SMB GFI EXINDA 4062V2 Manuale utente
EXINDA 4062V2
QUICK START GUIDE
The information and content in this document is provided for informational purposes only and is provided "as is" with no warranties of
any kind, either express or implied, including without limitation any warranties of merchantability, fitness for a particular purpose, and
non-infringement. GFI Software disclaims and in no event shall be liable for any losses or damages of any kind, including any
consequential or incidental damages in connection with the furnishing, performance or use of this document. The information is
obtained from publicly available sources. Though reasonable effort has been made to ensure the accuracy of the data provided, GFI
makes no warranty, promise or guarantee about the completeness, accuracy, recency or adequacy of information contained in this
document and is not responsible for misprints, out-of-date information, or errors. GFI reserves the right to revise or update its products,
software or documentation without notice. You must take full responsibility for your use and application of any GFI product or service. No
part of this documentation may be reproduced in any form by any means without prior written authorization of GFI Software.
If you believe there are any factual errors in this document, please contact us and we will review your concerns as soon as practical.
GFI trademarks or registered trademarks of GFI Software or its affiliates in the US and other countries. Any other trademarks contained
herein are the property of their respective owners.
is copyright of Exinda Inc.. - 1999-2021 Exinda Inc.. All rights reserved.
Document Version:
Last updated (month/day/year): 04/08/2021
Exinda 4062 v2 - Quick Start Guide
0.0.1 Hardware Specifications
Specification Detail
Form factor Desktop or 1U rack mount
Dimensions 44mm x 300mm x 436mm (1.72" x 11.81" x 16.81")
Power Internal – autoranging
Power Rating 17W @ 0.13A (Idle), 22W @ 0.16A (Max)
Weight 5.1kg (11lb)
RAM 16GB (2 x 8GB DIMMs)
Data Store/Cache Size SSD D3-S4510 (960GB)
Environment Continuous operation: 5°C to 35°C (41°F to 95°F), 8% to 90% relative humidity (non-condensing)
0.1 Step 1 - Physical Installation
Follow these steps to start the installation:
1. With the appliance powered OFF, install a straight through cable between Exinda’s LAN port and the LAN switch.
2. Install a crossover cable (red) between Exinda’s WAN port and the Router/Firewall.
3. Ensure that there is connectivity through the appliance.
This will ensure that Ethernet bypass is working.
4. Install a straight through cable (blue) between Exinda’s management port and the LAN switch.
5. Plug in the power cord.
6. Optional: Connect a monitor cable and USB keyboard for the initial configuration.
7. Switch on the appliance and ensure that the rear NIC lights flash and traffic is passing through.
0.2 Step 2 - Start Exinda
There are two possible ways to start your Exinda Appliance:
0.2.1 Jumpstart from the web interface
By default, the Exinda appliance obtains an IP address from DHCP on the management interface (Gb1). It finds the IP that the appliance
obtained, refer to the section below.
Note
If the Exinda does not obtain a DHCP address, it will default to IP address 172.14.1.57. If this happens, connect a PC with a straight-
through cable directly to Gb1, configure your PC's network adapter with an IP in the 172.14.1.0/24 subnet (IP: 172.14.1.58;
netmask:255.255.255.0). Open a web browser and connect to the Web User Interface by typing
https://172.14.1.57 in the address field.
1. From a web browser go to the following website: www.findmyexinda.com. This will download an applet and automatically
find the recently installed Exinda appliance.
www.findmyexinda.com uses a multicast packet to find local Exinda appliances. Therefore, you need to be on the same physical
local LAN for this to work.
2. Click on the Exinda appliance that has been found.
3. Log in with the username=admin and password=exinda.
4. Read and accept the End User License Agreement.
5. The system automatically starts the Configuration Wizard. Complete all steps.
6. Click Save in the status bar. Click ‘advanced mode’ in the title area.
This finished the initial configuration.
0.2.2 Using a Monitor and keyboard to Access the Command Line Interface
1. Plug a keyboard and a monitor to your Exinda Appliance.
2. Optionally: connect a Cisco compatible serial cable to the RJ45 serial port (upper left port).
3. To access the Exinda appliance via serial console, use your preferred terminal software (such as HyperTerm) with the following set-
tings: Bits per second=115200, Bits=8, Parity=None, Stop bits=1, Flow Control=None.
4. Log in with the username=admin and password=exinda.
5. Read and accept the End User License Agreement.
6. The system automatically starts the Configuration Jump Start. Complete all steps.
7. Click Save.
This finished the initial configuration.
For further support, visit https://www.gfi.com/support/exinda-support.
