INSTRUCTION MANUAL
INDUCTION COOKER
MODEL: BT-700D3(T)
PRODUCT CODE: ISC-BT-700D3(T)
Read the instructions before using the machine
1. Specication
Model No: BT-700D3(T)
Power Rate: 7000W
Voltage: 220-240V / 1N ~ 50/60 Hz
Temperature: 60°C - 240°C
2. Caution
• Do not plug in with wet hands.
• Do not plug into a socket where several other appliances are plugged in.
• Do not use if the plug cord is damaged or the power plug does not t the socket safely.
• Do not modify the parts, or repair the unit by yourself.
• Do not use the unit near ame or wet places.
• Do not use where children can easily touch the unit, or allow children to use the unit by
themselves.
• Do not place on unstable surfaces.
• Do not move the unit when the pot or the pan is on it.
• Do not heat the pot empty or overheat the pot.
• Do not place metallic objects such as knives, forks, spoons, lids, cans, and aluminum foils on
the top plate since they can get hot.
• Use the unit with sucient space around it. Keep the front side and either right or left side of
the unit clear.
• Do not use the unit on carpet or tablecloth (vinyl) or any other low-heat-resistant article.
• Do not place a sheet of paper between the pot or the pan and the unit. The paper may get
burnt.
• If the surface is cracked, switch o to avoid the possibility of electric shock and then take to
the service center immediately.
• Do not block air intake or exhaust vent.
• Do not touch the top plate right after removing the pot or the pan, as the top plate will still be
very hot.
• Do not place the unit near objects which are aected by magnets, such as: radios, televi-
sions, automatic-banking cards and cassette tapes.
• The power cord must be replaced by qualied technicians.
• CAUTION: Hot surface.
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervision.
• The temperature of accessible surfaces may be high when the appliance is operating.
• The appliance is not intended to be operated by means of an external timer or separate
remote control system.
• This product contains recyclable materials. Do not dispose this product as unsorted
municipal waste. Please contact your local municipality for the nearest collection point.
• Metallic objects such as kitchen utensils, cutlery etc. shall not be placed on the hob surface
within the cooking zones since they could get hot;
• Take care when operating the appliance, as rings, watches and similar objects worn by the
user could get hot when in close proximity to the hob surface
• Only use vessels of the type and size recommended.
• After use, switch the hob element o by means of its control. Do not rely on the pan detector.
• Appliance not to be cleaned with water jet.
• Any repairs shall be carried out only by persons trained or recommended by the
manufacturer.
• Care must be taken to ensure that the splash back and surrounding area free of metallic
surfaces
• Non-ionizing electromagnetic radiation, be careful.
• DANGER: High voltage.
• Appliance is not intended to be operated by means of an external timer or separate remote-
control system.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a hazard.
• Means for disconnection must be incorporated in the xed wiring in accordance with the
wiring rules
• Additional protective device of residual- current device of 30 mA shall be installed on the xed
wiring before connected to the xed wiring
Warning: Children should be supervised to ensure that they do not play with the appliance.
Power line connection
The using standard of power line is: 3G×4.0mm (core number × section).
When installation, please use special electricity air protection switch, and the switch must be
installed in a convenient or easy controlled place, and the installation place should reach a height
of 1.3M to 1.5M .The required electricity current of the switch is 35A.
The socket shall be connected according to the relevant standard or connected to a single-pole
cut-out. The method of connection is shown in Figure (3):
Voltage Power cord connection
3. How to Use
1. After the “ ” key is pressed, the indicators show ”---”. Place the pot on the heating zone
and press the “ ” button, the indicator displays 2000, then adjust the power levels from
100 to 3500 by using the“ ” or “ ” button. The signal “ ” means control the zone 1, the
signal “ ” means control the zone 2. The display and the operation of the two zone is the
same.
2. There will be no display under standby condition, the hob is heating when the digital such as
“2000” was displayed in screen.
3. When you want to stopped use, press “ ” until “----” is displayed, and come into standby
condition.
4. Lock function: To ensure the safety of children, the induction hotplate is provided with the
lock function. Press the “ ” key until the indicator light is switch on. The induction hotplate
enters the locking state. All keys, except the “ ” key, is disabled.
5. Unlocking: Press the “ ” key for 2 seconds until the indicator light is switch o, then every
key can be used.
6. The hob will shut o automatically if there has been no operation for 2 hours.
7. The temperature of accessible surfaces may be high when the appliance is operating.
Error code SolutionPossible cause
E0
E1
E2
E3
No cookware or incorrect
cookware on the hob.
Device is too hot.
Overheating protection is
active.
Power input has changed.
Place suitable cookware on the cooking
zone.
Clean ventilation slots and allow the unit
to cool for a few minutes.
Remove cookware from the hob, switch
off and allow to cool for a few minutes.
Switch off and allow the unit to cool.
If the problem persists, contact your
SmartChef-i distributer.
4. Should an abnormality occur, the induction hotplate will enter the protective
state automatically and display one of the following error codes:
5.Usable and Non-usable Utensils
Usable Pans
Steel or cast iron, enameled iron, stainless steel, at-bottom pans / pots with diameter from 12 to
26cm.
Non-usable Pans
Heat-resistant glass, ceramic container, copper, aluminum pans/pots. Rounded-bottom pans/pots
with bottom measuring less than 12cm.
Enameled Iron
Pot
Rounded Bottom
Pot
Aluminum
Copper Kettles
Bottom Measuring
less than 12cm
Pot with Stands Ceramic Pot Heat-resistant
Glass Pot
Iron or Enameled
Kettle
Cast-iron Pan Iron Kettle Deep-fry Pan Stainless Steel
Pot
Iron Plate
6. How to Clean
1. Disconnect plug and wait until the unit is cooled down completely. Clean after using every
time.
2. If the pots/pans are used without being cleaned, discoloration or cooked on stains may be
caused.
3. Do not use benzene, thinner, scrubbing brush or polishing powder to clean the induction
cooker.
4. Wipe using dish washing agent and damp cloth.
5. Use vacuum cleaner to suck up dirt from the air intake and exhaust vent.
6. Never run water over the unit (Water gets inside may cause malfunction).
This appliance is not intended to be operated by means of an external timer or separate remote-
control system.
This appliance is intended to be used in household and similar applications such as:
• Sta kitchen areas in shops, oces and other working environments.
• Farm houses.
• By clients in hotels, motels and other residential type environments.
• Bed and breakfast type environments.
Zhongshan Better Home Appliance Co., Ltd.
No.3 Jian’an Road, Nantou Town, Zhongshan, 528427, Guangdong, China
Imported and distributed by
(Pty)Ltd.
