Smartec STC-3580 ULTIMATE Manuale utente
www.smartec-security.eu
Professional
Embedded Type Dome Camera
Smartec STC-3580 ULTIMATE
USER’S MANUAL
Strong points
1. Best sensitivity in the
world (0.00004 lux F#1.4
50IRE)
2. 700 TV line in B/W and 580TV line in color.
3. ICR type day & night is suitable for 24
hours surveillance.
4. IP66 certified.
5. Vandal-proof
6. All the funcitons are controlled through OSD.
7. Full 3 axis bracket built-in
Information
Read this user guide carefully before any installation for safe operation of
product.
WARNING
1. Do not disassemble the unit yourself. When there is a problem with the unit
pleasecontact the security service provider or place of
purchase.
2. Use only regulated power source.
3. Do not disassemble or re-model the camera, it could cause fire, electric
shock or other hazards.
Caution
Configuration
Contents
Strong Points, Caution page 1
Configuration, Lens pin connection, Lens page 3
Contents in box page 4
Installation page 5
Connection page 6
Menu Setting, Menu Directory page 7
Menu details page 8-19
Dimension page 20
Specification page 21
Warranty Service page 22
Contents in box
Open the box and check the contents
1.Dome camera
2.Surface mount adaptor
3.Manual
4.Extra video cable
5.Screws to fix camera to surface mount adaptor
6.Screws to fix surface mount adaptor
7.Hold cover of surface mount adaptor
8.Opening tool
9.L wrench
Installation
Connecting the power and video
Setting menu
Menu details
Menu details
