SMC Networks SMCWCB-N Manuale utente

Wireless SMCWCB-N

EZ Connect™ N Pro Draft 11n Wireless Cardbus Adapter

www.smc.com

The EZ Connect™ N Pro Draft 11n Wireless Cardbus Adapter

(SMCWCB-N) is another cutting edge introduction in 2.4GHz

wireless communication for your notebook computer. Designed

for both the home and office, this Wireless Cardbus adapter

provides the speed, coverage, and security expected by today's

wireless users. The SMCWCB-N is compliant with the next gen-

eration IEEE802.11n draft v1.0 specification while maintaining

full backwards compatibility with the IEEE802.11b/g standards.

This next generation wireless networking standard utilizes

advanced MIMO (Multiple-In, Multiple-Out) technology to deliver

incredible speed & range. With wireless speeds up to 300Mbps

and up to 11x the coverage, the SMCWCB-N provides enough

bandwidth to stream HD video, listen to digital music, play online

games, transfer large files, make VoIP calls and surf the Internet

simultaneously. To secure wireless data transmissions and

prevent unauthorized access the SMCWCB-N supports the latest

WPA/WPA2 wireless security standards. WEP 64-Bit and 128-Bit

wireless encryption is also provided for securely connecting to

legacy devices which do not support the latest WPA/WPA2

standards. The SMCWCB-N includes an EZ Installation Wizard

for quick and easy installation. Simply put the EZ Installation

Wizard CD into your computer's CD-ROM drive, click on Install

Driver/Utility Link, and the wizard will perform the installation

automatically. Then insert your SMCWCB-N into an available

PCMCIA Type II or Type III slot on your notebook computer and

you are ready to enjoy the freedom of wireless networking. The

SMCWCB-N WLAN utility scans for all available wireless

networks and its profile management allows you to save names

and settings of multiple networks, so connecting becomes

instantaneous.

FEATURES

IEEE802.11n draft v1.0 compliant

IEEE802.11b/g compliant

EZ Installation Wizard

WPA/WPA2 Encryption

Wi-Fi Protected Set-up™ (WPS)*

Wi-Fi Multimedia (WMM)

BENEFITS

OVERVIEW

Utilizes advanced MIMO (Multiple-In, Multiple-Out) technology

to deliver incredible speed & range. With wireless speeds up to

300Mbps and up to 11x the coverage, you can stream HD video,

listen to digital music, play online games, transfer large files,

make VoIP calls and surf the Internet simultaneously.

Fully backwards compatible with the popular IEEE802.11b/g

standards.

Quick and easy installation.

Enterprise class WPA/WPA2 encryption secures your wireless

network from unwanted intruders.

Makes installation and activation of wireless security easy

Provide quality-of-service (QoS) to the wireless traffic by auto-

matically prioritizing and optimizing the handling of different

applications.

TECHNICAL SPECIFICATIONS SMCWCB-N

EASE OF USE

• EZ Installation Wizard

• Wi-Fi Protected Setup™*

SECURITY FEATURES

• WEP 64-/128-Bit Encryption

• WPA-/WPA2-PSK (Pre Shared Key)

QUALITY-OF-SERVICE (QOS)

• WMM (Wi-Fi Multimedia)

LED INDICATOR

• Link status

• Activity

STANDARDS

• IEEE802.11b, IEEE802.11g, IEEE802.11n draft v1.0

OPERATING FREQUENCY

• FCC: 2412~2462MHz (Ch1~Ch11)

• ETSI: 2412~2472MHz (Ch1~Ch13)

TYPICAL RF OUTPUT POWER

• 11n Mode: 10dBm (MCS7/15), 19dBm (MCS0/8)

• 11g Mode: 18dBm

• 11b Mode : 19dBm

TEMPERATURE

• Operating: 0odegrees C to 40odegrees C

• Storage: -10odegrees C to 70odegrees C

HUMIDITY

• Storage: 10% to 90% Non-condensing

DIMENSIONS

• 53.95 x 122.4 x 10.1mm

• 2.1 x 4.8 x 0.4in

WEIGHT

• 0.05Kg

• 0.11Ibs

CERTIFICATIONS

•FCC

•CE

SYSTEM REQUIREMENTS

• 2.4 GHz 802.11n draft wireless network or 2.4 GHz 802.11b/g

wireless network

• Microsoft Windows 2000 or Windows XP

• A Notebook with:

• 300MHz CPU or above

• Available PCMCIA Type II or Type III slot

• 20MB of available hard disk space

• CD-ROM drive

• We recommend using this product with the SMCWBR14-N

Barricade™ N Broadband Router or the SMC7904WBRA-N

Barricade™ N ADSL2/2+ Modem Router

PACKAGE CONTENTS

• EZ Connect™ N Wireless Cardbus Adapter (SMCWCB-N)

• Installation CD containing:

• EZ Installation Wizard

• Manual

• Quick Installation Guide

• Warranty registration card

WARRANTY

• SMC Limited Lifetime

*Support for these features will be added through future

driver/utility upgrade

North America

20 Mason

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/ Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local

country contact information

www.smc.com
