SMC Networks TigerSwitch SMC6709FL2 Manuale utente

TigerSwitch 10/100

9-Port Fast Ethernet Switch

◆ 8 10BASE-T/100BASE-TX ports, 1 100BASE-FX

MMF port

◆ 1.8 Gbps aggregate bandwidth

◆ Spanning Tree Protocol

◆ Port mirroring for non-intrusive analysis

◆ QoS support with two priority queues

◆ Full support for VLANs with GVRP

◆ IP multicasting with IGMP snooping

◆ Security filtering based on MAC addresses

◆ Manageable via console, Web, SNMP/RMON

Installation Guide

SMC6709FL2

38 Tesla

Irvine, CA 92618

Phone: (949) 679-8000

TigerSwitch 10/100

Installation Guide

From SMC’s Tiger line of feature-rich workgroup LAN solutions

February 2004
