SMC Networks EZ Networking SMC2208USB/ETH Manuale utente

Network Adapters SMC2208USB/ETH

EZ NetworkingTM USB to 10/100 Mbps Ethernet Adapter

www.smc.com

SMC's family of USB products offers a convenient and cost-

effective means of bringing straightforward peripheral

connectivity to the desktop based on the Universal Serial

Bus (USB). These products feature true plug-and-play

connection of PC peripherals "outside the box" and mark a

significant advance in desktop cable management. Using

the EZ Networking™ USB to Ethernet Converter you can

simplify PC connections in the home, office, or on the road.

The SMC2208USB/ETH USB to 10/100 Mbps Ethernet

adapter product supports Plug-and-Play and is easy to

install. The included EZ Installation Wizard makes

driver/utility installation a breeze. The USB to 10/100 Mbps

Ethernet Adapter is bus-powered, hence, it draws power

from the USB port of the host PC and requires no external

power supply. Simply plug in this new SMC2208USB/ETH,

which uses Type A USB port, to your Laptop/Desktop's USB

port and connect a Category 5 cable to the RJ-45 connec-

tor. You are now ready to connect and access network

resources.

FEATURES

USB specification 1.0, and 1.1 for standards-based compliance to

ensure compatibility

EZ Installation Wizard

Sleek, compact, and dongleless design

USB bus self-powered

Supports major operating systems

USB 1.0 and 1.1 supports 12Mbps high data rate performance

EZ Installation Wizard ensures easy driver/utility installation

Compact, easy to carry form factor; solid all-in-one design with

no moving parts to break

Draws power from the USB port of the host PC and requires no

external power supply

Supports Windows XP, Linux kernel v2.4 or later versions, Mac

9.X, 10.1 & 10.2

BENEFITS

OVERVIEW

TECHNICAL SPECIFICATIONS SMC2208USB/ETH

INTERFACES

• Complies with USB specification v1.0 and v1.1

• One 4-pin A-type USB connector

• One RJ-45 connector for Ethernet network interface

STANDARDS

• USB Specification 1.0 and 1.1

• IEEE 802.3 Ethernet

• IEEE 802.3u Fast Ethernet

ACCESS METHOD

• USB Port: USB spec.1.0 and 1.1

• RJ-45 Port: IEEE 802.3 and 802.3u CSMA/CD

• 10 and 100 Mbps full and half duplex

POWER CONSUMPTION

• 10Mbps mode: Max 143mA @5V

• 100Mbps mode: Max 150mA @5V

LED INDICATION

• 10/100: ON in 100 Mbps mode, OFF in 10 Mbps mode.

• F/H: ON in full duplex mode, OFF otherwise.

• ACTIVE: ON when 10 or 100Mbps Ethernet traffic is Active

DRIVERS SUPPORT

• Windows XP

• Linux kernel v2.4 or later versions

• Mac 9.X

• Mac 10.1

• Mac 10.2

COMPLIANCES

• FCC part 15 class B

• CE(CISPR22 class B)

ENVIRONMENT

• Operating Temperature: 0 ~ 55OC

• Humidity: 10 ~ 90%

• Storage Temperature -20 ~ 65OC

• Humidity 10 ~ 90%

WARRANTY

• Limited Lifetime

DIMENSIONS

• 74.5 x 28.1 x 15.1 mm

• 2.9 x 1.1 x 0.59 in

WEIGHT

•7.1 g

•.25oz

North America

20 Mason

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/ Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local

country contact information

www.smc.com

Contact
