1. Introduction

Detailed familiarisation with these operating instructions for the SR-300 RYS smoke

control panel in accordance with the descriptions given therein and observance of all safety

conditions form the basis for correct and safe operation of the unit.

It is assumed that work relating to transport, connection of plant associated with the

appliance as well as maintenance and repair is carried out by qualified personnel or is

supervised by authorised persons.

Qualified personnel are understood to be persons who, in view of their training,

professional experience of electronic equipment and knowledge of the relevant standards,

documentation and regulations relating to safety and working conditions, have been authorised

to carry out the necessary maintenance work on the basis of training protocols and are able to

diagnose and eliminate potential hazards.

The following operating instructions provide information on the application,

construction, assembly, use and maintenance of the SR-300 RYS smoke control panel. If the

units are operated as intended, this manual and other documents included with the unit

contain the instructions necessary for qualified personnel.

NOTE:

The manufacturer reserves the right to make changes to this instruction

manual.

Version 1.40

Release date: 17.02.2023 year

Page 3 of 74

Operation and Maintenance Manual

SR-300

2. General Rules of Safe Use

The SR-300 RYS smoke control unit was designed and built to comply with the

standard:

- prEN –12101-9:2011 Smoke and heat control systems –Part 9: Control panels

In designing and building the SR-300 RYS smoke control panel, SMAY used the latest

technology to guarantees the highest level of safety.

SMAY carries out continuous production supervision, which directly translates into

a high level of quality of the products offered, including the panels, their usability and their

exceptional service life. Despite this, devices can be dangerous if not properly used by

unqualified personnel or used in a manner inconsistent with its intended use.

NOTE:

Installation of the unit, connecting the associated systems, launching,

operation and maintenance shall be performed in accordance with directives and

legal regulations in force in the country where the unit is being installed.

The SR-300 RYS smoke extraction control panel should be used in compliance

with the instructions for use and within the technical parameters given herein.

SMAY authorised service points should be contacted for help as needed during

assembly, installation, commissioning, repairs and maintenance.

The documentation shall always be kept near the device to be easily accessible

for the service personnel.

Version 1.40

Release date: 17.02.2023 year

Page 4 of 74

Operation and Maintenance Manual

SR-300

3. Legal Regulations

3.1. Marketing authorisation

The SR-300 RYS smoke extraction control panels were admitted to the market under

documents issued by the Scientific and Research Centre for Fire Protection –National Research

Institute in Józefów:

1. National Technical Assessment No: CNBOP-PIB-KOT-2019/0115-1009

2. National Certificate of Constancy of Performance: 063-UWB-0192

3. Certificate of Constancy of Performance: 1438-CPR-0667

4. Approval Certificate: 3779/2019

The SR-300 RYS smoke extraction control panel was awarded the "B" construction mark

by the manufacturer. Its compliance with the National Technical Assessment has been

confirmed by the National Declaration of Constancy of Performance No: 017-B-2019

The SR-300 RYS smoke extraction control panel was assigned by the manufacturer with

the mark of the approval body of the Scientific and Research Centre for Fire Protection –

National Research Institute in Józefów (CNBOP-PIB).

4. Concept of the SR-300 RYS Smoke Extraction Control Panel

4.1. Intended use of the SR-300 RYS smoke extraction control panel

The SR-300 RYS smoke extraction control panel is designed for the control, supply and

monitoring of devices in smoke ventilation systems for buildings. It also provides the

ventilation function using a weather station.

The control unit can transmit fire alarm signals to devices or systems that are

responsible for fire safety on the premises. It is possible to use the control panel in the

following structures:

-Residential buildings

-Public buildings

-Factories

-Warehouses

The RYS control panel makes it possible to connect and monitor lines, with the following items

connected: smoke sensors for automatic smoke (smoke and heat) detection, as well as manual

call points for the activation of an appropriate control and monitoring procedure for firefighting

devices by a person who detects fire.

4.2. SR-300 RYS smoke extraction control panel technical data

The control unit can receive the initiating signals from the Fire AlarmSystem and other

fire safety systems or can carry out its control and monitoring functions based on its own

detection of the fire hazard by means of smoke (smoke and heat) sensors and manual call

points placed on the SR-300 RYS Smoke control panel monitoring lines.

When a fire hazard is detected, the exhaust element located in the roof/upper part of the

stairwell and the air compensation opening (door, air intake) are opened. Optionally, the

acoustic/optical fire alarm may be activated. Optionally, if the building is fitted with electric door

holders leading from the individual storeys to the stairwell, the doors are released and closed.

Version 1.40

Release date: 17.02.2023 year

Page 5 of 74

Operation and Maintenance Manual

SR-300

The control unit is able to perform the following functions:

-Detection of fire hazards via smoke and/or heat sensors

-Manual activation by means of manual call points

-Opening of the exhaust component

-Optical and acoustic sounder in the event of a fire hazard

-Ventilation of the stairwell when occupied

-Release of the door opener and door opening

-Communication with the fire alarm system, the system integrating fire protection

equipment (SIUP), the BMS and the access control system (control signals, faults

and operating acknowledgements)

4.3. Basic information

The SR-300 RYS smoke exhaust control panel is used to receive and process fire alarm

signals from the fire alarm system, automatic smoke and heat sensors, manual call points, as

well as to control and power executive elements of the staircase smoke exhaust system such

as door actuators, exhaust element actuators, air intake actuators and devices cooperating

with the SR-300 RYS smoke exhaust control panel, such as acoustic, optical and acoustic-

optical sounders or electric strikers. The SR-300 RYS smoke exhaust control panel can

cooperate with ventilation buttons and control ventilation with a weather station (optional

feature).

The control panel is manufactured in accordance with and meets the design requirements of

prEN 12101-9.

The integrated electrical supply for the control panel is made and certified in accordance with

EN 12101-10.

Selectable group configurations: up to four smoke extraction groups and up to four ventilation

groups.

The SR-300 smoke exhaust control panel is produced in 12 types, which differ in terms of the

number of available inputs/outputs and power. For a description of each type, see subsection

4.4 of this manual. Each of the 12 types of control unit can be extended with optional

additional cards, which are described in section 6 of this manual.

The maximum version of the control unit (SR-300 4.48 version without additional cards)

has the following inputs/outputs:

•Power output –intended for use with 24 V DC-powered devices (48 W maximum)

•Actuator outputs –four outputs designed to work with 24 V DC electric actuators with

variable polarity

•Electric door strike outputs –two voltage outputs intended to cooperate with door strikers

•Digital outputs –five potential-free outputs designed for:

-fault signalling

-four configurable outputs

•Supervised digital inputs –four inputs designed to receive digital signals, all inputs are

configurable

•Unsupervised digital inputs –five inputs designed to receive the following digital signals:

-signal from the weather station

-power supply fault indication

-230 V AC mains fault indication

-two configurable inputs

Version 1.40

Release date: 17.02.2023 year

Page 6 of 74

Operation and Maintenance Manual

SR-300

•MCP (manual call points) inputs –three lines (configurable fire/reset function for each input)

supervised, intended for use with manual call points; up to 10 manual call points can be

connected to a single line; all lines allow for monitoring of line short circuit/break status

(parametrisation with 5.6 ÷ 10 kΩ resistors)

•MCP (manual call points) outputs –five outputs intended for signalling the status of the MCP:

standby, fault, ventilation and fire (two outputs)

•SD smoke detector inputs –two conventional surveillance lines for use with smoke detectors;

each line can accommodate up to 32 smoke detectors or smoke and heat detectors; all lines

allow monitoring of line short-circuit/break conditions on the line (parametrisation with 4.7

kΩ resistors)

The SR-300 RYS smoke extraction control panel requires programming based on the

technical parameters of the connected receivers and in accordance with the fire emergency

scenario. The configuration of the SR-300 RYS smoke extraction control panel is done using

a dedicated configurator.

The configuration instructions in the configurator are a separate document and are

supplied with the unit. The configurator can be downloaded from the SMAY website.

4.4. SR-300 RYS extraction control panel series types

The SR-300 RYS smoke extraction control panel series consists of 12 types. The different

types differ in the number of inputs, outputs and the maximum available current to supply the

devices connected to the control panel. A description of the individual inputs and outputs of the

control panel, together with their configuration options can be found in section 7 of this

manual.

Table 4.1 considers the differences between the different types of SR-300, while technical data

can be found in section 5.2 of this manual.

In Table 4.1, the inputs/outputs are separate from the inputs/outputs of the manual call

points. There is one full input/output under MCP on each SR-300, while a simple MCP

input/output is available on selected unit types.

The full MCP input/output includes:

- two supervised configurable inputs (fire and reset)

- two non-supervised configurable inputs (ventilation start and ventilation stop)

- four configurable outputs 24 V DC to MCP diodes (standby, fault, fire and ventilation)

A simple MCP input/output includes:

- one supervised configurable input (fire, reset)

- one 24 V DC output for fire indicator on the MCP

Version 1.40

Release date: 17.02.2023 year

Page 7 of 74

Operation and Maintenance Manual

SR-300

4.48

46 [A]

YES

+2 sound out.

+2 vis. out

+1 Wind &

rain sensor

+2 Sup. in. +2

No-pot. out.

+1 Full MCP in.

+ 1 sim. MCP in.

+2 Smoke

detector lines

4.39

41.3 [A]

YES

+2 sound out.

+2 vis. out

+1 Wind &

rain sensor

+2 Sup. in. +2

No-pot. out.

+1 Full MCP in.

+ 1 sim. MCP

in.

+2 Smoke

detector lines

4.29

31 [A]

YES

+2 sound out.

+2 vis. out

+1 Wind &

rain sensor

+2 Sup. in. +2

No-pot. out.

+1 Full MCP in.

+ 1 sim. MCP

in.

+2 Smoke

detector lines

4.20

23.4 [A]

YES

+2 sound out.

+2 vis. out

+1 Wind &

rain sensor

+2 Sup. in. +2

No-pot. out.

+1 Full MCP in.

+ 1 sim. MCP in.

+2 Smoke

detector lines

4.8

10 [A]

YES

+2 sound out.

+2 vis. out

+1 Wind &

rain sensor

+2 Sup. in. +2

No-pot. out.

+1 Full MCP in.

+ 1 sim. MCP

in.

+2 Smoke

detector lines

2.29P

31 [A]

YES

+2 sound out.

+2 vis. out

+1 Wind &

rain sensor

+2 Sup. in. +2

No-pot. out.

+1 full MCP in.

+ 1 sim. MCP

in.

+2 Smoke

detector lines

2.20

22 [A]

YES

+2 sound out.

+2 vis. out

+1 Wind &

rain sensor

+2 Sup. in. +2

No-pot. out.

+1 Full MCP in.

+ 1 sim. MCP

in.

+2 Smoke

detector lines

2.8

10 [A]

YES

+2 sound out.

+2 vis. out

+1 Wind &

rain sensor

+2 Sup. in. +2

No-pot. out.

+1 Full MCP in.

+ 1 sim. MCP

in.

+2 Smoke

detector lines

1.20P

22 [A]

YES

+2 sound out.

+2 vis. out

+1 Wind &

rain sensor

+2 Sup. in. +2

No-pot. out.

...............

1.8P

10 [A]

YES

+2 sound out.

+2 vis. out

+1 Wind &

rain sensor

+2 Sup. in. +2

No-pot. out.

...............

1.8

10 [A]

YES

+2 sound out.

+2 vis. out

+1 Wind &

rain sensor

+2 Sup. in. +2

No-pot. out.

...............

1.4

5.5 [A]

YES

+2 sound out.

+2 vis. out

+1 Wind &

rain sensor

+2 Sup. in. +2

No-pot. out.

...............

TYPE SR-300

NUMBER OF FIRE ZONES

NUMBER OF VENTILATION ZONES

NUMBER OF ACTUATOR OUTPUTS

TOTAL OUTPUT CURRENT

POWER SUPPLY OUTPUT

POTENTIAL-FREE OUTPUTS

SUPERVISED INPUTS

UNSUPERVISED INPUTS

FULL MCP INPUT/OUTPUT

SIMPLE MCP INPUT/OUTPUT

SMOKE DETECTORS INPUTS

ELECTRIC DOOR STRIKE OUTPUTS

SLOT FOR SIGNALLING DEVICE

BOARD

CONTROL PANEL FUNCTIONALITY

WITH SIGNALLING DEVICE BOARD

WEATHER STATION BOARD SLOT

CONTROL PANEL FUNCTIONALITY

WITH WEATHER STATION BOARD

SLOT FOR THE DIGITAL I/O BOARD

CONTROL PANEL FUNCTIONALITY

WITH DIGITAL I/O BOARD

SLOT FOR MCP BOARD

CONTROL PANEL FUNCTIONALITY

WITH MCP BOARD

SLOT FOR SMOKE DETECTOR BOARD

CONTROL PANEL FUNCTIONALITY

WITH SMOKE DETECTOR BOARD

Version 1.40

Release date: 17.02.2023 year

Page 8 of 74

Operation and Maintenance Manual

SR-300

NOTE:

The following abbreviations are used in the table:

•sound out. –acoustic sounder outputs

•vis. out. –visual signalling output

•Wind and rain sensor –wind and rain sensor

•Sup. in. –supervised input

•No-pot. out. –potential-free output

•Full MCP in. –full input manual call points

•Sim. MCP in. –simple input manual call points

4.5. Inputs/outputs used depend on the type of the SR-300 RYS

Description

I/O no

Type

1.4

1.8

1.8P

1.20P

2.8

2.20

2.29P

4.8

4.20

4.29

4.39

4.48

SR-300 RYS smoke extraction control panel

Actuator outputs

Electric door strike outputs

Digital outputs

Out 1

Out 2

Out 3

Version 1.40

Release date: 17.02.2023 year

Page 9 of 74

Operation and Maintenance Manual

SR-300

Out 4

Out 5

Digital inputs

Unsupervised inputs

In. 1

In. 2

In. 3

Supervised inputs

In. 4

In. 5

In. 6

In. 7

Panelinputs of smoke

detectors

Detector 1

Detector 2

MCP (manual call point) inputs

Simple MCP

In. 1

Full MCP

In. 2

In. 3

In. 8

In. 9

Altri manuali per SR-300

Indice

Altri manuali SMAY Pannello di controllo

SMAY

SMAY SR-300 Foglio di istruzioni

Manuali Pannello di controllo popolari di altre marche

RDZ

RDZ PC-HRX Manuale utente

STG-BEIKIRCH

STG-BEIKIRCH MZ3 Manuale tecnico

Efka

Efka Variocontrol V810 Manuale utente

Cebora

Cebora 208-10 Manuale utente

AMX

AMX AutoPatch CP-15 Manuale utente

Satel

Satel CA-6 KLED-S Manuale utente

Evolution

Evolution IQ plus 800 Manuale utente

Fagor

Fagor 8040 TCO CNC Manuale utente

Trane

Trane ComfortLink II XL950 Control Manuale utente

AKO

AKO PROCool AKO-17635-2 Manuale utente

ABB

ABB 6136/30M-101 Manuale utente

Telikou

Telikou BK-603 Belt Pack Manuale utente

Mapei

Mapei Mapeheat Thermo Touch Manuale utente

Bosch

Bosch D9412GV4 Manuale utente

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries SC-SL4-AE2/1 Manuale utente

Sminn

Sminn BOX L VF1L EI Manuale utente

Balboa

Balboa TP600 Manuale utente

Nice

Nice HSCU1 Specifiche tecniche
