SMC Networks SMCWTVG Manuale utente

Wireless SMCWTVG

Wireless Travel Voice Gateway

www.smc.com

The SMCWTVG integrates the function of a wireless gateway

and a VoIP ATA into a compact device. The SMCWTVG is a

high speed broadband router that is capable of delivering

internet access to several users via the NAT function. The

wireless feature can be used in two different operating

modes. It can function as an 802.11b/g access point providing

service to wireless clients and as a wireless client itself for

PC connections to other Wi-Fi networks. All these features

combined make this the perfect accessory for any corporate

or business traveler.

Integrated wireless ensures this device can provide wireless

mobility for each user connecting to the SMCWTVG.

Advanced WPA2 and WEP encryption protects a users privacy

when using public hotspot networks or in a hotel environment.

In addition to encryption, the SMCWTVG supports MAC

address filtering and disable SSID broadcast.

For VoIP users the SMCWTVG provides the option to connect

an analog phone into the FXS interface for lower cost

telephone calls. Combined with either a VoIP service, or VoIP

access to your corporate LAN, users can now make voice

calls over the internet. And, with the Built-in FXO port users

have the ability to place or receive calls via the traditional

phone provider without difficulties.

FEATURES

Full VoIP Support

Integrated 802.11b/g Wireless

Easy Setup and Installation

Built-in Security for wireless and wired users

VoIP technology provides users the capability of voice

communication over IP networks (Internet).

Wireless Access point mode is used for providing wire-

less client access, and client mode allows the SMCWTVG

to connect to another wireless access point within range.

The easy-to-use setup wizard will help you to install the

SMCWTVG with just a few easy clicks.

Gateway features like Network address translation (NAT),

SPI firewall and VPN pass-through provide the capability

of constructing secure networks.

Advanced WPA2 and WEP encryptions will ensure the

users privacy while using the wireless functionality of the

SMCWTVG.

BENEFITS

OVERVIEW

TECHNICAL SPECIFICATIONS SMCWTVG

PORT

• One Wan 10/100 BaseT Ethernet Connection to a ADSL/ Cable modem

• One LAN 10/100 BaseT Ethernet connection to connect to a PC

• RJ-11 voice interface, FXS for connecting to a standard analog telephone

• RJ-11 voice interface, FXO for receiving calls on your regular PSTN line

GATEWAY FEATURES

• NAT/NAPT

• DHCP

• PPPoE

• Static IP

NETWORKING

• DNS

• DNS Relay

• Dynamic DHC

• Syslog

• Virtual DMZ

• Virtual Server

• VPN pass-through

• L2TP

• PPTP

• IPSec

• UPnP

• SNTP

• QOS

• 2 Priority levels

• QOS supports DSCP

• 802.1x

• EAP:TLS

SECURITY

• SPI Firewall

• DoS attack Protection:

• IP Spoofing

• Land Attack

• Ping of Death

• Smurf Attack

• TCP null scan

• SYN flood

• ICMP defect

WIRELESS FEATURES

• Wireless: IEEE 802.11b/g

• 3 modes

• AP mode

• Client mode

• QOS: 802.11e(WMM)

VOIP FEATURES

• Voice signaling protocol: SIPv2

• Voice Codec

• G711a-law/u-law

• G.726

• G729A/B

• Voice quality

• VAD ( Voice Activity Detection)

• CNG( Comfortable Noise Generation)

• Echo Cancellation ( G.165/G.168 echo canceller)

• Adaptive Jitter Buffer

• DTMF tone detection and generation

• Call Progress Generation

• Custom tone Generation

• Call features

• Call transfer

• Call waiting/Hold/Retrieve

• Call-ID block

• Do not Disturb Setting

• Call Return

• Distinctive Ringing

PERFORMANCE

• RF output power

• 802.11b: 18dBm

• 802.11g: 14dBm

• RF data rate ( automatic fall back)

• 802.11b: 1/2/5.5/11Mbps

• 802.11g: 6/9/12/18/24/26/48/54 Mbps

DIMENSION

• 24.7 mm X 107.5 mm X 78.67 mm (HxWxD)

POWER SUPPLY

• Input AC :100~240V 0.3A 50-60Hz

ENVIRONMENT

• Temperature: IEC 68-2-14

• -10 C to 50 C ( standard Operating)

• -40 C to 70 C ( Non-operation)

• Humidity 5% to 95% (Non condensing)

• Vibration: IEC 68-2-36 , IEC 68-2-6

• Shock: IEC 68-2-29

• Drop: IEC 68-2-32

EMISSIONS/SAFETY

• Safety: UL/cUL (UL60950) CB EN60950

• EMC: FCC part 15B class B, FCC part 15C FCC part 68,

CE EN55022 Class B

• EMS: CE en55024, CE EN 300328, CE EN301489

MANGEMENT

• Web-based management

• Firmware Upgrade Via HTTP Web Interface

North America

38 Tesla

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/ Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local

country contact information

www.smc.com
