessing the service menu 42

Transporting your interactive whiteboard system 43

Appendix A: Remotely managing your system through a network interface 45

Web page management 45

Simple Network Management Protocol (SNMP) 52

Appendix B: Remotely managing your system through an RS-232 serial interface 53

Serial interface settings 54

C O N T E N T S

vi smarttech.com/kb/170549

Projector programming commands 55

Appendix C: Integrating other devices 79

Video format 79

Connecting peripheral sources and outputs 85

Appendix D: Remote control code definitions 87

Appendix E: Hardware environmental compliance 89

Waste Electrical and Electronic Equipment and Battery regulations (WEEE and Battery

Directives) 89

Batteries 89

Mercury 89

More information 89

Index 91

Chapter 1

1 smarttech.com/kb/170549

Chapter 1: About your interactive

whiteboard system

SMARTBoardM600i6 interactive whiteboard system features 2

SMARTBoard M600 series interactive whiteboard 2

SMARTUF70 or SMARTUF70w projector 3

Included accessories 4

Remote control 4

Pens 4

Optional accessories 4

Your SMARTBoardM600i6 interactive whiteboard system combines the following components:

lSMARTBoard M600 series interactive whiteboard

lWall-mounted, short-throw SMARTUF70 or SMARTUF70w projector

lAccessories and optional equipment

This chapter describes the features of your interactive whiteboard and provides information about

product parts and accessories.

C H A P T E R 1

About your interactive whiteboard system

2 smarttech.com/kb/170549

SMARTBoardM600i6 interactive whiteboard

system features

Your SMARTBoardM600i6 interactive whiteboard

system uses the short-throw, high-offset

SMARTUF70 or SMARTUF70w projector. The throw

distance of the SMARTUF70 and SMARTUF70w

projectors is half that of the SMARTUF65 projector,

resulting in a shorter boom and reduced shadows on

the projected image.

When the projector displays an image from your

computer on the touch-sensitive interactive

whiteboard, you can do everything that you can do at

your computer—open and close applications, scroll

through files, conference with others, create new

documents or edit existing ones, visit websites, play

video clips and more—by touching the screen. You

can use an array of gestures within applications.

This projector also supports video and audio connections from a variety of devices, including

DVD/Blu-ray™ players, VCRs, document cameras and digital cameras, and can project media from

these sources onto the interactive screen.

When you use SMART software with your SMARTBoardM600i6 interactive whiteboard system, you

can write or draw over the projected computer image in digital ink using a pen tray pen or your finger,

and then save these notes to a .notebook file or directly into any Ink Aware application.

SMARTBoard M600 series interactive whiteboard

Your SMARTBoard M600 series interactive whiteboard, featuring SMART’s proprietary DViT®

(DigitalVisionTouch) technology, is the most intuitive touch-sensitive front projection interactive

whiteboard in the world.

The SMARTBoard M600 series interactive whiteboard performs best with the SMART UF70

projector because of its exceptional color performance, aspect ratio, input response and short-throw

image distance.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali SMART Lavagna bianca

SMART

SMART kapp Series Manuale utente

SMART

SMART KAPP IQ Manuale utente

SMART

SMART SMART Board Manuale utente

SMART

SMART V280 Manuale utente

SMART

SMART SB885 Manuale utente

SMART

SMART Board 800ix3 Manuale utente

SMART

SMART SBM600V Manuale utente

SMART

SMART AirLiner WS100 Istruzioni per il montaggio

SMART

SMART SMART Board 800ix Configuration and user's... Manuale utente

SMART

SMART Meeting Pro 4 Manuale utente

SMART

SMART SBM600 Manuale utente

SMART

SMART Board 600 Series Guida all'installazione

SMART

SMART Board 4000 Series Istruzioni per l’uso

SMART

SMART Board 880 Manuale utente

SMART

SMART kapp Manuale utente

SMART

SMART 6000 Series Manuale utente

SMART

SMART 880i5-SMP Manuale utente

SMART

SMART 6000S Series Guida all'installazione

SMART

SMART Smart Board 480 Manuale utente

SMART

SMART KAPP-IQ55 Manuale utente

SMART

SMART Board 8000 series Manuale utente

SMART

SMART 885ix2 Manuale

SMART

SMART SMART Board D685ix Manuale utente

SMART

SMART SBM680E Manuale utente

Manuali Lavagna bianca popolari di altre marche

Copernicus

Copernicus RC105 Manuale utente

IKEA

IKEA MALA 104.889.67 Manuale utente

funtronic

funtronic EasyBoard Manuale utente

Best-Rite

Best-Rite Baby Folding Wheasel 784-T Manuale utente

Best-Rite

Best-Rite Modular Room Divider Manuale utente

IKEA

IKEA MALA 504.565.92 Manuale utente

Panasonic

Panasonic TX-47P800HQ TX-47P800HZ Manuale utente

Quartet

Quartet QRT-72981 Manuale utente

EGAN

EGAN GlassWrite TableScreen TSG Manuale utente

Claridge

Claridge Edify Mobile Manuale utente

Legamaster

Legamaster e-Board Touch 2 Manuale utente

Nureva

Nureva WALL Manuale utente

Best-Rite

Best-Rite Black Splash Manuale utente

Da-Lite

Da-Lite Cosmopolitan Electrol Manuale utente

Steelcase

Steelcase H. System Manuale utente

Epson

Epson AN2WA87 Manuale utente

Rapidline

Rapidline GB96 Manuale utente

Luxor

Luxor WB3624W Manuale utente
