Open Permit Join
In addition to extending the range of Zigbee devices, the ZBRE also serves as a router and allows
other Zigbee devices to join the network. After the ZBRE has already joined the network (LED is
solid green), proceed as follows:
1. Press and hold the Program Button for 6 seconds. The Status LED will begin to ash rapidly.
The ZBRE will allow joining of other devices for up to 4 minutes.
2. Join the new Zigbee device to the network according to the join method of that device.
3. When the ZBRE has timed out for join permission, the Status LED will return to solid green.
2017 Compacta International, Ltd. - Rev. 6/2019
ZBRE and Smartenit are trademarks of Compacta International, Ltd.
Zigbee is a registered trademark of the Zigbee Alliance
(949) 429-3303
Technical Support
Smartenit.com
Quick Start Guide - ZBRE-U Model
Product Brief
Set-up
Zigbee Range Extender
Installation
Join Network
• Open a Zigbee router or network coordinator to permit joining of your ZBRE to the network.
• When the ZBRE has joined the network, the Status LED will stop ashing. If the Status LED remains
ashing, the device is unable to join the network.
The ZBRE provides the means to easily extend the range of
your Zigbee devices as well as increase the strength of your
Zigbee wireless network.
The built-in high power Zigbee radio joins the network as a
router and then facilitates the joining of devices that may not
be within range of the network. Use of the Zigbee standard
ensures compatibility with the emerging standards for smart
homes/buildings being deployed around the world.
Reset to Factory Defaults
• Press and hold the Program Button (located on the LED itself) while powering the ZBRE into a USB port
and release after 1-2 seconds.
• The Status LED will blink rapidly indicating the ZBRE has been reset and is searching for an open net-
work to join.
The ZBRE must be installed indoors or in a weather proof enclosure. The ZBRE USB stick can be attached
to a computer or a USB adapter to plug directly to a wall.
2017 Compacta International, Ltd. - Rev. 6/2019
ZBRE and Smartenit are trademarks of Compacta International, Ltd.
Zigbee is a registered trademark of the Zigbee Alliance
Program Button Additional Operation
Desired Operation Action on Pushbutton Device Behavior
Leave Network
Press and hold for 15
seconds
Status LED will
begin Fast Flashing
Close Join
Press and hold for 3
seconds when device is
in Open Join
Status LED will stop
ashing
Request New Firm-
ware via OTA
Tap 6 times LED will quick blip
o, once every
second while
OTA update is in
progress
Soft Reset
Tap 10 times LED will go out for
about a second and
then device will
rejoin network
Status LED Indication
Pattern Indication
Fastest ashing Joining/Rejoining network
Flash once per second Permit-Join mode
Solid Joined to network
Two blips per second Device cannot nd “Parent
Device” and/or network it
was joined to
(949) 429-3303
Technical Support
Smartenit.com
HA Prole: (0x0104)
Zigbee Device ID: 0x0008 (Range Extender)
Cluster ID Cluster Name Client/Server Cluster Description
0x0000 Basic Server Attributes for determining basic information and
setting and enabling device
0x0003 Identify Server Attributes and commands for putting a device into
Identication mode
